Deck Instructions
NOTE
If you are requesting a Return Material Authorization (RMA), then disconnect the
spin button from the existing iDeck™ and save it for future use. When ordered, a
new iDeck™ does not include this spin button.
14
Push the iDeck™ up from the bottom to remove it.
Figure 95 Removing the iDeck™
15
To replace the iDeck™, complete the preceding steps in reverse.
16
Route all the cables correctly to prevent damage.
17
Secure loose cables.
© 2017 Scientific Games Corporation, All Rights Reserved. Unauthorized distribution prohibited.
TwinStar™ Upright (SG-1V43-ST) Service Manual 1489211 [B]
Chapter 8 Deck
70
