- Page 1 SAVE–P VSR 150/B Installation instructions Document in original language | 271399 · v1...
- Page 2 This also applies to products already ordered, as long as it does not affect the previously agreed specifications. Systemair is not liable or bound by warranty if these instructions are not adhered to during installation or service. 271399 | v1...
-
Page 3: Table Of Contents
Contents Overview ............1 General Description ........1 Warranty ..........1 Type label..........1 Important Safety Information ......1 Intended Use.........1 Admonitions .........2 Technical Data ..........2 Dimensions and Weight ......3 Duct connections........4 Installation recommendation regarding condensation ........4 3.3.1 Condensation inside of the unit .........4 3.3.2 Condensation outside of the unit .........4 Delivery, Transport, Storage.......5... -
Page 5: Overview
For the assertion of warranty claims, the products must be correctly connected and operated, and used in accordance with the data sheets. Further prerequisites are a completed maintenance plan with no gaps and a commissioning re- port. Systemair will require these in the case of a warranty claim. Type label Before calling your service representative, make a note of the specification and production number from the type label, which can be found next to the external connections and inside of the unit. -
Page 6: Admonitions
| Technical Data • The system should operate continuously, and only be stopped for maintenance/service. • Do not connect tumble dryers to the ventilation system. • Make sure that filters are mounted before starting the unit. Admonitions Danger • Make sure that the mains supply to the unit is disconnected before performing any maintenance or electrical work! •... -
Page 7: Dimensions And Weight
Technical Data | Dimensions and Weight Fig. 2 Dimensions The unit weight is 58 kg. 271399 | v1... -
Page 8: Duct Connections
| Technical Data Duct connections Symbol Description Symbol Description Symbol Description Supply air Outdoor air Cooker hood air Exhaust air Extract air Installation recommendation regarding condensation 3.3.1 Condensation inside of the unit When the unit is installed in a cold attic (close to outdoor temperature) the unit should run continuously. If the unit is in- tended to be stopped by the user manually or due to calendar function we recommend to install air tight dampers at ex- tract and supply air ducts. -
Page 9: Delivery, Transport, Storage
• Check completeness of the delivery. Verify that all ordered equipment is delivered before starting the installation. Any discrepancies from the ordered equipment must be reported to the supplier of Systemair products. Warning When opening the transport packaging, there is a risk of damage from sharp edges, nails, staples, splinters etc. -
Page 10: Prerequisites For Installation
| Prerequisites for Installation Prerequisites for Installation To ensure a proper and fail-free operation, it is important that the unit is installed according to these instructions. The unit can be installed in the following positions. Fig. 3 Possible installation positions A. -
Page 11: Wall Preparation For Mounting Bracket
Installation | Wall preparation for mounting bracket The unit should be installed in such a way that there is no vibration noise coming from the wall on which the unit is installed. Outdoor Air Intake Location Recommendation Recommended installation location for the outdoor air intake is the northern or eastern side of the building and with a distance to openings for discharge of stale ventilation air, kitchen ventilator, central vacuum system, waste water drain- age and other pollution sources like exhaust from traffic, etc. - Page 12 | Installation Make sure that the surface is flat and that it supports the weight of the unit. Perform the installation in accordance with local rules and regulations. 271399 | v1...
-
Page 13: Ventilation Duct Connection And Insulation
Installation | Follow the ventilation drawing when connecting the unit to the duct system. Ventilation Duct Connection and Insulation Important • Always cover the ventilation ducts during construction period. • Make sure there are no loose objects or impurities inside the ducts. Install the ducts, supply air diffusers and air intake grilles as shown in the ventilation drawing. -
Page 14: Installation And Configuration Of Accessories
| Electrical connections Note: The type of ventilation ducts and insulation differ for each building and climate zone. If the ventilation drawing is not provided, please contact your installer or place of purchase for recommendations. Installation and Configuration of Accessories Please follow instructions included with the accessory or consult “Service and Accessories Installation”... -
Page 15: Before Starting The System
Before Starting the System | Position Description Digital input 1 — Rotor guard sensor (only for VSR, VTR models) Digital input 2 — Freely configurable / Cooker hood (VTR 150/K unit) Analog output 2 — Freely configurable / Electrical heater controller (VTC 700 unit) Analog output 1 —... -
Page 16: Concluding Routines
| Concluding Routines Set speed of supply and extract air fans for each level. When finished, review your settings. It is possible to go back to previous menus and make modifications. Choose heating type or none. Reset filter changer timer if necessary. Finish startup wizard with OK button. -
Page 17: Eu Declaration Of Conformity
EU Declaration of Conformity | EU Declaration of Conformity Manufacturer EN 60529 Systemair UAB Degrees of protection provided by enclosures (IP Code). Linų st. 101 EN 62233 LT–20174 Ukmergė, LITHUANIA Office: +370 340 60165 Measurement methods for electromagnetic fields of... - Page 18 Systemair UAB Linų st. 101 LT–20174 Ukmergė, LITHUANIA Phone +370 340 60165 Fax +370 340 60166 www.systemair.com...
