  • Page 1 ™ U (SG-1V224ST) O PRIGHT PERATOR NSTRUCTIONS Upright Cabinet Setup 02 October 2017 SG-1V224ST [I] RIGINAL NSTRUCTIONS LL NON NGLISH EDITIONS OF THIS DOCUMENT ARE TRANSLATIONS OF THE ORIGINAL INSTRUCTIONS CONFIDENTIAL...
  • Page 2 (all of the foregoing in (a), (b) and (c), collectively, "Content"). This Document and the Content are owned or controlled by Scientific Games or its licensors or third parties, when applicable. All right, title, and interest in and to the Content is the property of Scientific Games or its licensors, when applicable, and is protected by the intellectual property laws of the United States and elsewhere to the fullest extent possible.

  • Page 3: Table Of Contents

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Contents Chapter 1: Overview Prerequisites ..................6 Additional information .
  • Page 4 Contents TwinStar™ Upright (SG-1V224ST) Operator Instructions Removing the CPU ................24 Installing the CPU .

  • Page 5: Chapter 1: Overview

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Chapter 1 Overview This document provides operating instructions for the SG-1V224ST Upright. All features described in this document may not appear on every machine. Your machine may have only features supported by your software version, jurisdiction, and machine configuration. CAUTION: KEEP ALL DOORS CLOSED UNTIL THE UNIT IS SECURED IN PLACE TO PREVENT INSTABILITY.

  • Page 6: Prerequisites

    Overview TwinStar™ Upright (SG-1V224ST) Operator Instructions Prerequisites Installation may require the following additional items: • Locks (quantity 5 to 9 depending upon your machine configuration • Category 5 network cables (quantity and length depending upon your machine configuration and your floor plan) •...

  • Page 7: Electrical Specifications

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Overview Electrical Specifications NOTE: Typical currents are provided for reference only. Actual current use will depend upon machine configuration and the addition of supplemental equipment such as systems monitoring and progressive equipment. Description Value Line Voltage 120 V AC at 60 Hz (230 VAC at 50 Hz) Surge State Current 3.4 Amps at 120 V AC (1.65 Amps at 240 V AC)

  • Page 8: Dimensions

    Overview TwinStar™ Upright (SG-1V224ST) Operator Instructions Dimensions 1958 mm 1719 mm 77.1 inches 67.7 inches 1328 mm 52.3 inches 373 mm 14.7 inches 395 mm 673 mm 15.6 inches 26.5 inches 709 mm 27.9 inches SG-1V224ST [I] Dimensions CONFIDENTIAL.

  • Page 9: Anti-Tip Stands

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Overview Anti-Tip Stands 219002 or 219300-XXXXX FINISH: 01-99 = POWDER COAT PER BALLY SPEC 200200 AA-ZZ = LAMINATE PER BALLY SPEC 200300 STAND HEIGHT STAND SERIES Part Numbers for Anti Tip Stands Part Number Description 219002-61430 Anti-Tip Stand, 14-inch High 219300-C1430...

  • Page 10: Lock And Cam Specification

    Overview TwinStar™ Upright (SG-1V224ST) Operator Instructions Lock and Cam Specification Lock Location Illustration Part Number Belly Door Cam, Secondary 258802 Bill Acceptor Chassis Cam 200454 Bill Acceptor Chassis Lock Spacer, 1/8 Inch — 205052 Bill Acceptor Drop Door Cam, Secondary 258802 Main Door Lock Cam 258801...

  • Page 11: Installing The Main Door Lock

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Overview Installing the Main Door Lock • Location: at the center of the cabinet, below the deck • Unlocking Rotation: clockwise • Cam: STEP 1. Unlock the belly door by inserting the key into the left lock and turning it to the right. STEP 2.
  • Page 12 Overview TwinStar™ Upright (SG-1V224ST) Operator Instructions STEP 4. Remove the cover from the bottom of deck by removing six screws securing the deck bottom cover plate. Two Screws on the Left Side Four Screws on the Right Side STEP 5. Unlock the main door by inserting the key into the center lock and turning it to the right to release the handle.
  • Page 13 TwinStar™ Upright (SG-1V224ST) Operator Instructions Overview STEP 8. With the main door open, open the pillow assembly by grasping the top of the trim and tilting it towards yourself. STEP 9. To access the main door lock pod assembly, remove four screws from behind the main door. Note that a symbol of a lock identifies each of the lock pod screws.
  • Page 14 Overview TwinStar™ Upright (SG-1V224ST) Operator Instructions STEP 11. Insert the provided cover plate into the main lock. Cover Plate STEP 12. Install the main lock. SG-1V224ST [I] Door and Lock Locations CONFIDENTIAL.

