CD Automation srl
14.7 Group DEF (default of run time Loading)
Upper display
Lower display
By pressing the key FUNC the default value are loaded
14.8 Group PAL1 (Pallet 1 control parameters)
PROPORTIONALE BAND
Upper display
Lower display
Range
No selftune with O2Fn ≠ Cool
1.0% ↔ 100.0% of span
No selftune with O2Fn = Cool
1.5% ↔ 100.0% of span
Selftune with O2Fn ≠ Cool
LPb2 ↔ HPb
Selftune with O2Fn = Cool
LPb1 ↔ HPb
HYSTERESIS
(available only with ON/OFF – CntF = onoF (group miSC of configuration))
Upper display
Lower display
Range
0.1% ↔ 10.0% of span or 1LSD
rt
on
Pb1
Actual Value
HYS1
Actual Value for ON/OFF
pag. 47 di 122
