- Page 1 Industrial PC PPC-A72-133-C PN: CS19108R133 Content can change at anytime, check documentation website for latest information. www.chipsee.com...
-
Page 2: Table Of Contents
Contents 1. PPC-A72-133-C 1.1. Product Overview 1.2. Ordering Options 1.2.1. Operating System 1.2.2. Optional Features 1.3. Hardware Features 1.4. Power Input 1.5. Touch Screen 1.6. Connectivity 1.6.1. DB9 Connectors 1.6.2. USB Connectors 1.6.3. LAN Connectors 1.6.4. WiFi & BT Module 1.6.5. -
Page 3: Ppc-A72-133-C
PPC-A72-133-C PPC-A72-133-C Front View Rear View Chipsee Page 3 of 15... -
Page 4: Product Overview
Side View 2 Product Overview ® The Cortex -A72/53 series PPC-A72-133-C (PN: CS19108R133) is a high-quality industrial panel PC. It features a 13.3” ten-point capacitive touch screen with a resolution of 1920 x 1080 pixels and brightness of 250 cd/m . -
Page 5: Ordering Options
It also provides a complete set of peripheral interfaces. Ordering Options Chipsee products can be customized during the ordering process. The product will be shipped with the pre-installed factory defaults if no extra requirements are specified. The... -
Page 6: Optional Features
Software Documentation section provides a detailed instruction on how to install different OSes on your own. However, bear in mind that Chipsee can’t take the responsibility of inadequate installation procedure. If you “brick” your device, please contact Chipsee Technical Support at support@chipsee.com... -
Page 7: Power Input
Power Input The PPC-A72-133-C Industrial Panel PC can be powered by a wide range of input voltages: From 15V to 36V DC. The power input connector is a 3-pin, 3.81mm terminal. The polarity and the pinout is clearly marked on the housing of the product as shown on the figure below. -
Page 8: Touch Screen
Use a high-quality Power Adapter Unit (PSU) with low EMR. You can also provide power from a battery. Make sure that the PPC-A72-133-C Power Input connector (pin 3) is properly connected to the Power System Ground to provide sufficient EMI shielding and eliminate the problem entirely. -
Page 9: Usb Connectors
PPC-A72-133-C USB Connectors RS485. If you need different RS232/RS485 configuration, contact the Chipsee Technical Support at support@chipsee.com. Figure 498: DB9 Connectors USB Connectors There are 4 x dual USB 2.0 HOST connectors onboard, as shown on the figure below. Figure 499: USB 2.0 HOST Connectors There is also 1 x USB 3.0 HOST connector and 1 x USB Type-C connector, as shown below. -
Page 10: Wifi & Bt Module
Use CAT5 or better cables to achieve full data throughput over maximum distance defined by the 1000BASE-T standard (100m). WiFi & BT Module The PPC-A72-133-C Industrial Panel PC is equipped with the popular Realtek RTL8723 WiFi/ BT module that supports BT/BLE 4.0 (with backward compatibility), as well as 802.11bgn 2.4 GHz Wireless LAN (WLAN). -
Page 11: Expansion Connector
The product does not come shipped with the 4G/LTE module by default. Expansion Connector The PPC-A72-133-C Industrial Panel PC has 1 x Expansion Connector (closed by default), as shown on the figure below. This connector has connected to isolated GPIO signals. - Page 12 PPC-A72-133-C Expansion Connector Isolated GPIO reduced schematic Expansion Connector Pinout Function Function VDD, Isolated Power Input (+5V – +24V) GND_ISO OUT1 OUT2 OUT3 OUT4 Table 114 Expansion Connector Pinout Warning Since the PCB traces of the port are connected to the processor directly, be careful not to cause electrostatic discharge or over voltage on the pins, as it may damage the processor.
-
Page 13: Tf Card Slot
PPC-A72-133-C TF Card Slot TF Card Slot The PPC-A72-133-C Industrial Panel PC features 1 x TF Card (micro SD) slot. It can address up to 32GB of memory. Figure 506: TF (micro SD) Card Slot Note The product does not come shipped with the TF Card by default. -
Page 14: Measurements And Mounting Procedure
Figure 509: Power button Measurements and Mounting Procedure The outer mechanical dimensions of PPC-A72-133-C are 327 x 199 x 37.5mm (W x L x H). The PPC-A72-133-C Industrial Panel PC can be mounted with 8 x M4 screws or 4 x M4 screws using the VESA (100x100cm or 75x75cm) and Panel mounting methods, enabling simplified installation onto any standard mounting fixture. -
Page 15: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
