V-ZUG LTD
Cashier system
Coin System 1&2
1
2
Operating instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Coin System 1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for V-ZUG Coin System 1

Summary of Contents for V-ZUG Coin System 1

  • Page 1 V-ZUG LTD Cashier system Coin System 1&2 Operating instructions...
  • Page 2 The product family (model number) corresponds to the first alphanumerics on the identification plate. These operating instructions apply to: Model Type Product range Coin System 1 COS 1 Coin System 2 COS 2 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2014...

  • Page 3: Table Of Contents

    Contents Safety precautions Symbols used ..................General safety precautions ..............Instructions for use Before using for the first time .............. Correct use ....................Children in the household ..............Note on use ..................... Disposal Your appliance Appliance description ................10 Appliance design ................... 11 Inserting coins ..................

  • Page 4: Safety Precautions

    Safety precautions Symbols used Denotes important safety precautions. Failure to observe said precautions can result in injury or in damage to the appliance or fittings! Information and precautions that should be observed. Information on disposal Information about the operating instructions Indicates step-by-step instructions.

  • Page 5: General Safety Precautions

    1 Safety precautions General safety precautions • Read the operating instructions before using the appliance for the first time! • This appliance can be used by children aged 8 and above and by persons with reduced physical, sensory or mental capabilities, or lack of experience and/or knowledge, provided they are supervised or have been instructed on the safe use of the appliance...
  • Page 6 1 Safety precautions • If an appliance is not equipped with a mains cable and a plug or other means for discon- necting from the mains with a contact opening on each pole complying with the conditions of overvoltage category III for full isolation, an isolating device must be incorporated into the permanently installed electrical installation in accordance with the installation regulations.

  • Page 7: Instructions For Use

    Instructions for use Before using for the first time • The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/ electrician carry out the necessary work. • Dispose of the packaging material in accordance with local regulations. •...

  • Page 8: Note On Use

    2 Instructions for use Note on use • If the appliance is visibly damaged, do not use it. Contact our Customer Services. • Do not spray the appliance with water. Do not use a steam cleaner. • If the mains cable of the appliance is damaged, it must be replaced by Customer Services to avoid any danger.

  • Page 9: Disposal

    Disposal Packaging • All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection • Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety •...

  • Page 10: Your Appliance

    Your appliance Appliance description The cashier system controls the power supply to the connected appliance based on the amount entered. The length of time that electricity is consumed is then measured and charged. Enough coins (CHF / EUR) or tokens have to be inserted for a complete wash or drying programme.

  • Page 11: Appliance Design

    4 Your appliance Appliance design 1 Display for appliance 1 2 Selection button for appliance 1* 3 Selection button for appliance 2* 4 Display for appliance 2* 5 Lock for coin box 6 Coin box cover 7 Identification plate (underside of appliance) 8 Coin/token slot 9 Return slot...
  • Page 12 4 Your appliance Settings buttons Open the coin box cover. 1 2 3 – The settings buttons are located above the coin box. Features depend on the model. 1 Settings button «+» 2 Settings button «–» 3 Enter/Exit the settings at «SET»...

  • Page 13: Inserting Coins

    4 Your appliance Inserting coins Model 245 The coins are inserted in the coin/token slot. – The current credit is shown in the display. Model 246 Select required appliance. – The display with the current credit flashes for 5 seconds. Insert the coins while the display is flashing.

  • Page 14: Deleting Credit

    4 Your appliance Deleting credit Example: You have a credit of and would like to delete it. Press the «+» and «–» settings buttons at the same time for about 6 seconds. – The deleting process is shown in the display: –...

  • Page 15: Calculation

    Calculation Preface to the calculation The costs which are calculated for the appliance are based on the operating costs of the washing machine or tumble dryer connected. The operating costs comprise the costs of the electricity and water consumed as well as of any service subscription.

  • Page 16: Individual Calculations

    5 Calculation Total operating costs per programme (duration 70 mins.) CHF 1.14 Operating Per hour Programme duration costs CHF 1.14 × 60 mins. ÷ 76 mins. CHF/hr 0.90 In the absence of any individual components of the calculation, we recom- mend a sum of CHF 0.90 per hour for washing and CHF 1.20 per hour for drying.
  • Page 17 5 Calculation Water costs (incl. waste water) Water consumption Water rate Water costs …….m × CHF/m CHF ..... 3…… Subscription costs (per year with 5 to 12 parties) Service subscription (WM * No. wash cycles Subscription costs costs CHF…… + …… = CHF …… ÷...

