Summary of Contents for ASRock Industrial 1U2FH-4L Series

  • Page 2 Version 1.0 Published March 2022 Copyright©2022 ASRockRack Inc. All rights reserved. Copyright Notice: No part of this documentation may be reproduced, transcribed, transmitted, or translated in any language, in any form or by any means, except duplication of documentation by the purchaser for backup purpose, without written consent of ASRockRack Inc.
  • Page 3 Setting up the Server in a Restricted Access Location • Only skilled person can remove the chassis covers to access the inside of the system. • Access can only be gained by instructed person or by skilled person who have been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken.
  • Page 4 Contact Information If you need to contact ASRockRack or want to know more about ASRockRack, you’re welcome to visit ASRockRack’s website at www.ASRockRack.com; or you may contact your dealer for further information. ASRockRack Incorporation 6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.)

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction Shipping Box Contents Specifications Chapter 2 Server System Overview System Components Internal Features System Front Panel System Rear Panel Front Control Panel Buttons and LEDs PSU LED 3.5-inch Hard Drive Tray LEDs Chapter 3 Hardware Installation and Maintenance Server Top Cover Hard Drive Power Supply...
  • Page 6 Appendix C Block Diagram (EP2C622D16NM) Block Diagram (FH-C612NM)

  • Page 7: Chapter 1 Introduction

    1U2FH-4L Series Chapter 1 Introduction Thank you for purchasing 1U2FH-4L Series, a reliable barebone system produced under ASRockRack’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRockRack’s commitment to quality and endurance. 1. Because the hardware specifications might be updated, the content of this documentation will be subject to change without notice.

  • Page 8: Shipping Box Contents

    1.1 Shipping Box Contents Quantity Item 1U2FH-4L/C622 1U2FH-4L/C612 Series 1U2FH-4L Series Barebone (1U form factor) System Board (MB) Power Supply Unit System Fan HDD Backplane (BPB) Front Panel Board (FPB) Power Distribution Cage / Board (PDB) Power Cable, ATX 8Pin, PDB to MB, 200mm...

  • Page 9: Specifications

    1U2FH-4L Series 1.2 Specifications 1U2FH-4L Series System Form Factor 1U Rackmount 1U Rackmount Chassis Model 1U2FH-4L/C612 1U2FH-4L/C622 1U2FH-4L/C622VK Dimensions 28" x 16.9" x 17" (710 mm X 24.6" x 16.9" x 17" (625 mm X 430 mm X 43.5 mm) 430 mm X 43.5 mm)

  • Page 10: Chapter 2 Server System Overview

    Chapter 2 Server System Overview This chapter provides diagrams showing the location of important components of the server system. 2.1 System Components 1U2FH-4L/C612 Series Top Covers Riser Card Assembly 2 x Power Supply Units Server Board 5 x System Fans 2 x 2.5”...
  • Page 11 1U2FH-4L Series 1U2FH-4L/C622 Series Riser Card Assembly Top Cover 2 x Power Supply Units Server Board 6 x System Fans Front Controls and Indicators 4 x 3.5” HDD Carriers 3 x 2.5” HDD Carriers 1U2FH-4L/C622: 2 x 2.5” HDD 1U2FH-4L/C622VK: N/A...

  • Page 12: Internal Features

    2.2 Internal Features 1U2FH-4L/C612...
  • Page 13 1U2FH-4L Series Item Server Board (SB) Riser Card Assembly PCIE Add-on Card 1 (on the riser card assembly)* or Storage Mezzanine Card (on the server board) Top: PCIE Add-on Card 2 (on the riser card assembly)* Bottom: LAN Mezzanine Card (on the server board)**...
  • Page 14 1U2FH-4L/C622...
  • Page 15 1U2FH-4L Series Item Server Board (SB) Riser Card Assembly PCIE Add-on Card 1 (on the riser card assembly)* or Storage Mezzanine Card (on the server board) Top: PCIE Add-on Card 2 (on the riser card assembly)* Bottom: LAN Mezzanine Card (on the server board)**...

  • Page 16: System Front Panel

    2.3 System Front Panel 1U2FH-4L/C612 HDD0 HDD1 HDD2 HDD3 Description 4 x 3.5" Hot-Swap HDD Trays (HDD0~HDD3) 2 x USB 2.0 Ports Control Panel Buttons and LEDs VGA Port 1U2FH-4L/C622 HDD0 HDD1 HDD2 HDD3 Description 4 x 3.5" Hot-Swap HDD Trays (HDD0~HDD3) 2 x USB 2.0 Ports Control Panel Buttons and LEDs...

