  • Page 1 SuperBlade 8U Enclosures USER’S MANUAL Revision 2.0d...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Warnings Special attention should be given to the following symbols used in this manual.

  • Page 4: Table Of Contents

    Contents Contents Chapter 1 Introduction 1.1 Overview ..........................7 Design Features ........................7 1.2 Models and Features ......................8 Models ..........................8 Front View ...........................9 Rear View ..........................11 1.3 Chassis Management Module ....................12 Capabilities ........................12 Module Redundancy ......................12 1.4 Switches ..........................13 Switches Supported in each Enclosure Model ..............14 Chapter 2 Rack Installation 2.1 Overview ..........................15 2.2 Unpacking the System .......................15...
  • Page 5 Contents 3.3 Software Mode Selection ....................27 3.4 Quick Start Setup .......................27 3.5 Removing or Installing a Horizontal Divider ...............28 Chapter 4 Power and Cooling 4.1 Module Description ......................30 Power Cord ........................30 4.2 Installing a Power Supply ....................31 Removing a Power Supply ....................32 4.3 Power Supply Failure ......................32 Redundant Power Supplies ....................32 4.4 Power Management ......................33...
  • Page 6 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 7: Chapter 1 Introduction

    Efficient Power – Power supply modules are designed to operate up to 96% efficiency to limit energy consumption and heat. Safety Models The following safety models associated with the SuperBlade 8U enclosure have been certified as compliant with UL or CSA: B820-222, L820-22.

  • Page 8: Models And Features

    Chapter 1: Introduction 1.2 Models and Features The blades may be full-height (8U) with four sockets, or half-height (4U) with one or two sockets. The enclosure supports up to 20 half-height, 10 double-width, half-height, 10 full- height, or a combination. The maximum may vary depending on the CPU wattages. Models 8U Enclosure Capabilities Power...

  • Page 9: Front View

    Chapter 1: Introduction Front View Status LAN Port Indicators Console Port Figure 1-1. SBE-820C Front View, Ten Full-Height Blades with NVMe Front Features Feature Description Status Green: All blades, switch modules, CMM, power supplies, and fans are operating normally. Indicators Red: Critical warning—some components or modules are not operating normally.
  • Page 10 Chapter 1: Introduction Figure 1-2. SBE-820J2 Front View, Ten Half-Height, Double-Width Blades...

  • Page 11: Rear View

    Chapter 1: Introduction Rear View Figure 1-3. SBE-820C-822 Rear View Rear Features Feature Description Eight power supply modules with fans Three pairs of auxiliary fans High speed networking slot for IB 100G or OPA 100G switch module Chassis Management Module (CMM) Ethernet switch slots for 1G/10G/25G speed support...

  • Page 12: Chassis Management Module

    Chapter 1: Introduction 1.3 Chassis Management Module The Chassis Management Module (CMM) is a "command” module that communicates with the blade units, the power supplies and the blade switches. Used in conjunction with the Web Interface or IPMI View management software, the CMM provides administrator control over individual blade units, power supplies, cooling fans and networking switches and monitors onboard temperatures, power status, voltage levels and fan speeds.

  • Page 13: Switches

    Marvel BobCat3 Low Latency Switch MBM-XEM-100 56x 10Gbps Internal Ports; 4x 100Gbps/40Gbps (QSFP28) and 1x 1Gbps (RJ45) External Uplink Ports VLAN, STP, 802.1AX, 802.1AB, one console port SBM-25G-P10 Supermicro Pass-thru Switch *EOL See also the SuperBlade Switch Support Matrix. These modules are further described in a separate manual.

  • Page 14: Switches Supported In Each Enclosure Model

    Chapter 1: Introduction Switches Supported in each Enclosure Model Switch Modules per Enclosure Switch Module 820H 820H2 820C 820J 820J2 820L 200G Infiniband SBM-IBS-H4020 100G Infiniband SBM-IBH-E3616 100G Omni-Path SBM-OPA-C4020* 25G Ethernet SBM-25G-200 1G Ethernet MBM-GEM-001* 1G Ethernet MBM-GEM-004 10G Ethernet MBM-XEM-001* 10G Ethernet MBM-XEM-002...

