ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7678F/Q-VN
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev: 19-06-26
Advertisement
Related Manuals for Furniture of America CM7678F-VN
Summary of Contents for Furniture of America CM7678F-VN
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7678F/Q-VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 8pcs #1 x 1pc Bolt Ø5/16" x 1-1/4" Headboard #B x 8pcs #2 x 2pcs Bolt Ø5/16"...
- Page 4 Exploded View Align feet (#5) to the headboard (#1), then secure by using screws (#F) with bolts (A) and washers (C,D). #A x 4pcs #C x 4pcs #D x 4pcs #F x 8pcs Page 4 of 6...
- Page 5 Align legs (#5) to the footboard (#3), then secure by using screws (#F) with bolts (#A) and washers (#C,D). #A x 4pcs #C x 4pcs #D x 4pcs #F x 8pcs Align side rails (#2) to the headboard (#1) and footboard (#3), then secure by using bolts (#B) with washers (#C,D).
- Page 6 Align center slat (#7) to slat kit (#4), then secure by using support legs (#6). Align slats (#4) to rails (#2), then secure by using screws (#F). #F x 26pcs Page 6 of 6...