  • Page 17: System Rear Panel

    1U2FH-4L Series 2.4 System Rear Panel 1U2FH-4L/C612 Redundant PSU 1+1: Only one PSU is allowed to be removed while the server is running. Description 2 x Power Supply Units (Redundant PSU 1+1) *Server requires 1 working PSU, with 1 redundant PSU. You must have at least one active supply, installed, functioning and connected to AC.
  • Page 18 1 x PCI Express Slot 1 (on the riser card assembly) *Supports Low profile and FHHL (Full High Half Length) PCIe cards 1 x LAN Mezzanine Card Slot *Support for 1GbE x 2, 10GbE x2 or SFP+ (Fiber) x2 1 x PCI Express Slot 2 (on the riser card assembly) *Supports Low profile and FHHL (Full High Half Length) PCIe cards Rear Vent* *The locations of I/O shield and rear vent may vary depending on the system and server board models.

  • Page 19: Front Control Panel Buttons And Leds

    1U2FH-4L Series 2.5 Front Control Panel Buttons and LEDs 1U2FH-4L/C612 USB1 USB2 Description USB 2.0 Port (USB1) USB 2.0 Port (USB2) Power Button and LED UID Button and LED* System Status LED* HDD Activity LED* LAN1, LAN2 Activity LED* *Please be noted that the functions are supported depending on the type of the motherboard.
  • Page 20 Power Button Press the power switch button to toggle the system power on and standby/sleep modes. To remove all power from the system completely, disconnect the power cord from the server. NMI (Nonmaskable Interrupt) Button (for 1U2FH-4L/C622 only) Press the NMI button with a paper clip or pin to generate a nonmaskable interrupt and to put the server in a halt state for examination.

  • Page 21: Psu Led

    1U2FH-4L Series 2.6 PSU LED Power LED PSU Status LED Status Description Green Normal work; output ON and OK Amber Module fault/protection in operating mode (failure, OCP, OVP, Fan Fail, OTP, UVP) AC cord unplugged 2.7 3.5-inch Hard Drive Tray LEDs...
  • Page 22 HDD Activity LED Status Description Solid Green HDD active Blinking Green HDD accessing or reading HDD failed HDD powered-off...

  • Page 23: Chapter 3 Hardware Installation And Maintenance

    1U2FH-4L Series Chapter 3 Hardware Installation and Maintenance This chapter helps you assemble the chassis and install components. Before You Begin Before you work with the server, pay close attention to the “Important Safety Instructions” at the beginning of this manual.

  • Page 24: Server Top Cover

    3.1 Server Top Cover 1U2FH-4L/C612 Removing the Server Top Covers 1. Before removing the top cover, power off the server and unplug the power cord. 2. The system must be operated with the chassis top cover installed to ensure proper cooling. 1.
  • Page 25 1U2FH-4L Series 3. When the top rear cover has been removed, you can also remove the top front cover by pushing the top front cover toward the rear side. Installing the Server Top Cover 4. Lower the top front cover on the chassis, making sure the side latches align with the...
  • Page 26 5. Lower the top rear cover on the chassis, making sure the side latches align with the cutouts. Slide the top rear cover toward the front. 6. Secure the both covers with the screws.
  • Page 27 1U2FH-4L Series 1U2FH-4L/C622 Series Removing the Server Top Cover 1. Before removing the top cover, power off the server and unplug the power cord. 2. The system must be operated with the chassis top cover installed to ensure proper cooling.
  • Page 28 Installing the Server Top Cover 1. Lower the top cover on the chassis, making sure the side latches align with the cutouts. Slide the top cover toward the front. 2. Secure the cover with a screw.

  • Page 29: Hard Drive

    1U2FH-4L Series 3.2 Hard Drive 3.2.1 Installing a Hard Disk Drive into 3.5" Hard Drive Tray The system supports hot-swappable 3.5" hard drives. Removing 3.5” Hard Drive Trays from the Chassis 1. Press the locking lever latch on the drive tray to unlock the retention lever.
  • Page 30 Installing a 3.5” Hard Drive to the Hard Drive Tray 1U2FH-4L/C612 1. Place a 3.5" HDD into the tray with the printed circuit board side facing down. Carefully align the mounting holes in the hard drive and the tray. 2. Secure the hard drive using four screws. 3.
  • Page 31 1U2FH-4L Series 1U2FH-4L/C622 Series 1. Engage two embossed pins into the side dimples on the tray. 2. Carefully push down the other side of the tray until the other two embossed pins and side dimples lock into place. 3. Slide the drive tray into the HDD bay until the drive is fully seated.
  • Page 32 3.2.2 Installing a Hard Disk Drive into 2.5" Hard Drive Carrier The system supports 2.5" hard drives (7mm). 1U2FH-4L/C612: Removing 2.5” Hard Drive Carriers from the Chassis 1. Remove the screw that secures the hard drive carrier.
  • Page 33 1U2FH-4L Series Installing a 2.5” Hard Drive to the Hard Drive Carrier 1. Place the 2.5" HDD into the carrier with the label facing up and the connector end toward the rear of the carrier where the mounting hole is located.
  • Page 34 1U2FH-4L/C622 Series Removing a 2.5” Hard Drive Carrier from the Chassis 1. Hand-release the thumbscrew that secures the hard drive carrier to the chassis. 2. Push the carrier toward the rear of the chassis to remove it from the locked position. Then remove the hard drive carrier.
  • Page 35 1U2FH-4L Series Installing a 2.5” Hard Drive to the Hard Drive Carrier 1. Engage two embossed pins into the side dimples on the carrier. 2. Carefully push down the other side of the tray until the other two embossed pins and side dimples lock into place.