  • Page 15: Chapter 2 Rack Installation

    Chapter 2: Rack Installation Chapter 2 Rack Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a rack. Caution: Electrostatic Discharge (ESD) can damage electronic components. To prevent such damage to PCBs (printed circuit boards), it is important to use a grounded wrist strap, handle all PCBs by their edges and keep them in anti-static bags when not in use.

  • Page 16: Rack Precautions

    Chapter 2: Rack Installation Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them. • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together.

  • Page 17: Circuit Overloading

    Chapter 2: Rack Installation Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.

  • Page 18: Installing The Enclosure

    Chapter 2: Rack Installation 2.4 Installing the Enclosure There are a variety of rack units on the market, which may require a slightly different assembly procedure. Also see the instructions that came with the rails. This rail set fits a rack between 28.5 and 33.7 inch depth.
  • Page 19 Chapter 2: Rack Installation Figure 2-2. Securing the Left Rail to the Rack Note: The figure is for illustrative purposes only. Always install enclosures at the bottom of the rack first. Figure 2-3. Installing the Server into the Rack...

  • Page 20: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. 3.1 Removing Power Use the following procedure to ensure that power has been removed from the system.

  • Page 21: Installing Components

    Chapter 3: Maintenance and Component Installation 3.2 Installing Components Install: • Power Supply Modules (details in Chapter 4) • Fans • • Switches or pass-thru modules • Blade servers In all cases, slide the component into the enclosure, then secure with the locking lever. Note: All module bays must be populated either with a module or a dummy module cover to maintain proper airflow.

  • Page 22: Installing A Blade Unit Into The Enclosure

    Chapter 3: Maintenance and Component Installation Installing a Blade Unit into the Enclosure See the manual for your SuperBlade server for full details on its installation and configuration. 1. Fully open the locking lever on the blade and slowly push it into its bay. 2.

  • Page 23: Installing Double-Width Blades

    Chapter 3: Maintenance and Component Installation Installing Double-Width Blades Figure 3-3. Installing Ten Half-Height, Double-Width Blades When installing double-width blades, use an orientation similar to this.

  • Page 24: Installing The Dummy Blade Adapter

    Chapter 3: Maintenance and Component Installation Installing the Dummy Blade Adapter If you have blade slots in the enclosure that are not filled by blade servers, they must be filled by dummy blades. An 8U opening can be filled by two 4U dummies using an adapter. Combining Two 4U Dummies Using an Adapter 1.
  • Page 25 Chapter 3: Maintenance and Component Installation 3. Align the second dummy slots with the adapter. 4. Push the second dummy toward the back until it clicks into place. Figure 3-5. Aligning and Attaching the Second Dummy...
  • Page 26 Chapter 3: Maintenance and Component Installation 5. Install two screws to lock the assembly together. Figure 3-6. Installing Screws...

  • Page 27: Software Mode Selection

    Chapter 3: Maintenance and Component Installation 3.3 Software Mode Selection Using the Web-based Management Utility, you can specify your SuperBlade system to use a different mode for quieter operation and lower fan speed. This is done by selecting a mode in the CMM Operation Mode section of the CMM Status screen.

  • Page 28: Removing Or Installing A Horizontal Divider

    Chapter 3: Maintenance and Component Installation 3.5 Removing or Installing a Horizontal Divider The 8U enclosure supports 4U height blades by means of horizontal midplate dividers.These dividers can be removed or added as needed. Removing the Divider All involved blades must be removed. The right-side divider is shown as an example. 1.
  • Page 29 Chapter 3: Maintenance and Component Installation 3. Grab and rotate the divider counter-clockwise. Figure 3-9. Rotating the Divider 4. Remove the divider from the enclosure. Figure 3-10. Removing the Divider To install a divider, do the reverse procedure. When rotating the divider into position (similar to Step 3), be sure to engage the divider posts into the slots on the enclosure walls, as shown in Step 2..

