Gazebo penguin W1209 1/2-12 SAND Assembly Instructions Manual

10 x 12 solarium
Hide thumbs Also See for W1209 1/2-12 SAND:

Advertisement

Quick Links

Download this manual
W1209 ½-12
SAND
W1209 ½-32
SLATE
10 X 12 SOLARIUM
ASSEMBLY INSTRUCTIONS
DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED
PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS
Assembly by two or three adults is suggested.
Requires 96" clearance at the wall
Base Dimensions 144''x 118''
APPROX.
Largest Dimensions 144''x122''
(see pg.21)
ZZZ-209.W1209.1221-20.GP.EN.doc
WEB VERSION
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the W1209 1/2-12 SAND and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gazebo penguin W1209 1/2-12 SAND

Summary of Contents for Gazebo penguin W1209 1/2-12 SAND

  • Page 1 W1209 ½-12 SAND W1209 ½-32 SLATE 10 X 12 SOLARIUM ASSEMBLY INSTRUCTIONS DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS Assembly by two or three adults is suggested. Requires 96”...
  • Page 2 Some jurisdictions may require permits for, or otherwise regulate, installation and use. IMPORTANT: RETAIN FOR FUTURE REFERENCE, READ CAREFULLY For assistance with assembly, installation, parts, or customer service, contact Gazebo Penguin Customer Service Department at the numbers listed below (English & French, Mon-Fri 8:00 AM to 4:00 PM EST):...
  • Page 3 Leaking due to heavy rain may happen, please refer to the instruction manual for window positions and information on how to evacuate the water. The product is only warranted in the event it is installed in accordance with the Gazebo Penguin’s written instructions enclosed with the product.

  • Page 4: Tools Required

    TOOLS REQUIRED:  Screwdriver  Knife  File (smooth)  Needle-nosed pliers  Rubber mallet  Step ladder (minmum 6' in height)  Spatula  Power drill  Tube of silicon  Drill bit 5/16" cement (according to surface) BEFORE STARTING: Ensure that you have a solid base, such as concrete or wooden deck, not slanted more than 1”...
  • Page 5 STEP #3 Assemble ML-3, N-3, O-3, and MR-3 as shown ASSEMBLE PIECES and position evenly above vertical guides, at 96’’ BEFORE SCREWING from the ground. Secure wall track and vertical THEM TO THE WALL tracks to brick or cement wall by drilling through the aluminum and using screws Xx-3.
  • Page 6 STEP #5 Set right rafter T-3 over last bracket then secure it with Bb-3 screw and continue screwing through joint K-3 with the Bb-3 screw. Secure to Q-3 bracket with self-tapping screw (PQ-3). Repeat on left side with rafter S-3. STEP #6 Set U-3 rafters over the middle of each panel with Bb-3 screws at the top and...
  • Page 7 STEP #7 Remove protective film from two (2) sides of each panel and make sure the top side of the panel faces the sunlight. Insert and slide on the top groove of the rafters all the way to the end. Pp-3 should go first and last with the Qq-3 panels in between.
  • Page 8 STEP #9 Insert the second row of panels into the lower groove on the rafter. Slide panels until they reach the aluminum pieces between the panels and gently tap on the panel to guide it into the aluminum groove. Use a spatula if needed to make it fit.
  • Page 9 STEP #11 On the inside of the solarium under each rafter there are two rows of inserts with threads, and one crossbeam in two pieces. Start the upper row with a Jj-3 at either end and Kk-3 between panels, screwing them in place with Ff- 3.
  • Page 10 STEP #13 Lift up door and track inside of solarium then set it over the door opening by screwing at the top. First use bolts (Ww) and washers (Gg-3) on the inside and female bolts (Cc-3-2) on the outside for the top assembly.

