INTEGRAL TIME
(available only with PID o PI - CntF <> onoF (group miSC of configuration))
Upper display
Lower display
Range
00.01 ↔ 20.00 mm.ss
Beyond the maximum value, the display of the integral action is excluded.
With selftune activated, the lower limit is given by Lti
DERIVATIVE TIME
(available only with PI - CntF = Pi (group miSC of configuration))
Upper display
Lower display
Range
00.01 ↔ 10.00 mm.ss
With selftune activated, the derivative time is equal to tI / 4
INTEGRAL PRELOAD
(available only with PID or PI - CntF <> onoF (group miSC of configuration))
Upper display
Lower display
Range
With O2Fn ≠ Cool
0 ↔ 100
With O2Fn = Cool
-100 ↔ 100
ti1
Actual Value
td
Actual Value
iP1
Actual Value
pag. 48 di 122
