- Page 1 Envoy Parking Garage Luminaire...
-
Page 2: Table Of Contents
ENVOY P A R K I N G G A R A G E L U M I N A I R E TABLE OF CONTENTS Design Considerations ...3 Innovation...4 Installation + Maintenance...5 Lamps + Egress Options ...6 Mounting Configurations ...7 Optical Versatility...9... - Page 3 P A R K I N G DESIGN + FORM Envoy is a unique presentation of form, function and performance. Uniformity, minimum foot-candles and other design criteria are accomplished through Envoy’s multitude of reflector and shielding options. Coupled with toolless access and release features throughout...
-
Page 4: Design Considerations
DESIGN CONSIDERATIONS THE MULTITUDE OF TASKS ENCOUNTERED IN A PARKING GARAGE ENVIRONMENT REQUIRE FORETHOUGHT AND PLANNING WHEN DESIGNING A NEW LIGHTING SYSTEM. [1] Adequate horizontal and vertical illumination is required for the safety and security of occupants within the structure. Direct and indirect illumination allows safe movement of pedestrian and vehicular traffic, including the ability to easily identify... -
Page 5: Innovation
INNOVATION Envoy is truly unique in form and construction. Practical and useful features abound throughout the design, culminating in an extremely versatile parking garage luminaire. By focusing on solutions that meet contractor and end user needs, Envoy overcomes the challenges of effectively and efficiently lighting parking structures. -
Page 6: Installation + Maintenance
SIMPLE, EFFICIENT AND SECURE. Envoy’s “quick mount + release” attachment mechanism is standard on all fixtures and may be used with standard 4" J-Boxes and Envoy’s multiple mounting accessories. A positive audible “click” is heard which signals the fixture is firmly secured and locked into place. -
Page 7: Lamps + Egress Options
PATH OF EGRESS. Safe movement of pedestrian and vehicular traffic is the number one priority when designing for required “path of egress” codes. Envoy offers the most comprehensive selection of path of egress options available to the market, with a board range of lamp sources and configurations to choose from. -
Page 8: Mounting Configurations
MOUNTING CONFIGURATIONS 13 1/2" [343mm] Approx. STANDARD J-BOX MOUNT [Recessed] The J-Box is recessed/cast into ceiling. Envoy is attached using the quick mount release bracket system. 8 3/8" [213mm] Adustable to 13 1/4" 13 1/8" [334mm] TRUNNION-MOUNT [TM] The trunnion mount bracket allows direct attachment to ceiling using anchors and provides a 1/2"... - Page 9 Garage fixtures are commonly mounted to pendant pipes to bring the light source closer to ground level to achieve increased light levels. Many times this is desirable due to higher ceiling heights or structural supports at the ceiling level that interfere and block light emitted from the luminaire. Envoy offers multiple pendant mount solutions.
-
Page 10: Optical Versatility
OPTICAL VERSATILITY ROUND [RD] Bright specular Alzak ® anodized aluminum main reflector and diffuse anodized aluminum upper reflector. CONCENTRATED DOWN LIGHT [CD] 360° Internal shield efficiently redirects uplight downward to offer higher illumination values on the ground where light may be needed most. Useful in areas requiring higher footcandle values such as parking garage entrances/exits or where restricted uplight is desired. - Page 11 OPTICAL SOLUTIONS FOR DIVERSE NEEDS AND ENVIRONMENTS. Envoy offers three optical distributions and a variety of light control media to optimize lighting performance and comply with local lighting ordinances. The standard Envoy system features the main reflector contributing to both horizontal and vertical illumination. The upper reflector contributes 10% uplight, reducing the visual cave effect within the parking structure.
-
Page 12: Configurations + Layouts
CONFIGURATIONS + LAYOUTS ROUND [RD] Down Reflector Light Light Inserts none Driving Direction SQUARE [SQ] Down Reflector Light Light Inserts Driving Direction RECTANGULAR [TG] Down Reflector Light Light Inserts Driving Direction RECTANGULAR [TG] Down Reflector Light Light Inserts Driving Direction Two-way Drive Lane Double Luminaire Row Two-way Drive Lane... - Page 13 LIGHT CONTROL Envoy’s numerous reflector options and light controlling shields allow flexibility in application for all garage types. All of the three [3] main distributions are available with the complete line of shield options and accessories. CONCENTRATED DOWNLIGHT [CD] Down...
- Page 14 CONFIGURATIONS + LAYOUTS SINGLE FIXTURE ROW LAYOUT [1 FIXTURE PER BAY] Bay Width=60 Foot Note: All values are maintained illumination and account for 20% ceiling and floor reflectance with flat ceilings. Contribution from subsequent fixtures mounted in line, but no contribution from adjacent bays. Lamp, electrical and surface reflection characteristics can affect accuracy and may vary.
- Page 15 DOUBLE FIXTURE ROW LAYOUT [2 FIXTURES PER BAY] Bay Width=60 Foot Note: All values are maintained illumination and account for 20% ceiling and floor reflectance with flat ceilings. Contribution from subsequent fixtures mounted in line, but no contribution from adjacent bays. Lamp, electrical and surface reflection characteristics can affect accuracy and may vary.
-
Page 16: Optical Renderings
30' Spacing Between Fixtures [East/West] 25' Spacing Between Fixtures [North/South] In applications where light trespass is a concern, Envoy’s house-side shield [HS] accessory controls spill light on the garage exterior while still maintaining illuminance criteria within the garage, including strong vertical illumination for vehicle and facial recognition. -
Page 17: Energy
Hi/Low Dimming [HL]: Available with specific HID lamps and CWA ballast circuits, this option features a PC board within Envoy that allows step dimming through low voltage wires hooked to a control module, making it ideal to harvest natural daylight along perimeters of open parking structures. -
Page 20: Specification Features
A tamper resistant option is available to prevent unauthorized access. Envoy is IP66 rated, promoting long term optical efficiency while allowing for fast efficient cleaning by power washing. All gaskets contained within Envoy are silicone material including lens gasket and housing wire grommet. - Page 21 Certifications IP66 Rated U.L. 1598 Listed 2G Vibration Tested C-UL Listed 40°C Ambient* ISO 9001 NOTES: * Varies by model. Wire Grommet Quick Mount Release Bracket System Lens Gasket Quick Mount Plate Release Lever...
-
Page 22: Other Options
In applications where vandalism is a concern, a typical solution is to mount the luminaires out of reach. Mounting at elevated heights predictably results in lower light levels. To address vandalism Envoy has inherent, robust design features and various options to help prevent damage and unauthorized access. -
Page 23: Ordering Information
CERTIFICATIONS IP66 Rated 40°C Ambient Temperature* Bronze C-UL/U.L. 1598 Listed Wet Location SHIPPING DATA 2G Vibration Tested Net Weight [21 lbs.] Volume [2.1 cu. ft.] ISO 9001 EPL ENVOY DISTRIBUTION COLOR OPTIONS + RD=Round ACCESSORIES [add as SQ=Square [See Below]... - Page 24 Ontario, California Peachtree City, Georgia Cooper Lighting and McGraw-Edison are valuable trademarks of Cooper Industries in the United States and other countries. You are not permitted to use the Cooper Trademarks without the prior written consent of Cooper Industries. Cooper Industries, Ltd.
