Deck Instructions
NOTE
If you are requesting a Return Material Authorization (RMA), then disconnect the
LED control board from the existing iDeck™ and save it for future use. When
ordered, a new iDeck™ does not include this LED control board.
Figure 93 LED Control Board—Remove and Save for Future Use
13 Using a 7mm nut driver, remove the 13 screws from the bottom of the iDeck™.
Figure 94 Unfastening the Bottom of the iDeck™
