  • Page 1 All manuals and user guides at all-guides.com V ZUG Ltd Cashier system Coin System 1 Coin System 2 Operating instructions...
  • Page 2 The model number corresponds to the first 3 digits on the identification plate. These installation instructions apply to the models: Model Type Model no. Coin System 1 COS 1 Coin System 2 COS 2 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2004...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Contents Safety precautions Before using for the first time ..... . 4 Correct use ........5 Children in the home .

  • Page 4: Before Using For The First Time

    All manuals and user guides at all-guides.com Safety precautions The appliance corresponds to recognised technology stand ards and the relevant safety regulations. Proper use of the appliance is however essential to avoid damage and acci dents. Please therefore follow the precautions given in these operating instructions.

  • Page 5: Correct Use

    All manuals and user guides at all-guides.com … Safety precautions Correct use The appliance is for collecting the costs of operating a washing machine or tumble dryer. No liability is assumed for any damage caused by improper or incorrect use. Any repairs, modifications or manipulations to the appliance, especially any electrically live parts, may only be carried out by the manufacturer, its Customer Services or similarly qualified persons.

  • Page 6: Appliance Description

    All manuals and user guides at all-guides.com Your appliance Appliance description The cashier system controls the power supply to the appliance connected based on the amount entered. Measured and charged is the length of time that electricity is used. Enough coins (CHF / EUR) or tokens have to be entered for a complete wash or drying programme.

  • Page 7: Appliance Construction

    All manuals and user guides at all-guides.com … Your appliance Appliance construction 1 Display for appliance 1 2 Selection key for appliance 1* 3 Selection key for appliance 2* 4 Display for appliance 2* 5 Lock for coin box 6 Coin box cover 7 Identification plate (underside of appliance) 8 Coin/token slot...

  • Page 8: Inserting Coins

    All manuals and user guides at all-guides.com … Your appliance Display messages On using for the first time, a short system test is carried out automatically. – The current software version, e.g. , is shown in the display. – If the credit is zero, is shown in the display.

  • Page 9: Emptying The Coin Box

    All manuals and user guides at all-guides.com … Your appliance Emptying the coin box Coins accepted by the coin validator drop into the coin box. It can hold approximate- ly 400 coins. If a coin is not validated, it automatically drops into the return slot. Use the key to remove the coin box cover 1.

  • Page 10: Totaliser

    All manuals and user guides at all-guides.com … Your appliance Totaliser Total coins entered can be shown in the display. Depress the «–» settings key for about 3 seconds. – The total is shown in the display. Model 245 If the total is greater than , the «+»...
  • Page 11 All manuals and user guides at all-guides.com Calculation The charges to be defined for the appliance are based on the operating costs of the washing machine or tumble dryer connected. The operating costs comprise the costs of the electricity and water consumed as well as of any service agreement.

  • Page 12: Individual Calculation

    All manuals and user guides at all-guides.com … Calculation Individual calculation You will need the following details: Electricity consumption* ... kWh From the operating instructions Water consumption* (1m³ = 1000 litres) ....m³ From the operating instructions Programme duration* ..hr ..From the operating instructions Electricity tariff per kWh (incl.
  • Page 13 All manuals and user guides at all-guides.com Settings Different settings (parameters) can be set for the appliance. This is described below for both models. Depress the «SET» settings key for about 3 seconds. – appears in the display (model 245). –...

  • Page 14: Parameters

    All manuals and user guides at all-guides.com … Settings Parameters The settings are set at the factory as follows: Parameter Unit Setting range Factory setting Your setting 0 or 1 hrs:mins 0:01 to 4:00 1:00 0.00 to 99.90 0.90 hrs:mins 0:01 to 4:00 1:00 0.00 to 99.90...
  • Page 15 All manuals and user guides at all-guides.com … Settings Parameter Unit Setting range Factory setting Your setting 0.0 to 1.0 mins:secs 0:00 to 5:00 5:00 0 or 1 0.00 to 99.90 0.10 0.00 to 99.90 0.20 0.00 to 99.90 0.50 0.00 to 99.90 1.00 0.00 to 99.90...

  • Page 16: Key To Parameters

    All manuals and user guides at all-guides.com … Settings Key to parameters Model 245 and model 246 (appliance 1) Parameter Function Description For setting the operating mode to Operating mode time-dependent (0) appliance 1 or usage-dependent (1) operation Unit for Defines the length of time (e.g.
  • Page 17 All manuals and user guides at all-guides.com … Settings Model 246 (appliance 2) Parameter Function Description For setting the operating mode to Operating mode time dependent (0) appliance 2 or usage dependent (1) operation Unit for Defines the length of time (e.g. 1 hour) time-dependent operation during which the tariff in P33 is valid.
  • Page 18 All manuals and user guides at all-guides.com … Settings General parameters Parameter Function Description For setting CHF / EUR (0) Coin / token operation or tokens (1) Defines the value of 0.10 Value CHF 0.10 CHF 0.10 = 10 rappen Defines the value of 0.20 Value CHF 0.20 CHF 0.20 = 20 rappen...
  • Page 19 All manuals and user guides at all-guides.com Technical data Dimensions Model 245 Model 246 Width: 17 cm 17 cm Height: 32 cm 32 cm Depth: 17 cm 17 cm Weight: 4.8 kg 5 kg Electrical connection Model 245 Model 246 Switching capacity: 400 V 3N~ max.
  • Page 20 All manuals and user guides at all-guides.com Disposal Packaging All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety Disable the appliance to prevent accidents caused by improper use, especially...
  • Page 21 All manuals and user guides at all-guides.com Index Accessories Queries........23 Ordering ......23 Quick instructions ....... 24 Appliance construction....7 Appliance description....6 Repair service ......23 Replacement key......19 Calculation....... 11 Safety........20 Deleting credit......9 Safety precautions Dimensions .......
  • Page 22 All manuals and user guides at all-guides.com Notes...
  • Page 23 – The identification plate is on the underside of the appliance. If the appliance is not working properly, contact your nearest V-ZUG Ltd Service Centre using freephone 0800 850 850 and stand in close proximity to the appliance.
  • Page 24 All manuals and user guides at all-guides.com Quick instructions Please first read the safety precautions in the operating instructions! V ZUG Ltd Industriestrasse 66, 6301 Zug Tel. +41 (0)41 767 67 67, Fax +41 (0)41 767 61 61 vzug@vzug.ch, www.vzug.ch J245.13-2...
