Summary of Contents for VivoLink HDBaseT VL120016
- Page 1 User Manual VL120016 HDBaseT Extender...
- Page 2 This manual is only for operation instruction only, not for any maintenance usage. Trademarks Product model, VivoLink are trademarks of EET Europarts A/S. Any other trademarks mentioned in this manual are acknowledged as the properties of the trademark owner. No part of this publication may be copied or reproduced without the prior written consent of EET Europarts A/S.
- Page 3 HDBaseT Extender SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
-
Page 4: Table Of Contents
HDBaseT Extender Table of Contents 1. Introduction ......................... 1 1.1 Introduction to VL120016................... 1 1.2 Features ......................1 1.3 Package Contents ..................... 1 2. Panel Description ......................2 2.1 VL120016T ......................2 2.2 VL120016R ......................3 3. System Connection ..................... 5 3.1 Usage Precautions .................... -
Page 5: Introduction
HDBaseT Extender 1. Introduction 1.1 Introduction to VL120016 VL120016 is a mini-size extender set consists of transmitter (VL120016T) and receiver (VL120016R). HDBaseT technology is used to transmit high-resolution 1080p/ 4k signal from transmitter to the receiver via a CAT5e/CAT6a cable at a distance of up to 70/40m.Moreover, VL120016 support CEC, bi-directional RS232&IR control, and one- directional PoH function (Tx to Rx). -
Page 6: Panel Description
HDBaseT Extender 2. Panel Description 2.1 VL120016T LINK HDCP RS232 Name Description HDBT Link status indicator: OFF: No Link ① LINK GREEN:Link Successful Blinking GREEN: Link abnormal HDCP compliant indicator OFF: No HDMI traffic (no picture) ②... -
Page 7: Vl120016R
HDBaseT Extender ⑨ DC 24V Connect with power supply Pictures shown in this manual are only for reference. 2.2 VL120016R LINK HDCP RS232 Name Description HDBT Link status indicator: OFF: No Link ① LINK GREEN:Link Successful Blinking GREEN: Link abnormal HDCP compliant indicator ... - Page 8 HDBaseT Extender Connect to the HDBT OUT socket on the VL120016T via CAT5e/ ⑧ HDBT IN CAT6a cable. Connect with power supply (Not necessary if VL120016T connects ⑨ DC 24V with power). Pictures shown in this manual are only for reference.
-
Page 9: System Connection
HDBaseT Extender 3. System Connection 3.1 Usage Precautions 1) System should be installed in a clean environment and has a prop temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated and safety. 3) All devices should be connected before power on. -
Page 10: Application
HDBaseT Extender Step5. Connect the RS232 port of the devices to be controlled and VL120016R or VL120016T. Step6. Connect with DC24V power adaptor(s) (One is enough if VL120016T is connected with adapter as its PoH function). 3.4 Application VL120016 has a good application in various occasions, such as computer realm, monitoring, big screen displaying, meeting room, education and bank &... -
Page 11: Specification
HDBaseT Extender 4. Specification Model VL120016T VL120016R Spec Input Input Signal 1 HDMI,1 IR & 1 RS232 1 IR, 1 RJ-45 & 1 RS232 HDMI female, 3.5mm mini 3.5mm mini jack, RJ-45, 3p Input Connector jack, 3p captive screw captive screw connector connector Digital audio, transmit Digital audio, transmit... -
Page 12: Supported Resolution
HDBaseT Extender 4.1 Supported Resolution Aspect Ratio Resolution Refresh Rate 4096x2160 30Hz 4Kx 2K 3840x2160 24/25/30Hz 1920x1080 60Hz 1600x900 60Hz 16:9 1366x768 60Hz 1280x720 60Hz 1024x576 60Hz 1920x1200 60Hz 1680x1050 60Hz 16:10 1360x768 60Hz 1280x800 60Hz 1600x1200 60/65/70/75/85Hz 1280x1024 60/75/85/96Hz 1024x768 60/70/75/85Hz 800x600... -
Page 13: Panel Drawing
HDBaseT Extender 5. Panel Drawing 115 mm R 232 5-1 VL120016T HDBT IN 115 mm R 232 5-2 VL120016R... -
Page 14: Troubleshooting & Maintenance
HDBaseT Extender 6. Troubleshooting & Maintenance No image on display: Ensure that the display device has been set to the correct input. Ensure that the HDMI cables used for both the source/transmitter and the receiver/display are properly connected and are working. Test the HDMI cables directly from a source to display and ensure their operation. -
Page 15: After-Sales Service
HDBaseT Extender 7. After-sales Service If there appear some problems when running the device, please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: We warrants that its products will be free from defects in materials and workmanship for three years, which starts from the first day the product leaves warehouse (check the SN mark on the product).