  • Page 11: Special Notes

    STEP #14 Anchor the solarium to the deck or floor securely using screws and shields supplied. See diagram below. SPECIAL NOTES To remove a screen, remove the two (2) screws at the top of the frame then pull sideways to the opposite end of the handles to remove.
  • Page 12 Suggestions The below mentioned are only suggestions in order to permit drainage, these will vary depending on your flooring – material, flatness and slope. ZZZ-209.W1209.1221-20.GP.EN.doc WEB VERSION...
  • Page 13 SOLARIUM W1209 ½ SAND (see page 17 for slate parts) PACKED PACKED DESCRIPTION DRAWING DESCRIPTION DRAWING IN BOX IN BOX 10-497 10-496 FRAME NEXT REGULAR TO DOOR FRAME (Has more holes) 10-498 12-141 SLIDING HALF FRAME DOOR A-3 1/2 10-499 11-544 SLIDING CONNECTING...
  • Page 14 PACKED PACKED DESCRIPTION DRAWING DESCRIPTION DRAWING IN BOX IN BOX 10-509 12-146 ROOF LEFT SIDE RAFTER CAP RAFTER 12-147 12-148 RIGHT SIDE REGULAR RAFTER RAFTER 10-514 10-513 MIDDLE MIDDLE ROOF JOINT ROOF JOINT 10-516 10-515 EDGING EDGING 08-156 08-158 SCREW BOLT Bb-3 12-037...
  • Page 15 PACKED PACKED DESCRIPTION DRAWING DESCRIPTION DRAWING IN BOX IN BOX 10-518 10-519 REGULAR ROOF TOP ROOF REINFORCE CROSSBAR Ll-3 Kk-3 08-134 10-520 UPPER DOOR ROOF TOP RAIL END REINFORCE Mm-3 12-149 (63 ¼ x 24 ½”) 08-135 SCREW LEFT+RIGHT Oo-3 ROOF PANEL Pp-3 12-150...

  • Page 16: Available Replacement Parts

    AVAILABLE REPLACEMENT PARTS DESCRIPTION DRAWING DESCRIPTION DRAWING 85-014 10-435-12 REPLACEMENT PVC WINDOW SCREENING (no (in frame) frame) 12-176-12 85-417-S PVC WINDOW for ROUND SPLINE FOR HALF FRAME A-3 SCREENING 10-493 11-824-12 PVC WINDOW BOTTOM PLASTIC (replacement PANEL (for wall material only) panels) 85-417-P 11-825-12...
  • Page 17 SOLARIUM W1209 ½ SLATE PACKED PACKED DESCRIPTION DRAWING DESCRIPTION DRAWING IN BOX IN BOX 10-497 10-496 FRAME NEXT REGULAR TO DOOR FRAME (Has more holes) 10-498 12-141 SLIDING HALF FRAME DOOR A-3 1/2 10-499 11-544 SLIDING CONNECTING DOOR FRAME PIECE 11-545 11-546 TOP DOOR...
  • Page 18 PACKED PACKED DESCRIPTION DRAWING DESCRIPTION DRAWING IN BOX IN BOX 10-509 12-146 ROOF LEFT SIDE RAFTER CAP RAFTER 12-147 12-148 RIGHT SIDE REGULAR RAFTER RAFTER 10-514 10-513 MIDDLE MIDDLE ROOF JOINT ROOF JOINT 10-516 10-515 EDGING EDGING 08-156 08-158 SCREW BOLT Bb-3 12-037...
  • Page 19 PACKED PACKED DESCRIPTION DRAWING DESCRIPTION DRAWING IN BOX IN BOX 10-518 10-519 REGULAR ROOF TOP ROOF REINFORCE CROSSBAR Ll-3 Kk-3 08-134 10-520 UPPER DOOR ROOF TOP RAIL END REINFORCE Mm-3 12-149 (63 ¼ x 24 ½”) 08-135 SCREW LEFT+RIGHT Oo-3 ROOF PANEL Pp-3 12-150...
  • Page 20 AVAILABLE REPLACEMENT PARTS DESCRIPTION DRAWING DESCRIPTION DRAWING 85-014 10-435-32 REPLACEMENT PVC WINDOW SCREENING (no (in frame) frame) 12-176-32 85-417-S PVC WINDOW for ROUND SPLINE FOR HALF FRAME A-3 SCREENING 10-493 11-824-32 PVC WINDOW BOTTOM PLASTIC (replacement PANEL (for wall material only) panels) 85-417-P 11-825-32...
  • Page 21 Note: The Dimensions are approximate. ZZZ-209.W1209.1221-20.GP.EN.doc WEB VERSION...
