ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7695CK/EK-VN
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 8
(Included)
(Not Included)
Rev: 19-0 7 - 02
Advertisement
Related Manuals for Furniture of America CM7695CK-VN
Summary of Contents for Furniture of America CM7695CK-VN
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7695CK/EK-VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 8...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 1pc Headboard Allen Wrench M5 #2 x 2pcs #B x 4pcs Side Rail Bolt Ø5/16"...
- Page 4 #J x 1pc #I x 26pcs Power line Screw #8 x 38mm Page 4 of 8...
- Page 5 #5L/R Back Align HB legs (#5R/L) to headboard (#1), then secure by using bolts (#C) with washers (#F,G). #C x 8pcs #F x 8pcs #G x 8pcs Page 5 of 8...
- Page 6 Align FB legs (#6) to footboard (#3), then secure by using bolts (#E) with washers (#F,H). #E x 4pcs #F x 4pcs #H x 4pcs 1) Align the side rails (#2) to the headboard (#1) and footboard (#3), then secure side rails (#2) to footboard (#3) by using bolts (#B) with washers (#F,H).
- Page 7 Align central support slats (#4) to the slats (#7), then secure by using support legs (#8). You can adjust the leveler of the support legs (#8) according to ground level. Align slats (#7) to the side rails (#2), then secure by using screws (#I). #I x 26pcs Page 7 of 8...
- Page 8 Touch LED lamp switch to turn on and off. Make sure wires are connected to headboard and electrical outlet. #J x 1pc Outlet LED Lamp Switch ASSEMBLY IS COMPLETED Page 8 of 8...
