Summary of Contents for Niviuk IKUMA 3 P
- Page 1 IKUMA 3 P User manual...
- Page 2 Niviuk paraglider. Performance, lightness and durability go hand in hand with the new IKUMA 3 P. Intuitive and accessible, you can push your own limits with the ultra-light version of our high performance EN B+ wing.
- Page 3 Equally, we would like to remind you that it is important to carefully read all the contents of your new IKUMA 3 P manual. Misuse of this equipment could lead to severe or irreversible injuries to the pilot, even death. The manufacturers and dealers cannot be held responsible for misuse of the equipment.
-
Page 4: Table Of Contents
2.3 CONNECTING THE HARNESS 10.3 LINE PLAN 10.4 RISER PLAN 2.4 HARNESS TYPE 2.5 SPEED-BAR 10.5 LINE MEASUREMENTS IKUMA 3 P 20 2.5.1 SPEED SYSTEM ASSEMBLY 10.6 LINE MEASUREMENTS IKUMA 3 P 22 LOSING ALTITUDE 10.7 LINE MEASUREMENTS IKUMA 3 P 24 2.5.2 CHANGING THE RISER CORDS... -
Page 5: Characteristics
EN-B wing that will provide safety and control. The Ikuma 3 P is also the perfect partner in your hike & fly adventures. Its lightness will allow you to reach new heights. State-of-the-art ultralight materials have been used throughout the wing to achieve the perfect balance between weight and durability. -
Page 6: In-Flight Behavior
It is lightweight; even lighter in flight and easy to pilot, with outstanding has evolved a lot, with a positive and specific advancement of the The IKUMA 3 P is supplied with the IKS 1000 as standard. This is a turbulence buffering and a surprising range of speed for incredible leading edge. -
Page 7: Elements, Components
The same fabric has been used as in the rest of the range, ensuring its guaranteed lightness, strength and durability without loss of colour. The IKUMA 3 P is supplied with the IKS 1000 as standard. This is a lightweight means to connect the risers to the lines. -
Page 8: Connecting The Harness
2.4 HARNESS TYPE Released speed-bar: the A, B and C-risers are aligned. The IKUMA 3 P can be flown with virtually all current harnesses. If the harness used has an adjustable chest strap, we recommend adjusting Full speed-bar: the difference between the A - C-risers is 180 it to the distance recommended during the certification, which varies mm in all sizes. -
Page 9: Changing The Riser Cords
IKUMA 3 P. In case it is necessary to modify the brake length, loosen the knot, slide the line through the brake handle to the desired point and re-tighten the knot firmly. -
Page 10: The First Flight
For launch, a smooth and progressive inflation is recommended. The exactly the same folding procedure and with its zip closed, becomes a IKUMA 3 P is easy to inflate and does not require a great deal of much easier to carry case. -
Page 11: In Flight
If it does not, The IKUMA 3 P has an excellent profile to deal with incidents; it is very try to weight-shift towards the collapsed side. If this does not resolve... -
Page 12: Accelerated Flight
The corrective manoeuvres to use are the same as those applied in case of If, for any reason at all, the IKUMA 3 P’s brake lines become disabled an asymmetric collapse: control the turn/spin by applying tension on in flight, it will become necessary to pilot the wing gently using the the opposite brake and weight shift opposite to the turn. -
Page 13: Losing Altitude
5. LOSING ALTITUDE Knowledge of different descent techniques could become vital in A paraglider flying at its maximum rotating speed can reach –20 m/s, certain situations. The most suitable descent method will depend on or the equivalent of a 70 km/h vertical descent, and will stabilise in a the particular situation. -
