JNS Aquaria VS-1.5 Installation Manual

9
Install the silencer with lid.
Install the large O-ring and drain tube onto the
10
collection cup.
Install the collection cup and connect the air
hose to the silencer.
Recommendations
1
For best performance, clean the collection cup frequently with a sponge and warm water
2
It may require 2 – 4 weeks for the skimmer to reach optimal performance due to tiny amounts of oil or remnants left from manufacturing. Skimmer
performance may be erratic during this time; be sure to allow ample time for the skimmer to break-in before making adjustments. You can clean the
skimmer with warm water and sponge to shorten the break-in-period.
3
Regular maintenance of the pump will ensure a long life and maximum performance: recommended every 3 months.
You can disassemble the pump by following steps:
(1) Take off the air hose and connector to check if there's any clogging and clean it up. (especially the place marked on the photo)
It's common that the carbonate (limescale) builds up to form a very hard white substance.
(2) Loosen the nut ring to pull out the inside parts.
Warranty
JNS warrants all JNS products to be free from manufacturing defects for one year from the original purchase date when purchased through an authorized JNS retailer. This warranty
does not cover any damages caused by misuse, neglect, alterations or improper handling / transport / maintenance / installation. Physical damages are not covered by warranty. JNS
does not cover personal injury, personal loss, or other damages associated with the use of our products. In order to request warranty service, please email us at info@jnsaquaria.com.
A purchase receipt is required for any warranty services. Products requiring warranty service must be returned to JNS. You are responsible for the cost of shipping a warranty claim to
JNS and any damages that may occur during transit. Once a returned product has been inspected, it will be repaired or exchanged at our discretion and returned to you. Internation-
al and/or expedited shipping are not covered under your JNS warranty.
Select a suitable place to set your VS-1.5
1
The aquarium's water level
must not be more than 10 cm
from the aquarium's rim.
10 cm
To Start
1
Fill skimmer with aquarium water until it flows out of the outlet.
2
Remove the air hose from the silencer, pick up the silencer and
water to prime the pump. (image
3
Plug-in, and wait until the pump primes,
and no air in the inlet tubes. This may
take a few minutes (verify the air hose is
immersed in water and the inlet/outlet
pipes are tightly connected). Once it's
done, water would be flushed out from
the outlet. (image )
3
4
Once the pump is primed and operating normally, pull the
air hose out of water and replace it on to the silencer.
5
The skimmer will take 2-4 weeks to reach optimal
operation. During the break-in period, we recommend
setting the collection cup in its highest position (with the
O-ring placed towards the bottom of the collection cup).
You can adjust the form of skimmate by simply
changing the position of O-ring.
O-ring level low
skimmate color
(3) Separate the inside parts to clean, espacially the impeller.
After assembly, test if the rotor could turn normally.
2
The water intake must be completely
submerged underwater when in use.
3
Hang the protein skimmer on the
aquarium. Adjust the positioning
screws so the skimmer is parallel to
your aquarium.
Caution! Over-tightening the
screws will damage the skimmer!
immerse in skimmer
)
2
image 3
high
How to remove the limescale?
NO OTHER CHEMICALS, soak in a
mixture of 1 part water and 1 part
vinegar (citrin acid also available) for
at least 24 hours. Once you finish,
please rinse with warm water.
** please clean carefully with brush.
small washer could be
easily ignored, make sure
to put it back in positon.
