- Page 1 ARROW P USER MANUAL...
- Page 2 ARROW P is one of the most stable harnesses and offers exceptional comfort and ergonomics for its weight. The ARROW P joins the new generation of Niviuk harnesses, with the aim of responding to the needs of all those pilots who want to go further.
-
Page 3: User Manual
You can get more information from our website at www.niviuk.com The information in this manual is provided in order to warn you against adverse flying situations and potential dangers. Equally, we would like to remind you that it is important to carefully read all the contents of your new ARROW P manual. -
Page 4: Table Of Contents
3.3 Landing 3.4 Flying above water or landing in water 4. TYPES OF FLYING 4.1 Winch flying 4.2 Tandem 4.3 Other 5. CARE AND MAINTENANCE 5.1 Maintenance 5.2 Storage 5.3 Checks and inspections 5.4 Repairs 5.5 Niviuk Service 5.6 Product registration... -
Page 5: Overview Of The Harness
User manual 1. GENERAL CHARACTERISTICS 1.1 Overview of the harness Aerodynamic tail Carabiners Rescue handle Speedbar hole Adjustable chest strap... - Page 6 User manual 3D-modelled seat Rescue compartment Ballast pocket Foam protection...
- Page 7 User manual Adjustable shoulder straps Adjustable coverleg strap Cockpit Adjustable pod with inner side lines Speedbar...
-
Page 8: Technical Data
EN/LTF EN/LTF EN/LTF *Carabiners and speedbar included in weight Important notice: the sizes of this model are different from any other Niviuk harness. Please follow the specifications provided. Weight and height range table Weight (kg) To be tried on (it... -
Page 9: Target Group
User manual 1.3 Target group Cross-country and Hike & Fly The ARROW P has been designed for the most demanding hike & fly pilots. An ergonomic and compact harness perfectly suited for XC flights as well as vol biv adventures in the mountains. Travel long distances on foot or in the air with a lightweight, stable and comfortable harness. - Page 10 User manual Super-light An ultralight harness, from 1.67 kg, the perfect partner for hike & fly enthusiasts. Like all our P Series products, light materials have been used for its development. The pod is made of D70, a lightweight fabric with good tear resistance, and the rest is made of Lycra light for added stretch.
-
Page 11: Design Process
1.4 Design process The NIVIUK team has done extensive and meticulous work. Distinctive adjustments were made as a result of flight testing of the various prototypes. These were tested in all flight conditions. This intensive development of an innovative and modern harness has... -
Page 12: Unpacking And Assembly
User manual 2. UNPACKING AND ASSEMBLY 2.1 Assembling the harness Before your first flight we recommend making the initial adjustments of the harness using a hang frame. Position the harness and hang it from the carabiners. Sit in the harness and close it. Using the straps, adjust it to your individual preference. -
Page 13: Chest Straps
Adjust it in a hang frame before your first flight. Niviuk R+D pilots provide the following tip for getting into the pod without getting stuck: put your left leg in first, and then put your right leg in. A good tip that works for any type of pod, just... -
Page 14: Replacing The Pod
User manual 2.4 Replacing the pod The ARROW P pod can be removed with a zip for easy replacement. 2.5 Optional accessories Ballast Drink tube Camelbak Pee tube... -
Page 15: In Flight
User manual 3. IN FLIGHT 3.1 Pre-flight checks For maximum safety, check your equipment thoroughly, using the same sequence, before every flight. Check the following: There is no visible damage to the harness or carabiners that could affect the flight. All buckles, straps and zips are connected/closed. -
Page 16: Landing
User manual 3.3 Landing Before landing, slide your legs forward in the harness to assume a standing position. Never land whilst still in the seated position as this may cause a back injury. Standing up before landing is an active safety decision and is much more effective than relying on the passive system of the back protector. -
Page 17: Types Of Flying
User manual 4. TYPES OF FLYING 4.1 Winch flying The ARROW P is suitable for winch launching. The winch release is attached by means of the main carabiners on the risers, where the wing is attached. 4.2 Tandem The ARROW P is not recommended for tandem operation. 4.3 Other The ARROW P is not designed or recommended for aerobatic or acro flying. -
Page 18: Care And Maintenance
The inside of the inflatable fairing is made from Skytex 27 g and Skytex 32 g is used on the outside. PLEASE NOTE: the lightweight products in the P series are more sensitive. Therefore, NIVIUK recommends being extremely careful with the handling and care of these products. -
Page 19: Checks And Inspections
User manual 5.3 Checks and inspections In addition to daily and pre-flight checks, the ARROW P must be thoroughly inspected at every parachute repack, which is normally once a year. Additional checks should be carried out after every impact, bad launch or landing, or in case of signs of damage or wear. -
Page 20: Niviuk Service
5.5 Niviuk Service Niviuk Service is our official workshop offering a quality service, based on the care and maintenance of flight equipment. Thanks to the knowledge, technologies and procedures we have acquired over the years, we can repair any flying equipment. -
Page 21: Safety And Responsibility
The warranty does not cover misuse of the equipment. Any modification of the paraglider or its components invalidates the guarantee and its certification. If you notice any defects in your harness, please contact Niviuk immediately for a more thorough inspection. 8. SPECIFICATIONS 8.1 Harness materials... -
Page 22: Certification
You will find the certification certificates on the product page at www.niviuk.com Paragliding Harness - EN PH_407.2023 Inspection number : Niviuk Gliders Manufacturer : Arrow P M Model and size : Maximum pilot weight [kg] : Integrated container for rescue system:... - Page 23 Niviuk Paragliders C/ del Ter, 6 La Cellera del Ter - 17165 Spain info@niviuk.com niviuk.com...
