Deck Instructions
Deck Instructions
Removing the iDeck™
Use the following steps to remove the iDeck™:
1
Switch off the power before removing or installing the iDeck™.
2
Use a protective object to place over the top of the iDeck™, as shown in the following image, to protect it from
any damage.
Figure 82 Protecting the Surface of the iDeck™
3
With the main door open, grasp the top of the trim of the pillow assembly and tilt it towards yourself. The pillow
assembly has a magnetic catch.
Figure 83 Opening the Pillow Assembly
© 2017 Scientific Games Corporation, All Rights Reserved. Unauthorized distribution prohibited.
TwinStar™ Upright (SG-1V43-ST) Service Manual 1489211 [B]
Chapter 8 Deck
64