Page 14: Special Methods
6. SPECIAL METHODS 6.1 TOWING The IKUMA 3 P does not experience any problem whilst being towed. Only qualified winch personnel should handle the certified equipment to carryout this operation. The wing must be inflated similarly as during a normal take off. -
Page 15: Care And Maintenance
Each length must be adapted and customised for each The IKUMA 3 P is part of our lightweight P Series. With all the lightweight wing concerned, as a result of an analysis carried out by specialised and ultralight materials we use, we ensure a good compromise between and authorised personnel. -
Page 16: Safety And Responsability
We recommend any inspection or repair is performed by a Niviuk professional in our official workshop. Any modification of the glider made in an external workshop will invalidate the guarantee of the product. Niviuk cannot be held responsible for any issues or damage resulting from modifications or repairs carried out by unqualified professionals or who are not approved by the manufacturer. -
Page 17: Annexes
10. ANNEXES 10.1 TECHNICAL SPECIFICATIONS Cells Number Flat Aspect ratio Projected Flat m² 19,8 21,8 23,8 25,8 27,8 Area Projected m² 16,87 18,58 20,28 21,99 23,69 Span Flat 10,62 11,15 11,65 12,13 12,59 Chords Maximum 2,29 2,41 2,51 2,62 2,72 Total Lines Main... -
Page 18: Materials Technical Data
10.2 MATERIALS CANOPY FABRIC CODE SUPPLIER UPPER SURFACE 2044 32 PS / D10 DOMINICO TEX CO (KOREA) BOTTOM SURFACE DOMINICO TEX CO (KOREA) PROFILES 2044 32 FM / 7000 E91 DOMINICO TEX CO (KOREA) / PORCHER SPORT (FRANCE) DIAGONALS 30 DFM / 2044 32 FM DOMINICO TEX CO (KOREA) LOOPS LKI - 12... -
Page 19: Line Plan
10.3 LINE PLAN... -
Page 20: Riser Plan
10.4 RISER PLAN... - Page 21 10.5 LINE MEASUREMENTS 10.6 LINE MEASUREMENTS IKUMA 3 P - 20 IKUMA 3 P - 22 LINES HEIGHT + RISER mm LINES HEIGHT + RISER mm 6544 6463 6544 6616 6869 6877 6782 6870 6946 7228 6507 6428 6496 6571...
-
Page 22: Line Measurements Ikuma 3 P
10.7 LINE MEASUREMENTS 10.8 LINE MEASUREMENTS IKUMA 3 P - 24 IKUMA 3 P - 26 LINES HEIGHT + RISER mm LINES HEIGHT + RISER mm 7188 7092 7191 7269 7562 7483 7384 7486 7568 7899 7149 7055 7138 7221... - Page 23 10.9 LINE MEASUREMENTS IKUMA 3 P - 28 LINES HEIGHT + RISER mm 7766 7669 7770 7855 8215 7726 7629 7714 7804 7766 7680 7584 7675 7761 7614 7691 7595 7707 7784 7633 7599 7511 7620 7699 7395 7558 7472...
-
Page 24: Line Measurements Ikuma 3 P
PG_2303.2023 and NfL 2-565-20 and NfL 2-565-20 21.03.2024 30.11.2023 Date of issue (DMY): Date of issue (DMY): Niviuk Gliders / Air Games S.L. Niviuk Gliders / Air Games S.L. Manufacturer: Manufacturer: Ikuma 3 P 20 Ikuma 3 P 22 Model:... - Page 25 PG_2305.2024 and NfL 2-565-20 and NfL 2-565-20 30.11.2023 30.11.2023 Date of issue (DMY): Date of issue (DMY): Niviuk Gliders / Air Games S.L. Niviuk Gliders / Air Games S.L. Manufacturer: Manufacturer: Ikuma 3 P 24 Ikuma 3 P 26 Model:...
-
Page 26: Line Measurements Ikuma 3 P
10.10 CERTIFICATION Classification: In accordance with standards: EN926-1:2015, EN926-2:2013+A1:2021 PG_2306.2023 and NfL 2-565-20 30.11.2023 Date of issue (DMY): Niviuk Gliders / Air Games S.L. Manufacturer: Ikuma 3 P 28 Model: SI461927 Serial number: Configuration during flight tests Paraglider Accessories 19.9... - Page 27 Niviuk Paragliders C/ Del Ter 6 - D 17165 La Cellera de Ter - Girona - Spain +34 972 422 878 | info@niviuk.com www.niviuk.com...
