Troubleshooting

F-Drive R12 Control Card LED Indicators
Note:
identify," it will cause all LEDs on the control card to blink in a 500 ms on, 500 ms off
pattern until you stop the Identify command.
Blue "Power" LED
Behavior Status or Error
Solid On Power is present at the control card.
Off
Triple
Blink
Slow
Blink
Green "DMX" LED
Behavior Status or Error
Solid On DMX data is present.
Slow
Blink
Triple
Blink
Yellow "Link" LED
Behavior Status or Error
Random
Blink
Triple
Blink
Off
Slow
Blink
34
If you send an Identify command to the control card to 1 for "start
Power is not present at the control card.
Firmware download is in progress. The "DMX" (green), "Link" (yellow), and
"Error" (red) LEDs and LEDs on the output cards will also triple blink.
Bootloader mode: waiting for firmware. The "Link" (yellow) LED will also
slow blink.
Invalid RDM ID. The "Link" (yellow) LED will also slow blink and the "Error"
(red) LED will fast blink.
DMX data is not present.
Firmware download is in progress. The Power (blue), Link (yellow), and
Error (red) LEDs and LEDs on the output cards will also triple blink.
Communication is active.
Firmware download is in progress. The "Power" (blue), "DMX" (green),
and "Error" (red) LEDs and LEDs on the output cards will also triple blink.
Communication is inactive.
Bootloader mode: waiting for firmware. The "Power" (blue) LED will also
slow blink.
Invalid RDM ID. The "Power" (blue) LED will also slow blink and the "Error"
(red) LED will fast blink.