  • Page 15: Chapter 2: Getting Started

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Chapter 2 Getting Started Unpacking and Inspecting the Machine STEP 1. Remove any external packaging. STEP 2. Verify that the serial numbers on the cabinet match the shipping documents. STEP 3. Unpack and remove all loose parts from the cabinet such as extra cables, lock cams, and mounting hardware.

  • Page 16: Securing The Machine

    Getting Started TwinStar™ Upright (SG-1V224ST) Operator Instructions Securing the Machine STEP 1. Ensure the new location has appropriate power and network cabling installed. NOTE: Changes in floor configuration may require rerouting power and CAT-5 cables. STEP 2. Move the machine to the desired location using a lifting or moving device such as a hand truck.
  • Page 17 TwinStar™ Upright (SG-1V224ST) Operator Instructions Getting Started • Example - For multiple, freestanding, odd numbers of cabinets not positioned against a wall, install in pods. NOTE: For pod configurations, fasten adjacent stands together using the Stand Hinge Bracket with Mounting Hardware Kit (1400978-104). CAUTION: To prevent tipping, always secure the cabinet firmly to the stand using the Cabinet Stand Mounting Hardware Kit (205343).
  • Page 18 Getting Started TwinStar™ Upright (SG-1V224ST) Operator Instructions STEP 6. Connect the speaker cable and secure the speaker with two screws. Speaker Cable Two Screws SG-1V224ST [I] Securing the Machine CONFIDENTIAL.

  • Page 19: Opening And Closing Doors

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Getting Started Opening and Closing Doors Use the following instructions to ensure safe and correct operation: • Secure doors with locks installed according to instructions from your lock manufacturer. • When closing doors, always ensure the door frame areas are free from foreign objects and that the door latches securely.

  • Page 20: Accessing The Main Door

    Getting Started TwinStar™ Upright (SG-1V224ST) Operator Instructions Accessing the Main Door STEP 1. To unlock the main door, insert the key into the center lock and turn it to the right to release the handle. STEP 2. Grasp the handle from the left edge and pull it forward until the upper portion of the main door separates from the lock.

  • Page 21: Accessing The Pillow Assembly

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Getting Started Accessing the Pillow Assembly STEP 1. With the main door open, open the pillow assembly by grasping the top of the trim and tilting it towards yourself. Opening and Closing Doors SG-1V224ST [I] CONFIDENTIAL.

  • Page 22: Accessing The Upper Monitor

    Getting Started TwinStar™ Upright (SG-1V224ST) Operator Instructions Accessing the Upper Monitor STEP 1. With the main door open, access the upper monitor by pressing the latch (yellow) at the bottom of the monitor assembly. STEP 2. Grasp the top corners of the upper monitor, pull up and towards yourself, then lower the monitor into the side brackets.

  • Page 23: Accessing The Cash Box Door

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Getting Started Accessing the Cash Box Door STEP 1. To unlock the cash box access door, insert the key into the right lock, turn it to the right, and lower the door. Opening and Closing Doors SG-1V224ST [I] CONFIDENTIAL.

  • Page 24: Removing The Cpu

    Getting Started TwinStar™ Upright (SG-1V224ST) Operator Instructions Removing the CPU STEP 1. With the belly door, the main door, and the pillow assembly open, locate the CPU in the center of the EGM, insert the key, and turn it. STEP 2. From the belly door area, remove the CPU by grasping the handle at the front of the CPU and pulling it towards yourself.

  • Page 25: Installing The Cpu

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Getting Started Installing the CPU STEP 1. With the belly door, the main door, and the pillow assembly open, insert the CPU into the housing, gently push the handle at the front of the CPU towards the back of the housing until the CPU connects securely.

  • Page 26: Setting Up The Machine

    Getting Started TwinStar™ Upright (SG-1V224ST) Operator Instructions Setting up the Machine STEP 1. Use the instructions provided by your lock manufacturer to install locks in appropriate areas. (configurations may vary.) • main door • belly door • cash box door •...

  • Page 27: Connecting Emotive Lighting (If Applicable)

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Getting Started Connecting Emotive Lighting (If Applicable) Use the following instructions to connect LCU boards between games in a bank and synchronize emotive lighting features. STEP 1. Open the belly and main doors. See “Opening and Closing Doors” on page 2-19. STEP 2.
  • Page 28 Getting Started TwinStar™ Upright (SG-1V224ST) Operator Instructions This page is intentionally blank. SG-1V224ST [I] Using the Touchscreen CONFIDENTIAL.

