Summary of Contents for Bellfires Smart Bell 65
- Page 1 Installation and maintenance manual Smart Bell 65/60 MF Serial number: Production date:...
- Page 2 Barbas Bellfires BV. This document could contain technical inaccuracies or typographical errors. Barbas Bellfires BV reserves the right to revise this document from time to time in the contents thereof.
-
Page 3: Table Of Contents
4.3.2 Put the ceramic log set on the burner bed..............22 4.3.3 Do a final check on the fireplace..................24 Maintenance..................25 Annual maintenance........................25 5.1.1 Clean the appliance......................25 5.1.2 Do a check on the appliance...................26 Maintenance procedures......................26 5.2.1 Remove the door (including glass)..................26 Smart Bell 65-60... - Page 4 Dimensions Smart Bell 65/60 with an Insert frame 15 mm............38 Dimensions Smart Bell 65/60 with an Insert frame 50 mm............39 Dimensions Smart Bell 65/60 with an Insert frame 50 mm and Convection fan......40 7.10 Dimensions of the restriction plate.....................40 Warranty Terms..................
-
Page 5: About This Document
Installation • Maintenance This document refers to the Smart Bell 65/60 MF as 'the appliance'. This document is an essential part of your appliance. Read it carefully before you do work on the appliance. Keep it in a safe place. -
Page 6: Description
Overview of a typical installation Note: This is an example of a typical installation with the convection fan set option and a wall outlet for the concentric flue, your installation can be different. Smart Bell 65-60... -
Page 7: Overview Of The Appliance
Inlet opening convection air An inlet opening in the front of the appliance which is connected to the convection casing Outlet opening convection air An outlet opening in the front of the appliance which is connected to the convection casing Smart Bell 65-60... -
Page 8: Overview Of The Burner Bed And The Pilot Light
Pilot light outer casing Protective cover for the pilot light Pilot light burner Supplies the gas for the pilot light Thermocouple Detects if the pilot light is on Ignition electrode Supplies a spark to ignite the pilot light Smart Bell 65-60... -
Page 9: Overview Of The Ceramic Log Set
Description Overview of the ceramic log set No. Ember grate No. Ember grate with pilot opening No. 'Fire glass' Dark Amber No. Embers No. Log No. Charcoal Smart Bell 65-60... - Page 10 Description No. Log No. Charcoal No. Wood chip No. Wood chip Smart Bell 65-60...
-
Page 11: Overview Of The Control Elements
Gas connection for the gas valve that is con- The connection for the rear burner gas pipe nected to the rear burner Thermocouple interrupter connection The connection for the thermocouple inter- rupter Pilot light connection The connection to the pilot light gas pipe Smart Bell 65-60... -
Page 12: Overview Of The Front Of The Gas Regulator Block
Sets the maximum gas pressure for the burn- er. The adjustment screw is factory set and sealed. Motor-knob Operates the internal main gas valve Microswitch Detects the end position of the motor-knob 8 wire cable connection Connects the 8-wire cable from the receiver Smart Bell 65-60... -
Page 13: Overview Of The Connections On The Gas Regulator Block
For the gas pipe to the front burner Nut Ø 8mm For the gas pipe to the front burner Gas supply connection Inlet for the gas supply Gas pipe front burner Supplies gas to the front of the main burner Smart Bell 65-60... -
Page 14: Overview Of The Receiver
Connection for a wifi-box (SI) Optionally, a wifi-box can be connected to the receiver to control the appliance with a smart- phone or tablet with the Bellfires app. Connection for the fan/light module (MOD- To control the light function and optionally to... -
Page 15: Overview Of The Fan/Light Module
Connection for a convection fan Powers the convection fan. Optional for this appliance Connection for the ambient lights Powers the ambient light bulbs Connection for the receiver To control the light function and optional the convection fan function Smart Bell 65-60... -
Page 16: Safety
Make sure that you do not damage the pipes. • Make sure that the compression fittings do not come loose. • Do not install the appliance against a flammable rear wall. • After installation, Make sure that the pipes and compression fittings are gas tight. Smart Bell 65-60... -
Page 17: Safety Instructions With Regard To The Environment
Dispose of ceramic heat-resistant glass as household waste. Do not dispose of ceramic heat-resistant glass in a glass recycling container. • Dispose of an obsolete appliance according to instructions of the authorities or the fitter. • Obey the local regulations. Smart Bell 65-60... -
Page 18: Installation
Remove the carrying brackets. Put a nonflammable insulation plate (B) of at least 12 mm thick between the appliance and the rear wall. Make sure that the insulation plate covers the entire area of the rear of the appliance. Smart Bell 65-60... -
Page 19: Horizontally Align The Appliance
Use a wall socket with earth connection. • The socket must be accessible at all times. Connect the plug to the wall socket. Make sure that the electrical cable does not touch the appliance, due to the high temperatures of the appliance. Smart Bell 65-60... -
Page 20: Connect The Concentric Flue System
Failure to remove the baffle plate, if there is no need to mount a restriction plate, can lead to dangerous situations! Procedure Remove the baffle plate, by unscrewing two bolts. Screw the bolts back into the ceiling of the combustion chamber, after the baffle plate has been removed. Smart Bell 65-60... -
Page 21: Build The Fireplace
Build the fireplace around the appliance. Install the grates on the inlet openings and the outlet openings. Install the frame on the appliance. Prepare the appliance for use • Do all the procedures in this section. Optional procedures are indicated with (optional). Smart Bell 65-60... -
Page 22: Do A Check On The Operation Of The Lighting
Only use the items that are supplied. Preparation Make sure that all items of the log set are there. See Put the ceramic ember grates on the lower and upper main burner, as shown below. Refer to for the numbers of the items. Smart Bell 65-60... - Page 23 Do not apply embers on the openings of the ember grates. Embers in the openings of the ember grates can cause a blockage of the openings. Put the charcoal pieces at the designated places around the burner bed. Refer to for the numbers of the items. Smart Bell 65-60...
