RALLY 2
electric shower
Installation and
operating
instructions
I
NSTALLERS PLEASE NOTE THESE INSTRUCTIONS
ARE TO BE LEFT WITH THE USER
The shower head and hose supplied with this product are a safety
critical part of your shower. Failure to use genuine Triton parts
may cause injury and invalidate your guarantee.
1
2181400E - December 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RALLY 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Triton RALLY 2

Summary of Contents for Triton RALLY 2

  • Page 1 ARE TO BE LEFT WITH THE USER The shower head and hose supplied with this product are a safety critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. 2181400E - December 2021...
  • Page 2 INTRODUCTION - PLEASE READ PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. ARNING: DO NOT operate shower if frozen, or suspected of being frozen.
  • Page 3 IMPORTANT - PLEASE READ THESE GENERAL GUIDANCE NOTES BEFORE PROCEEDING GENERAL 2.3 DO NOT solder pipes or fittings within 300mm of the shower unit, as heat can transfer along Isolate the electrical and water supplies before the pipework and damage components. removing the cover.
  • Page 4 The shower installation MUST be carried out by a suitably qualified person, in the sequence of this instruction book. To check the product suitability for commercial and multiple installations, please contact Triton’s specification advisory service before installation. Please see back of book for contact information.

  • Page 5: Table Of Contents

    PLEASE USE THE FOLLOWING CHECK LIST TO AID YOUR INSTALLATION Tick off as you complete SECTION SECTION Check that the water supply will satisfy requirements ..........SECTION SECTION Check that water & cable entry points of the unit meet requirements ....SECTION SECTION Check that the electric supply will satisfy requirements ...........
  • Page 6 CONTENTS Page INTRODUCTION IMPORTANT SAFETY INFORMATION & GENERAL GUIDANCE NOTES (please read) GENERAL ADVICE TO USERS - CLEANING ADVICE INSTALLATION CHECK LIST (PLEASE FOLLOW & COMPLETE) SPECIFICATIONS ...................... 7 DIMENSIONS & CABLE/WATER ENTRY POINTS ............8 ELECTRICAL REQUIREMENTS ................9 - 10 INSTALLING THE SHOWER ..............11 - 19 Siting of the shower ...................

  • Page 7: Specifications

    SECTION SECTION SPECIFICATIONS check list ELECTRICAL Nominal power - rating at 230V 8.7kW – (40A MCB rating) PLUMBING (see page 6 & 7 for water regulations) Supply Source Mains pressure cold water only Minimum running pressure and flow to the inlet 100kPa (1.0 bar) at 8 litres per minute for of the shower for full performance 8.7kW...

  • Page 8: Dimensions & Cable/Water Entry Points

    SECTION SECTION DIMENSIONS & ENTRY POINTS check list Fig.1 DIMENSIONS Fig.2 ENTRY POINTS WATER = Back = Others Left: Bottom, Back, Top & Side. Right: Bottom, Back & Side. = Back = Others CABLE Left: Bottom, Back, Top & Side. Right: Bottom, Back &...

  • Page 9: Electrical Requirements

    Fig.3 - Illustrative purposes only WARNING! W-006-A Triton Showers, THIS APPLIANCE MUST BE EARTHED Triton Road, Nuneaton, Warwickshire, CV11 4NR The installation, supply cable and circuit xxxx protection must conform with BS 7671 (IEE wiring regulations) and be sufficient for the amperage required.
  • Page 10 SECTION SECTION Continued A 45 amp double pole isolating switch with 9.3 In any event, it is essential that individual a minimum contact gap of 3mm in both site conditions are assessed by a competent poles must be incorporated in the circuit. electrician in order to determine the correct cable size and permissible circuit length.

  • Page 11: Siting Of The Shower

    SECTION SECTION Installation - SITING OF THE SHOWER check list SITING OF THE SHOWER The installation must be in accordance with Mains electric supply Water Regulations/Bylaws - see page 2 for (via double pole switch) water specifications • If it is intended to operate the shower at pressures above the maximum or below the Double minimum stated, contact Customer Service...
  • Page 12 SECTION SECTION Continued IMPORTANT: Water regulations (fig.6) WARNING • It is required that the shower head be The shower MUST NOT be ‘constrained by a fixed or sliding attachment positioned where it will be so that it can only discharge water at a point subjected to freezing conditions.

  • Page 13: Plumbing Installation

    SECTION SECTION Installation - PLUMBING INSTALLATION check list PLUMBING INSTALLATION IMPORTANT INFORMATION Plumbing to be carried out before wiring The outlet of the shower acts as • DO NOT use jointing compounds on any a vent and must not be connected pipe fittings for the installation.

