Summary of Contents for Sleep 8 ErgoBed 633
- Page 1 ErgoBed 633 Good sleep changes everything OWNER’S MANUAL Actual product appearance and functionality may vary from photographs, illustrations and descriptions included in this manual.
-
Page 2: Table Of Contents
Table of Contents Safety Precautions and Usage Statements Parts List Base and Remote Overview Quick Reference Guide Installation Guide Remote Control Remote Control Pairing Bluetooth App Guide Power Down Box Syncing Two Bases (Optional) Connecting Strap (Optional) Troubleshooting MANUALS EN PT ES LV EL ET RO FR HE DE... -
Page 3: Safety Precautions And Usage Statements
Safety Precautions and Usage Statements Attention: Important Safety Disclaimers Read all instructions before using your adjustable base. Save these instructions. TO REDUCE THE RISK OF SHOCK, BURNS, FIRE OR INJURY: For optimal safety and operation, plug bed base into a surge protector (not included). The bed base should only be plugged directly into a wall outlet or surge protector (strongly recommended). - Page 4 IN-HOME USE AND HOSPITAL STANDARDS: Ergomotion adjustable bed bases are designed solely for in-home use. This base was not designed as a hospital bed and is not designed to meet hospital standards. Do not use this base with TENT TYPE oxygen therapy equipment or near explosive gases. ADDITIONAL SAFETY FEATURES Casters (optional leg accessory) are equipped with locking wheels to prevent unwanted movement.
- Page 5 of the user, the feeling of vibrations will differ. We encourage the user to find the massage intensity setting that suits them best. It is important to understand the physics of vibrations. Just as an engine may run rough during idle, as the RPMs increase, the vibrations change concurrently.
- Page 6 changes. Some of the materials in our adjustable bases such as the woods, metals and plastics used in the platform, frame and components are sensitive to moisture content and temperature and may make sounds in colder environments. PAIRED OPERATION: When operating a “paired” split base setup there may be a time latency up to 1.5 seconds between each bases articulation.
- Page 7 • Call Customer Service for any technical issues. Do not try to force the base down, this can damage the motors or frame. • Use mild soap and water to clean your adjustable base if staining occurs. • Keep in mind that adjustable bases are recommended to be used with adjustable friendly mattresses.
-
Page 8: Parts List
Parts List Before discarding the packing materials, ensure all the parts are accounted for. All electronics and components that need to be installed are located in boxes under the base or attached to the frame. Wireless Remote Control and AAA Batteries (3) Mattress Retainer Bar* Legs (4) Power Cord... -
Page 9: Base And Remote Overview
‡ Only included in the width of the bases ≤ 1000mm. MISC Parts (NOT INCLUDED) Base and Remote Overview Massage Motor Massage Motor Control Box Foot Motor Bluetooth Power Down Box Underbed Underbed Lighting Lighting Head Motor Massage Motor Massage Motor Underbed Lighting... -
Page 11: Quick Reference Guide
Quick Reference Guide Not to scale. For illustration purposes only. Read all instructions before beginning installation. Head Vibration Foot Vibration Power Cord Control Box Foot Massage Motor Motor Power Supply Splitter Cable Head Motor Input Cord Y-Cable Underbed Lighting Power Down Box Bluetooth If installing a split unit, see page 20. - Page 12 STEP 3 To install the legs, thread the washer over the bolt of the leg with the recessed side facing the leg, and tighten by hand. Do not over tighten. STEP 4 To sync two bases see detailed installation instructions on page 20. Locate the Power Down Box and install (2) 9 Volt Alkaline Batteries (not included).
- Page 13 STEP 6 Uncoil the Power Cord and connect to the Power Supply. Place Power Supply on the ground and extend from the base. Ensure that the Power Supply and all attached cords are directed toward the desired surge protector. STEP 7 Carefully flip the base over on to its legs.