  • Page 29: Chapter 3: Operational Tasks

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Chapter 3 Operational Tasks Attendant Pays and Canceling Credits NOTE: For more information on messages and solutions, see 1437680 Service Manual and User Guide: ArgOS. Messages similar to the following require an Attendant to release the lockup by turning a key in the Attendant key switch: •...

  • Page 30: Collecting Bills From The Machine

    Operational Tasks TwinStar™ Upright (SG-1V224ST) Operator Instructions Collecting Bills from the Machine NOTE: Bill acceptor cash box collection procedures depend upon the machine model specification, added equipment and the jurisdiction. Note that bill acceptor cash boxes may vary depending upon the manufacturer and may include a cash box release mechanism.

  • Page 31: Refilling Printer Paper

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Operational Tasks Refilling Printer Paper NOTE: Printer paper refill procedures depend upon the machine model specification, added equipment, and the jurisdiction. CAUTION: Complete your site’s procedures for accessing the machine. Obtain appropriate printer paper and ensure the printer paper matches the machine’s printer paper size and capacity.
  • Page 32 Operational Tasks TwinStar™ Upright (SG-1V224ST) Operator Instructions This page is intentionally blank. SG-1V224ST [I] Attendant Pays and Canceling Credits CONFIDENTIAL.

  • Page 33: Chapter 4: Board Reference

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Chapter 4 Board Reference CPU-4.2.2X (1458954) CPU-4.2.2X (1458954) SG-1V224ST [I] CONFIDENTIAL.

  • Page 34: Backplane Assembly (1460383)

    Board Reference TwinStar™ Upright (SG-1V224ST) Operator Instructions Backplane Assembly (1460383) SG-1V224ST [I] Backplane Assembly (1460383) CONFIDENTIAL.

  • Page 35: Backplane Board Detail View

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Board Reference Backplane Board Detail View Backplane Assembly (1460383) SG-1V224ST [I] CONFIDENTIAL.

  • Page 36: Backplane Board Connector Descriptions

    Board Reference TwinStar™ Upright (SG-1V224ST) Operator Instructions Backplane Board Connector Descriptions Backplane Board Connector Descriptions Component Typical Usage and Description Component Typical Usage and Description DC Power Distribution Spare 24V Aux Power Spare 24V Printer Arm Mech Host Interface 1 J41-J44 USB 2.0 DC Power Distribution...

  • Page 37: Backplane Cabling Block Diagram

    TwinStar™ Upright (SG-1V224ST) Operator Instructions Board Reference Backplane Cabling Block Diagram BV / PRINTER Data > J6/J11 Upper Lower Deck Data > Data > Data > Speaker Speaker PORT 4 Power Power Power Data < Lower Monitor Data > / Date < / PWR Bezel PORT 3 Lighting...

  • Page 38: Lighting Control Unit (Lcu) Board (Pca257509-0-0)

    Board Reference TwinStar™ Upright (SG-1V224ST) Operator Instructions Lighting Control Unit (LCU) Board (PCA257509-0-0) SG-1V224ST [I] Lighting Control Unit (LCU) Board (PCA257509-0-0) CONFIDENTIAL.
  • Page 39 TwinStar™ Upright (SG-1V224ST) Operator Instructions Board Reference LCU Board Components Component Typical Usage and Description Port 0 Super Candle Tower Light Port 1 Pro Topper Monitor LED devices Port 2 Top Monitor Screen LED devices Port 3 Bottom Monitor Screen LED devices Port 4 Lower Cabinet LED devices (Speaker, Deck, and Belly Door) Port 5...

  • Page 40: Lcu Board Connector Descriptions

    Board Reference TwinStar™ Upright (SG-1V224ST) Operator Instructions LCU Board Connector Descriptions LCU Board Connector Descriptions Component Typical Usage and Description Port 0 Super Candle Port 1 Topper Lighting Port 2 — Port 3 Upper Monitor Port 4 Cabinet Lighting Port 5 Halo Port 6 —...
  • Page 41 TwinStar™ Upright (SG-1V224ST) Operator Instructions Chapter 5 Spare Parts Spare Parts Part Number Item Description Quantity 1-25 Units 26-99 Units 100+ Units 257540-00001 Lower Monitor, with 24-Inch Touchscreen 257540-00002 Upper Monitor, with 24-Inch Touchscreen 257464 iDeck™ Assembly 1458954 CPU Assembly, CPU-4.2.2X A5 1460383 Backplane Assembly, 4.0 UPD 1436714...
  • Page 42 Spare Parts TwinStar™ Upright (SG-1V224ST) Operator Instructions This page is intentionally blank. SG-1V224ST [I] Spare Parts CONFIDENTIAL.