  • Page 36: Power Supply

    3.3 Power Supply The system can accommodate two AC or two DC power supplies in the bay at the rear of the chassis. Each unit provides up to 650 Watts (1U2FH-4L/C612) or 750 Watts (1U2FH- 4L/C622 Series) of power. Only a single power supply is required for operation, with the second power supply purely as a redundant, load-sharing backup.
  • Page 37 1U2FH-4L Series Removing the Power Supply Unit To remove a failed power supply, please first identify the failed power supply . 1. Hold onto the power supply handle while pressing the locking lever towards the power supply handle. 2. Pull to remove the power supply from the chassis.

  • Page 38: Add-On Card

    3.4 Add-On Card 1. You can install up to two PCIE Add-on Cards to the chassis when they are installed on the provided riser card assembly. 2. Please be noted that you can install either a PCIE Add-on Card or a mezzanine card at one time only.
  • Page 39 1U2FH-4L Series 3. Remove the screw securing the filler plate. 4. Push to release the the filler plate from the assembly. 5. Slide the filler plate out sideways. 6. Install an Add-on Card into the retainer plate and into the connector on the riser card assembly.
  • Page 40 8. Place the assembly back into the chassis and secure it with screws.

  • Page 41: Lan Mezzanine Card

    1U2FH-4L Series 3.5 LAN Mezzanine Card Note: The mazzanine card slot is located under the add-on card slot. If there is an add-on card assembly installed, you need to remove it before starting to intall a mezzanine card. 1U2FH-4L/C612 Removing the Blanking Plate for a LAN Mezzanine Card If you need to remove the blanking plate, please remove the screws that secure the blanking plate on the chassis.
  • Page 42 Installing a LAN Mezzanine Card You can use an optional Ethernet mezzanine card for additional LAN ports. Please be aware that the mezzanine card must be used in conjunction with a matching I/O module. For M540R mezzanine card, you need to install the RJ-45 plug release module instead of a regular I/O module. 1.
  • Page 43 1U2FH-4L Series 4. Tighten the screws to secure the matching I/O module to the chassis. Install the RJ-45 plug release module instead for the M540 mezzanine card. RJ-45 Plug Release Module 5. If you use the RJ-45 plug release module, simply press it to release plugs.
  • Page 44 1U2FH-4L/C622 Removing the Blanking Plate for a LAN Mezzanine Card 1. Remove the screw that secures the blanking plate on the chassis. Keep the screw for later use. 2. Slide the blanking plate out sideways.
  • Page 45 1U2FH-4L Series Installing a LAN Mezzanine Card You can use an optional Ethernet mezzanine card for additional LAN ports. Please be aware that the mezzanine card must be used in conjunction with a matching I/O bracket. 1. Install the four Plastic Spacers into the motherboard around the mezzanine card slot.
  • Page 46 3. Insert and slide the I/O bracket into the slot/ 4. Tighten the screw to secure the matching I/O bracket to the chassis. I/O Bracket Simply squeeze the top of each spacer support to release the mezzanine card.

  • Page 47: System Fan

    1U2FH-4L Series 3.6 System Fan Replacing the System Fan 1. Unplug the fan connecter and remove the failed fan. 2. Align the mounting holes on the fan bar with the fan mounts on the replacement fan. 3. Gently place the fan on the fan bar. Make sure the fan is well seated.

  • Page 48: Installing The Cpu (Lga 3647 Socket)

    Appendix A Installing the CPU (LGA 3647 Socket) 1. Before you insert the CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 49 1U2FH-4L Series 1. Before you installed the heatsink, you need to spray thermal interface material between the CPU and the heatsink to improve heat dissipation. 2. Illustration in this documentation are examples only. Heatsink or fan cooler type may differ.
  • Page 51 1U2FH-4L Series Tighten the two Corner Plunger to 12 IN.LB. Two turns at a time. Tighten the two Middle Nuts to 12 IN.LB. Two turns at a time.

  • Page 52: Installing The Cpu (Lga 2011 R3 Socket)

    Installing the CPU (LGA 2011 R3 Socket) 1. Before you insert the 2011-3-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 53 1U2FH-4L Series...
  • Page 54 The cover must be placed if returning the motherboard for after service.
  • Page 55 1U2FH-4L Series Installing the CPU Fan and Heatsink Before you installed the heatsink, you need to spray thermal interface material between the CPU and the heatsink to improve heat dissipation.

  • Page 56: Installation Of Memory Modules (Dimm)

    Appendix B Installation of Memory Modules (DIMM)
  • Page 57 1U2FH-4L Series Appendix C Block Diagram (EP2C622D16NM)
  • Page 58 Block Diagram (FH-C612NM)