-
Page 14: Remote Control
Remote Control Remote Control arrives paired to the adjustable base. Three (3) AAA batteries are required to operate the remote. M A S S A G E 10 MIN 20 MIN 30 MIN TIMER/ ALL OFF HEAD FOOT HEAD FOOT SAVE UP TO FAVORITE POSITION To program: Press and hold one of the buttons(... -
Page 15: Remote Control Pairing
The MASSAGE button activates head and foot massage at levels 1, 3, 6 and then turns head and foot massage off. The TIMER/ALL OFF button Starts massage at level 3. Select a 10, 20 or 30 minute massage interval. Pressing a fourth time will turn off massage. The light on the top of theremote indicates a 10, 20 or 30 minute timer setting. - Page 16 STEP 2 Remove the back cover of the remote, press and hold down the PAIR button. The PAIR button will illuminate blue and start flashing. When the PAIR button stops flashing, the illuminated light on the Power Down Box will go out. Release the PAIR button. The remote is now paired to the adjustable base.
-
Page 17: Bluetooth App Guide
Bluetooth App Guide For iOS and Android devices. Download and open the Open the menu by Select Settings “Ergomotion” remote app hitting the from the App store. button in the top left hand corner. Bluetooth® Setup Once in Settings, please select V4.0 in “Bluetooth version” item. - Page 18 BEFORE YOU BEGIN THE PAIRING PROCESS, please make sure the blue indicator light on your Bluetooth® dongle is blinking, indicating that it is discoverable. If the blue indicator light is not blinking, please unplug your base from its power source (a surge protector is recommended) for 10 seconds and plug it back in.
- Page 19 Selecting each option will prompt a pop up showing you an example of each remote style option and will give you the option to accept that style or not. STEP 2 Once you have chosen the correct remote style please select the back button “ ”...
-
Page 20: Power Down Box
Power Down Box Store the Power Down Box in a convenient location for emergency use. Two (2) 9 volt alkaline batteries are required to operate the power down feature and are NOT included. OVERVIEW For emergency use only, in case of a power outage. In the event that the base is stuck in an articulated position during a power outage, the Power Down Box will return the base to a FLAT position. -
Page 21: Syncing Two Bases (Optional)
Syncing Two Bases (Optional) A Sync Cord is included with the base. Not available on Queen, Full or Full-Long size bases. The Sync Cord connects the two control boxes to a single remote for the synchronization of two bases. STEP 1 Unplug bases from power source. -
Page 22: Connecting Strap (Optional)
PERFORMANCE NOTES If bases become mismatched, pressing the FLAT button will re-sync the mechanical positions. Control Box 2 Control Box 1 Sync Cord Power Down Power Down Connecting Strap (Optional) If any split setup is being installed, plastic connecting straps are provided (one per base) to secure the bases together. - Page 23 STEP 2 Slide side (a) of the connecting strap onto leg bolt. Swing the strap and connect side (b) to the leg bolt. Secure the strap by shifting to the left. STEP 3 Re-tighten legs. Do not over tighten. Use the remaining strap on other end of the base. Secure the strap by shifting to the left.
-
Page 24: Troubleshooting
Troubleshooting If one or more functions on the bed base have stopped operating: • Check under the bed base to verify that the wired connections are secure and that there are no cords or bedding obstructing the movement of the base. •... - Page 25 Nationwide Customer Service Customer Service: eusupport@ergomotion.com Web: https://www.ergomotion.com https://eu.ergomotion.com/ https://eu.ergomotion.com/warranty-activation/ Manufacturer: Keeson Technology Corporation Limited.: NO.158 qiumao road, Wang Jiangjing Development Zone, JiaxingCity, Zhejiang Province, China Importer: AFT-ADVANCE FURNITURE TECHNOLOGIES, LDA RUA DO ORREIRO, 67, 3700-211, SÃO JOÃO DA MADEIRA, PORTUGAL 516942220 Produced for Sleep.8: UK: Sleep.8 Intrinsic Limited PALMERSTON HOUSE, 814 BRIGHTON ROAD, CR8 2BR PT: SLEEP8 RETAIL PT Rua Castilho 59C, 1250-190, Lisboa, Portugal...
