Ins-30153 PROXIMITY backbox reader
Technical Support
01273 811011
Technical help is available:
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
The back plate has been designed to fit the majority of UK, European and US backboxes.
The reader will operate with a wide range of tokens including Paxton, Hitag1, Hitag2, EM4100 and Mifare.
Fitting
Preparation - Install a standard electrical backbox at the required position. Run the data cable from the control unit
location and tie off inside the backbox.
Installation - Attach the back plate to the backbox with the screws provided. Wire in the cable to the connector and
clip the reader to the back plate. The reader can now be fully tested and the Net2 system commissioned.
Final fix - Once the building work, local decorating, etc. has been completed, you can add the reader cover and
secure the assembly with the screw provided and peel off the protective film.