  • Page 30: Chapter 4 Power And Cooling

    Chapter 4: Power Supplies and Fans Chapter 4 Power and Cooling The SuperBlade enclosure integrates a power supply and a cooling fan into a single module. The fan can operate independently from the power supply, so that if the power supply fails, the fan continues to provide cooling for the system.

  • Page 31: Installing A Power Supply

    Chapter 4: Power Supplies and Fans 4.2 Installing a Power Supply To prevent compatibility issues, only use components that match the specifications or part numbers. 1. Insert the power module into the empty power bay. Be sure that the orientation is correct.

  • Page 32: Removing A Power Supply

    Redundant Power Supplies (Note that Supermicro no longer supports the BBP module) Each blade enclosure can hold multiple power supplies. Installing all possible power supplies may provide you with redundant power, depending upon the number of blades in the enclosure, the model and power level of the power supplies installed and the power load from modules in your system.

  • Page 33: Power Management

    CMM then recalculates the remaining power for additional blades. Backup Battery Power (EOL) (Note that Supermicro no longer supports BBP.) Backup battery power (BBP) modules, like all rechargeable batteries, eventually their capacity and performance decline as they age. Regular maintenance of charge and discharge cycles is recommended to maintain the effectiveness of the BBP batteries.

  • Page 34: Auxiliary Fans

    Chapter 4: Power Supplies and Fans Also, either of the blade management software utilities can increase the fan speed and maximize system cooling. Auxiliary Fans In addition to the primary fans, the enclosure includes six smaller (4cm) fans in three modules of two fans each.

  • Page 35: Power Supply Specifications

    Chapter 4: Power Supplies and Fans 4.6 Power Supply Specifications PWS-3K01A-BR Feature Description 2880W +12V, 240A, +12Vsb, 3A Total Output Power 3000W +12V, 250A, +12Vsb, 3A AC 2880W: 200–207Vac, 16–15.7A, 50–60Hz Input AC 2880W: 207.1–240Vac, 16–14.5A, 50–60Hz DC 2880W: 240Vdc, 15A (China only) Form Factor SuperBlade Dimensions...
  • Page 36 Chapter 4: Power Supplies and Fans PWS-2K21A-BR Feature Description Maximum Output 2200W Type Hot-swap Redundant Module (N+1) Dimensions (WxLxH) 106.5 x 245.3 x 84 mm 100-127Vac input: 100A 200-220Vac input: 150A Input Rated Voltage/ 220-230Vac input: 165A Current 230-240Vac Input: 174A 200-240Vac Input: 183.3A (UL/cUL Only) Rated Frequency 50-60HZ...
  • Page 37 Chapter 4: Power Supplies and Fans PWS-2K02D-BR (EOL) Feature Description Maximum Output 2000W Type Hot-swap Redundant Dimensions (WxLxH) 106.5 x 283.3 x 84 mm Input Rated Voltage/ -40 to -44Vdc: 133.3A Current -44 to -66Vdc: 166.7A Efficiency Certification 92%+ -40 to -44Vdc input: 1600W +12V Output -44 to -66Vdc input: 2000W +12Vsb DC Output...

  • Page 38: Chapter 5 Data Plane

    Chapter 5: Data Plane Chapter 5 Data Plane This chapter describes network data routing from blades through midplanes, switches and enclosures. Blade models are shown as examples. 5.1 820L Enclosure Switch Switch Figure 5-1. 820L Rear View...

  • Page 39: With Ethernet Switches

    - 002+: extra 1G data port - NIC: onboard NIC – X710 - NIC: onboard NIC – X710 8/16/2021 Better Faster Greener™ © 2020 Supermicro In the diagram, the arrow colors illustrate which NIC port connects to which switch. Port Mapping to Switch...

  • Page 40: 820J/820J2 Enclosure

    Chapter 5: Data Plane 5.2 820J/820J2 Enclosure Switch Switch CMM1 CMM2 Switch Switch Figure 5-2. 820J/820J2 Rear View...

