Paxton PROXIMITY P Ins-30003-EX Quick Start Manual

18/11/2019
Ins-30003-EX PROXIMITY P series compact reader
For technical help please contact your distributor
A list of distributors can be found on our website at - http://paxton.info/508
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
Suitability
Security-sensitive doors
Mounted on metal surface
Quickstart guide
Exit button
(push to make)
+12V
Electric release
Exit
0V
0V
12V DC release current rating
must be less than 1A.
Wet environments
Readers mounted together
12V DC power
supply
+12V
P75 Screw connector option
The unit should be mounted in conjunction
with an electrical backbox to achieve the
required clearance for the connector.
If an adaptor plate (310-750) is fitted, the
mountings on the backbox can also be used.
Paxton
300 mm
between readers
0V
Indoor use only
