QOLSYS IQ PANEL 2 PLUS Quick Manual

IQ PANEL 2 PLUS QUICK GUIDE
1a WALL MOUNT
Press the buttons on the
bottom to release the back
plate from the panel face
OPTIONAL MOUNTING: TABLE STAND (INCLUDED IN BOX)
1b
Remove the back plate
2
Connect power supply
WARNING! Use 5.5vDC - 7vDC Power
Supply ONLY
ACCESS ADVANCED SETTINGS
5
Swipe down to access settings tray
Settings Advanced
(default installer
password is 1111)
Security Signaling Residential Fire Alarm &
Security Equipment, UL Listed
Conforms to ANSI/UL Standards
Conforms to ANSI/UL Std. S985. 1023. & 1635
Certified to ULC Sub. C1023 & ULC Std. S545
Doc#: IQP2P-QG-01-19 Rev Date: 01/07/19
Qolsys Inc. proprietary. Reproduction without permission is not permitted.
1
2
Secure the back plate to the wall,
then loop the hang strap over the
strain relief hook (1) Run the
antenna through the hole (2)
Plug in the power supply (1)
and then clip the wire to the
retainer clip (2) then into the
strain relief hook (3)
3
Press and hold the power
button on the right side of
the panel for 3 seconds to
power up
6
RUN A
CELL TEST
System
7
CONNECT
WI-FI
8
CHECK FOR
UPDATES
Upgrade
Software
9
INSTALL
DEVICES
Installation
Plug in the power supply
(1) and then clip the wire
to the retainer clip (2)
Replace the back cover
4
10 ADD SECURITY SENSORS
Cell Test
Tests
Security
Sensors
CHOOSE
YOUR
NETWORK
Wi-Fi
ADD Z-WAVE DEVICES
11
UPGRADE
USING
NETWORK
Check for
updates
Z-Wave
Devices
Devices
2
1
Place the panel onto the bottom of
the back plate (1) and hinge upward
and snap in place (2). Take care as
you route the antenna into the wall
Connect the table stand to
the holes on the upper back.
CREATE
MOBILE TECH
ACCOUNT
Auto Learn Tamper or Customize
Sensor trip sensor as desired*
*If pairing devices with encryption, be sure to
select "S-Line" as the "Source" of the signals
PAIR
Add Touch Customize
Device "PAIR" (both as desired
on panel and
on the device)
techsupport@qolsys.com
TRY THE
APP
Add New
Touch
"Add New"
Add New
Touch
"Add New"
(855) 476-5797