  • Page 18: Settings

    Settings Instructions for settings Different settings (parameters) can be set for the appliance. This is described below for both models. Press the «SET» button for about 3 seconds. – appears in the display (model 245). – appears in the displays (model 246). Press the «+»...

  • Page 19: Parameters

    6 Settings Parameters The parameters are set at the factory as follows: Parameter Unit Setting range Factory Your setting setting 0 or 1 hrs:mins 0:01 to 4:00 01:00 0:00 to 99:90 0.90 hrs:mins 0:01 to 4:00 01:00 0:00 to 99:90 0.90 00:10 to 01:00...
  • Page 20 6 Settings Parameter Unit Setting range Factory Your setting setting 0:0 to 1:0 00:00 to 05:00 05:00 mins:secs 0 or 1 0:00 to 99:90 0.10 0:00 to 99:90 0.20 0:00 to 99:90 0.50 0:00 to 99:90 1.00 0:00 to 99:90 2.00 0:00 to 99:90 0.00...

  • Page 21: Key To Parameters

    6 Settings Key to parameters Model 245 and model 246 (appliance 1) Parameter Function Description Operating For setting the operating mode to time- mode for dependent (0) or consumption-dependent (1) appliance 1 operation Unit for time- Unit of time for appliance 1 “time-dependent” dependent operating mode.
  • Page 22 6 Settings Shut-off delay Depending on the washing machine or tumble time for appli- dryer connected, there are pauses during a ance 1 programme sequence (gaps in the power being drawn). As soon as there is a gap that is greater than the set shut-off delay time (end of programme), debiting stops.
  • Page 23 6 Settings Model 246 (appliance 2) Parameter Function Description Operating mode for For setting the operating mode to time- appliance 2 dependent (0) or consumption-dependent (1) operation Unit for time- Unit of time for appliance 1 “time- dependent operation dependent” operating mode. Defines the for appliance 2 length of time (e.g.
  • Page 24 6 Settings Shut-off delay time Depending on the washing machine or tumble dryer connected, there are pauses appliance 2 during a programme sequence (gaps in the power being drawn). As soon as there is a gap that is greater than the set shut- off delay time (end of programme), debiting stops.
  • Page 25 6 Settings General parameters Param- Function Description eter Coin / token For setting CHF / EUR (0) or tokens (1) operation Value CHF 0.10 Defines the value of 0.10 CHF 0.10 = 10 rappen Value CHF 0.20 Defines the value of 0.20 CHF 0.20 = 20 rappen Value CHF 0.50 Defines the value of 0.50 CHF 0.50 = 50...
  • Page 26 6 Settings If the value of the parameters 51 to 60 is set at 0.00, the corre- sponding coin/token will not be accepted.

  • Page 27: Technical Data

    Technical data Dimensions Model 245 Model 246 Width: 17 cm 17 cm Height: 32 cm 32 cm Depth: 17 cm 17 cm Weight: 4.8 kg 5 kg Electrical connections Model 245 Model 246 Switching capacity: 400 V 3N~ max. 16 A 2 ×...
  • Page 28 Notes...
  • Page 29 Appliance description ....10 Notes ..........28 Appliance design ......11 Packaging ...........9 Calculation ........15 Parameters ........19 Customer Services ......31 Product family ........2 Deleting credit ......... 14 Queries ..........31 Dimensions ........27 Disconnection ........9 Disposal ..........9 Recommendations for use ...10 Repair service .........

  • Page 30: Index

    Index Technical data ......... 27 Validity ..........2 Totaliser ..........14 Model 245 .........14 Model 246 .........14 Your appliance ........ 10 Type .............2...

  • Page 31: Repair Service

    FN _______________________ Appliance _______________________ Please have these details to hand when contacting V-ZUG in connection with a malfunction. You will find them on the identification plate of your appliance. The identification plate is on the underside of the appliance.
  • Page 32 Please read the safety precautions in the operating instructions! V-ZUG LTD Industriestrasse 66, 6301 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850 J245.13-3...