  • Page 41: With Pass-Thru Modules

    Node 2 Node 1 - onboard NIC (PCH X722) 8/16/2021 Better Faster Greener™ © 2020 Supermicro In the diagram, the arrow colors illustrate which NIC port connects to which Pass-Thru module. Port Mapping to Switch or Pass-Thru Module NIC Port Label...

  • Page 42: With Ethernet Switches

    Chapter 5: Data Plane With Ethernet Switches Data Plane of SBI-4219P in 820J(J2) Enclosure with 4 Ethernet Switches Data Plane of SBI-4129P in 820J Enclosure with 4 Ethernet Switches 1x 1G, 4x 10G & 2x 40G 1x 1G, 4x 10G & 2x 40G 1x 1G &...

  • Page 43: Intel Blade With Ethernet Switch And Pass-Thru Module

    Chapter 5: Data Plane Intel Blade With Ethernet Switch and Pass-Thru Module Data Plane of SBI-420P in 820J(J2) Enclosure with 2 Pass-Thru Modules Data Plane of SBI-420P in 820J Enclosure w/ 2 Ethernet Switches and 2 Pass- Thru Modules 1x 1G & 6x 100G 1x 1G &...

  • Page 44: Amd Blade With Ethernet Switch And Pass-Thru Module

    Chapter 5: Data Plane AMD Blade With Ethernet Switch and Pass-Thru Module Data Plane of SBA-4119SG in 820J(J2) Enclosure with Ethernet Switch and Pass-Thru Modules Data Plane of SBA-4119SG in 820J Enclosure with Ethernet Switch Module and Pass-Thru Module 1x 1G & 4x 100G 1x 1G &...

  • Page 45: 820C Enclosure

    Chapter 5: Data Plane 5.3 820C Enclosure Switch Switch Figure 5-3. 820C Rear View...

  • Page 46: Intel Blade With Ib Switch And Ethernet Switches

    Chapter 5: Data Plane Intel Blade with IB Switch and Ethernet Switches The diagram shows data routes from the blade NICs and add-on cards to the dual Ethernet switches and the HPC Omni-Path/InfiniBand switch (OPA/IBS). Data Plane of SBI-4129P in 820C Enclosure w/ IB and Eth. Switch Module 1x 1G, 4x 10G &...

  • Page 47: 820H/820H2 Enclosure

    Chapter 5: Data Plane 5.4 820H/820H2 Enclosure Switch Switch Figure 5-4. 820H/820H2 Rear View...

  • Page 48: Intel Blade With Ib Switch And Ethernet Switch

    Node 2 Node 10 - onboard NIC - 25G NIC 9/23/2021 Better Faster Greener™ © 2020 Supermicro In the diagram, the arrow colors illustrate which NIC port connects to which module. Port Mapping to Switch NIC Port Label Arrow Color...

  • Page 49: Amd Blade With Ib Switch

    Chapter 5: Data Plane AMD Blade with IB Switch The diagram shows data routes from the blade NIC and add-on cards to the HPC Infiniband switch (IBS). Data Plane of SBA-4119SG in 820H(H2) Enclosure with IB 200G Switch Module 20 x 200G 5x 100G 5x 100G HPC Switch Module#B1...

  • Page 50: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at www.supermicro.com/about/policies/...
  • Page 51 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 52 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 53 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 54 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 55 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告 システムコンポーネントの取り付けまたは取り外しのために、...
  • Page 56 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 57 Appendix A: Warning Statements ¡Advertencia! Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo. Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 58 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 59 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 60 Appendix A: Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 61 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 62 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 63 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 64 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 65 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 66 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 67 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 68 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 69 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
  • Page 70 Appendix B: System Specifications Appendix B System Specifications Dimensions (HxWxD) 14" x 17.6" x 32" in. (356 x 447 x 813 mm) Address Defaults CMM: IP Address: https://192.168.100.100, Gateway Address: 0.0.0.0, Subnet Mask: 255.255.255.0 GbE Switch: IP Address: https://192.168.100.102, Gateway Address: 192.168.100.1, Subnet Mask: 255.255.255.0 Operating Environment Operating Temperature: 0º...
  • Page 71 Appendix B: System Specifications...
