- Page 1 HDMI Video Scaler, 4K/60 User Manual 500438-V2 © MuxLab Inc. 2023 94-001001-A/SE-001001-A...
-
Page 2: Table Of Contents
1. Safety Precautions..............................3 2. Introduction................................4 3. Features..................................4 4. Package Contents..............................4 5. Specifications................................5 6. Operation Controls and Functions........................6 6.1. Front Panel................................6 6.2. Rear Panel................................6 7. EDID Settings................................7 8. Video & Audio................................7 9. RS-232 Command..............................8 10. Application Diagram............................12 © MuxLab Inc. 2023 94-001001-A/SE-001001-A... -
Page 3: Safety Precautions
All contents in this manual are copyrighted, and cannot be cloned, copied, or translated without the express permission of MuxLab Inc. Product specifications and information in this document are for reference only, and the content may be updated from time to time without prior notice. -
Page 4: Introduction
HDMI Video Scaler, 4K/60 2. Introduction he HDMI Video Scaler, 4K/60 (500438-V2) allows one (1) HDMI source to be distributed to one (1) HDMI display. The scaler supports video sources up to 4K/60 Hz, 12 bit color and HD audio. The scaler is able to upscale up to 4K/60Hz and downscale to 1024x768/60Hz. It can extract audio signals from HDMI source to digital optical and analog stereo L/R audio outputs. -
Page 5: Specifications
32 - 104°F / 0 - 40°C Operation Temperature Storage temperature -4 - 140°F / -20 - 60°C Relative Humidity 20 - 90% RH (no condensation) 2 years Warranty Order Information 500438-V2 HDMI Video Scaler, 4K/60 (UPC: 627699014387) © MuxLab Inc. 2023 94-001001-A/SE-001001-A... -
Page 6: Operation Controls And Functions
HDMI signal input port, connected to HDMI source device such as DVD or Set-top HDMI IN Port box with HDMI cable 3-pin phoenix connector, connected to a PC or control system for serial port RS232 Port upgrade or RS-232 command control. DC 12V/1A power input port. 12VDC, 1A © MuxLab Inc. 2023 94-001001-A/SE-001001-A... -
Page 7: Edid Settings
The video scaler supports the following video output resolutions via a powerful scaling engine. Output Resolution Output Resolution 4096x2160p 60Hz 1920x1080p 50Hz 4096x2160p 50Hz 1360x768p 60Hz 3840x2160p 60Hz 1280x800p 60Hz 3840x2160p 50Hz 1280x720p 60Hz 3840x2160p 30Hz 1280x720p 50Hz 1024x768 60Hz 3840x2160p 25Hz 1920x1200p 60Hz RB AUTO 1920x1080p 60Hz © MuxLab Inc. 2023 94-001001-A/SE-001001-A... -
Page 8: Rs-232 Command
PC with a 3-pin phoenix connector cable. Then open a Serial Command tool on PC to send ASCII commands to control the product. The ASCII command list about the product is shown below. © MuxLab Inc. 2023 94-001001-A/SE-001001-A... - Page 9 HDMI Video Scaler, 4K/60 © MuxLab Inc. 2023 94-001001-A/SE-001001-A...
- Page 10 HDMI Video Scaler, 4K/60 © MuxLab Inc. 2023 94-001001-A/SE-001001-A...
- Page 11 HDMI Video Scaler, 4K/60 © MuxLab Inc. 2023 94-001001-A/SE-001001-A...
-
Page 12: Application Diagram
HDMI Video Scaler, 4K/60 10. Application Diagram 2321 Cohen | St-Laurent , H4R 2N7 | Québec, Canada Tel: 514-905-0588 | Fax: HDMI Video Scaler, 4K/60 514-905-0589 | Toll free: 1-877-689-5228 info@muxlab.com | 500438-V2 salesteam@muxlab.com | www.muxlab.com Follow us:...
