JNS Aquaria ConeS CO Series Quick Start Manual

ConeS CO Series
In-Sump Protein Skimmer
CO-2 / CO-3 / CO-5 / CO-6
Footprint (mm) 370x180 or 315x270
Height (mm)
SHARK 2.0 (22W)
Pump
Filtration Rating (L)
Light Bioload
Heavy Bioload
Recommended
Water Level (mm)

Before Use

Please open the package carefully and check for damaged or lost parts. PARTS INCLUDED:
Collection Cup
with lid
Main body Silencer

Recommendations

While we take great care to keep any contaminates away from our products during assembly, please take a moment to clean the skimmer and
1.
plumbing before attaching to your tank. Only clean your product with warm water. Never clean Acrylic with alcohol based products. Use
caution when handling as acrylic scratches easily.
It may require 2 ‒ 4 weeks for the skimmer to reach maximum performance due to tiny amounts of oil or remnants left from manufacturing.
2.
Skimmer performance may be erratic during this time and be sure to allow ample time for the skimmer to break-in before making adjustments.
Regular maintenance of the pump will ensure a long life and maximum performance: recommended every 3 months.
3.
For best performance, please clean the collection cup frequently. Use a sponge and warm water to clean it.
4.
(DO NOT USE ANY SOAP OR CHEMICALS TO CLEAN THE COLLECTION CUP).

Assembly

Install the rubber feet to
1.
the base of the main body
and the pump.
5. Connect the pump
to the silencer with
Ø 10mm air hose

Operation

The pump must be completely submerged underwater when in use. Running the pump dry or in too low of a water level will damage the pump.
1.
For proper performance of the quick-precise adjustment valve, the water in your sump must not be any higher than the following levels:
2.
CO-2 CO-3
200 - 220 mm 200 - 220 mm
CO-2 CO-3
360x320 or 440x210
465 580
SHARK 3.0 (27W)
1200 L 1800 L
640 L 1080 L
200 - 220 mm 200 - 220 mm
Drain tube
Ø 10mm air hose
2. Connect the pump to the
main body with Ø 25mm
hose.
CO-5
215 - 230 mm
CO-5
420x350 or 510x270
580
SHARK 6.0 (45W)
2400 L
1400 L
215 - 230 mm
< Accessories pack >
Rubber feet *8 Screw for silencer
Ø 25mm hose
3. Install the silencer to the
main body, to fix silencer
with screw for silencer.
5. Install the drain tube
to the drain port of
the collection cup
CO-6
215 - 230 mm
1
CO-6
420x460 or 560x320
580
SHARK 7.0 (48W)
***
3200 L
The pump must be
2000 L
completely submerged
underwater when in use
215 - 230 mm
< Pump >
CO-2: CO-3:
SHARK 2.0
CO-5: SHARK 6.0 CO-6:
4. Install the collection cup,
do not over-tighten.
SHARK 3.0
SHARK 7.0
