- Page 1 User Manual VLHDMIEXTFIB HDMI 2.0 Fiber Optical Extender All Rights Reserved Version: VLHDMIEXTFIB_2022V1.0...
- Page 2 HDMI 2.0 Fiber Optical Extender Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 HDMI 2.0 Fiber Optical Extender SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ⚫...
- Page 4 HDMI 2.0 Fiber Optical Extender Elektro- und Elektronikgeräte Informationen für private Haushalte Das Elektro- und Elektronikgerätegesetz (ElektroG) enthält eine Vielzahl von Anforderungen an den Umgang mit Elektro- und Elektronikgeräten. Die wichtigsten sind hier zusammengestellt. 1. Getrennte Erfassung von Altgeräten Elektro- und Elektronikgeräte, die zu Abfall geworden sind, werden als Altgeräte bezeichnet.
- Page 5 HDMI 2.0 Fiber Optical Extender gewährleisten. Die Möglichkeit der unentgeltlichen Rückgabe eines Altgerä tes besteht bei rü cknahmepflichtigen Vertreibern unter anderem dann, wenn ein neues gleichartiges Gerät, das im Wesentlichen die gleichen Funktionen erfü llt, an einen Endnutzer abgegeben wird. Wenn ein neues Gerät an einen privaten Haushalt ausgeliefert wird, kann das gleichartige Altgerät auch dort zur unentgeltlichen Abholung übergeben werden;...
-
Page 6: Table Of Contents
HDMI 2.0 Fiber Optical Extender Table of Contents 1. Product Introduction ........................... 1 2. Features ................................1 3. Package List ..............................1 4. Specification ..............................2 5. Panel Description ............................3 5.1 Transmitter ............................3 5.2 Receiver ............................... 4 6. System Connection ............................ -
Page 7: Product Introduction
1. Product Introduction Thanks for choosing the HDMI 2.0 Fiber Optical Extender which is designed to extend 4K@60HZ 4:4:4 12 bits HDCP encrypted HDMI signal up to 300m via single-mode or multi-mode(OM3/OM4) fiber or non-HDCP encrypted signal up to 2km via single-mode fiber. -
Page 8: Specification
4. Specification Transmitter Input (1) HDMI IN Input Connector (1) Type-A female HDMI Output (2) OPTICAL OUT; (1) AUDIO OUT Output Connector (2) LC connector; (1) Toslink connector Control (1) IR IN; (1) IR OUT; (1) RS232 Control Connector (2) 3.5mm mini jacks; (1) 3-pin terminal block Receiver Input (2) OPTICAL IN;... -
Page 9: Panel Description
5. Panel Description 5.1 Transmitter Name Description ① Power LED Turns red when DC power present. Turns green when the transmitter and receiver link ② Link status LED successful. Turns green when the signal data is transmitted between ③ Work status LED transmitter and receiver. -
Page 10: Receiver
5.2 Receiver Name Description ① Power LED Turns red when DC power present. Turns green when the transmitter and receiver link ② Link status LED successful. Turns green when the signal data is transmitted between ③ Work status LED transmitter and receiver. ▪... -
Page 11: System Connection
6. System Connection Usage Precautions: Make sure all components and accessories included before installation. ⚫ System should be installed in a clean environment with proper temperature and ⚫ humidity. All of the power switches, plugs, sockets, and power cords should be insulated and ⚫... - Page 12 Mode ①: Transmitter: ARC; Receiver: ARC The audio signal is transmitted from the display back to HDMI IN and AUDIO OUT ports. 300m HDMI: Audio: Optical: Control: Transmitter : ARC Receiver: ARC TV Remote Speaker IR Emitter APMLIFIER Blu-Ray DVD Speaker TV Remote Display...
- Page 13 Mode ②: Transmitter: ARC; Receiver: AUDIO The audio signal is transmitted from the AUDIO IN to HDMI IN and AUDIO OUT ports. 300m HDMI: Audio: Optical: Control: Transmitter: ARC Receiver:AUDIO TV Remote Speaker Speaker Blu-Ray DVD APMLIFIER TV Remote Display Digital Radio IR Emitter Mode ③: Transmitter: AUDIO;...
- Page 14 Mode ④:Transmitter: AUDIO; Receiver: AUDIO The audio signal is transmitted from the AUDIO IN to the AUDIO OUT port. 300m HDMI: Audio: Optical: Control: Transmitter: AUDIO Receiver: AUDIO TV Remote Blu-Ray DVD Digital Radio Speaker TV Remote Display IR Emitter...
-
Page 15: Troubleshooting & Maintenance
7. Troubleshooting & Maintenance Problems Potential Causes Solutions Color losing or vague/ Poor quality of the optical Change for qualified OM3 double image in HDMI fiber cable. cable. display. Not been powered. Power up the unit. Power led is off, No Make sure power adapter is response for operations Poor contact. -
Page 16: Customer Service
8. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years. 2) Scope These terms and conditions of Customer Service apply to the customer service provided for the products or any other items sold by authorized distributor only.