-
Page 24: Do A Final Check On The Fireplace
The ignition must be quiet and must produce a calm flame. To start the appliance, refer to the user manual. Do a check on the main burner. The flames increase in height and change from blue/ yellow to yellow. If all flames are yellow, the appliance is ready for use. Smart Bell 65-60... -
Page 25: Maintenance
• Do all procedures in this section every year. Caution: • Use only original parts. Individual parts for replacement or accessories are available from your BELLFIRES-dealer. • Introduced modifications to the appliance are not permitted. 5.1.1 Clean the appliance Safety conditions Caution: •... -
Page 26: Do A Check On The Appliance
5.2.1 Remove the door (including glass) Turn off the gas supply to the appliance before removing the door. With the hook, pull the thin, metal spring strip on the top middle from the stud on the door. Smart Bell 65-60... -
Page 27: Install The Door (Including Glass)
Install the door (including glass) in the reverse order of the procedure 'Remove the door (including glass)' Push the safety strip first fully back into the appliance, by lifting the strip a little. Place the door and glass, and tilt it backwards. Attach the safety strip on the door. Smart Bell 65-60... -
Page 28: Remove The Frame
First remove the door (including glass). Refer to Loosen the 3 hexagonal bolts on the inside of the top frame and the 2 Hexagonal bolts at the bottom left and bottom right (A) respectively a couple of turns. Remove the frame. Smart Bell 65-60... -
Page 29: Install The Frame
• Use only the Bellfires ambient light bulb. Prepare the appliance for use. Refer to Turn on the power supply to the appliance. 4.3.1 Make sure that the ambient lighting operates correctly. Refer to Smart Bell 65-60... -
Page 30: Troubleshooting
The overpressure door is acti- Do a check on the appliance for pliance vated. problems. The lacquer of the appliance is Use an aerosol can with heat damaged resistant lacquer to repair any damage in the laquer. Smart Bell 65-60... -
Page 31: Technical Specification
Technical specification Technical specification Smart Bell 65/60 MF (MagniFire) - GB, IE, ES, IT Natural gas Butane/ Propane Name Bellfires Bellfires Model Smart Bell 65/60 MF Smart Bell 65/60 MF Country GB, IE, ES, IT GB, IE, ES, IT Product identification no... - Page 32 • User manual in the attached documents: (*) Both burners at maximum. Appliance is on temperature. (**) Both burners at maximum. Appliance is cold. (***) Both burners at minimum. Heat changing surface: Entire front of the appliance. Smart Bell 65-60...
-
Page 33: Diagram Electricity And Gas
Gas pipe rear burner Gas pipe front burner Gas supply connection Pilot light burner Pilot light pipe Piezo cable Thermocouple Thermocouple interrupter 8 wire cable 5 wire cable 2 wire cable Connecting cable 230VAC with earthed plug Convection fan (option) Smart Bell 65-60... -
Page 34: Dimensions Smart Bell 65/60 With A Built-In Frame
Technical specification Dimensions Smart Bell 65/60 with a Built-in frame Smart Bell 65-60... -
Page 35: Dimensions Smart Bell 65/60 With A Classic Frame 35 Mm
Technical specification Dimensions Smart Bell 65/60 with a Classic frame 35 mm Smart Bell 65-60... -
Page 36: Dimensions Smart Bell 65/60 With A Classic Frame 52 Mm
Technical specification Dimensions Smart Bell 65/60 with a Classic frame 52 mm Smart Bell 65-60... -
Page 37: Dimensions Smart Bell 65/60 With A Classic Frame 70 Mm
Technical specification Dimensions Smart Bell 65/60 with a Classic frame 70 mm Smart Bell 65-60... -
Page 38: Dimensions Smart Bell 65/60 With An Insert Frame 15 Mm
Technical specification Dimensions Smart Bell 65/60 with an Insert frame 15 mm Smart Bell 65-60... -
Page 39: Dimensions Smart Bell 65/60 With An Insert Frame 50 Mm
Technical specification Dimensions Smart Bell 65/60 with an Insert frame 50 mm Smart Bell 65-60... -
Page 40: Dimensions Smart Bell 65/60 With An Insert Frame 50 Mm And Convection Fan
Technical specification Dimensions Smart Bell 65/60 with an Insert frame 50 mm and Convection fan 7.10 Dimensions of the restriction plate Width of the delivered flue restriction plates in mm Concentric flue connection Ø100 - Ø150 Roof-mounted outlet Smart Bell 65-60... -
Page 41: Warranty Terms
Complaints will only be accepted if they are reported to the Bellfires dealer, together with the serial number of the Bellfires appliance which is stated on the front of the user manual. In addition, the original receipt (invoice, receipt, cash receipt) showing the date of purchase must also be submitted. - Page 42 Article 5: Warranty period This warranty will only be granted during the warranty period. The body of the Bellfires appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase. For other parts of the Bellfires appliance, a similar warranty applies from the moment of purchase for a period of one year.
-
Page 43: Eu-Declaration Of Conformity
EU-Declaration of Conformity EU-Declaration of Conformity Smart Bell 65-60... - Page 44 Your Bellfires dealer 001 - 01.02.2018 - 346275...