  • Page 14: Electrical Installation

    SECTION SECTION check list Installation - ELECTRICAL INSTALLATION ELECTRICAL INSTALLATION NOTE: Deviations from the designated entry IMPORTANT: Switch off the electricity supply at the mains before proceeding. points will invalidate product approvals. The cable entry points are listed on page 3. •...
  • Page 15 SECTION SECTION Continued The shower cover has been designed with four Fig.9 Left hand side ‘cut out’ bottom pipe access points and the top rear of the backplate has been designed with one ‘cut out’ backplate top rear as shwon in fig.9. ‘Cut out’...
  • Page 16 SECTION SECTION Continued Fitting Procedure Fig.10 • Turn off water supply either at the mains stopvalve or the isolating stopvalve. • Temporarily connect the mains water supply to the inlet of the shower using a 15mm x Fixing hole 15mm compression fitting. •...
  • Page 17 SECTION SECTION Continued • Route the cable into the shower unit for Fig.11 connection to the terminal block (fig.11) as follows: Earth cable to terminal marked Terminal Neutral cable to terminal marked N block Live cable to terminal marked • Fig.12 shows a schematic wiring diagram. IMPORTANT: When connecting the cable fully tighten the terminal block screws and make sure that no cable insulation is trapped under the...

  • Page 18: Fitting The Cover

    SECTION SECTION check list Installation - FITTING THE COVER FITTING THE COVER Figs 13, 14, 15 and 16 show the correct control knob position when fitting the cover. • Check to ensure that the wiring is not trapped and replace the cover squarely to the backplate and guide into position so that the knobs locate correctly into the splined spindles.

  • Page 19: Commissioning Procedure

    SECTION SECTION !! IMPORTANT !! check list COMMISSIONING Fig.17 WARNING Before normal operation of the shower, it is essential the following commissioning Power selector procedure is completed correctly. to COLD COMMISSIONING PROCEDURE COLD The first operation of the shower is intended to flush out any remaining unit debris and to make sure the heater unit contains water before the elements are switched on.

  • Page 20: User Operating Instructions & Functions

    SECTION SECTION check list USER OPERATING INSTRUCTIONS OPERATING THE SHOWER (fig.19) Fig.19 Make sure the commissioning procedure has been carried out. To start the shower Power selector • Turn the power selector to either Cold, Economy or High and the water will flow. To stop the shower •...
  • Page 21 SECTION SECTION Continued and should only need altering to compensate pressure is required to enable the shower to for seasonal changes in ambient water operate at full power. In the event a low pressure temperature. condition (down to 0.7 Bar), the shower will continue to operate at a reduced power setting.

  • Page 22: Cleaning The Filter - Installers & Service Engineers Only

    CLEANING THE FILTER Instructions for installers and service engineers only INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY Instructions for installers and service engineers only CLEANING THE FILTER It is recommended that the filter is periodically cleaned in order to maintain the performance of the shower.

  • Page 23: Fault Finding/Troubleshooting

    See ‘Water too hot’ causes 2.1, 2.2 and 2.3 and cycling hot/cool at temperature limiter. their appropriate action/cures. If it continues intervals. contact Triton Customer Service. 4 Water too cool 4.1 Too much flow. 4.1.1 Reduce flow rate via temperature control.
  • Page 24 4 Water too cool 4.4 Electrical 4.4.1 Have unit checked by suitably qualified or cold. (continued) malfunction. electrician or contact Triton Customer Service. 4.5 Safety cut-out 4.5.1 Thermal safety cut-out device has operated. operated. Have the unit checked by a suitably qualified engineer or contact Customer Service.

  • Page 25: Spare Parts

    SPARE PARTS Rear of outlet Ref. Description Part No. Model Inlet filter assembly ....P22611004 Solenoid Valve ......P22610801 Stabilising Valve ......P22640800 Pressure Switch Module ....P22611003 Can & Element Assembly ..83314810 (8.7kW) Outlet Pipe and PRD ....S23511002 Terminal Block and wires ..S82201240 Thermal Cut-Out (TCO) ...22012340 Microswitch (X2) ......83314240 10.

  • Page 26: Shower Controls - Quick User Guide

    SHOWER CONTROLS - QUICK USER GUIDE To START or STOP your shower. To START the shower, turn the power To STOP the shower, knob from the OFF position to turn the power knob Cold, Economy or High. to the OFF position. Turn the main power isolator switch ON.
