- Page 4 2. Align the legs (#5) to the holes along the bottom of the headboard (#1) and footboard (#3). Insert 4 screws (#G) and 2 bolt assemblies (#A) into each leg. Secure using the Allen wrench and a screwdriver. 1. Prepare 8 bolt assemblies by first inserting a lock washer (#B) onto the bolt (#A) then a flat washer (#C) onto that same bolt (#A).
- Page 5 1. Prepare 2 bolt assemblies by first inserting a lock washer (#B) onto the bolt (#A) then a flat washer (#C) onto that same bolt (#A). 2. Align the top of the support legs (#6) to the holes along the center support rail (#7). Insert a bolt assembly into each from above and secure using the Allen wrench (#F).
- Page 6 Assemble the slats by following the image below. Place the assembled slats onto the side rails.
- Page 10 2. Align the legs (#5) to the holes along the bottom of the headboard (#1) and footboard (#3). Insert 4 screws (#G) and 2 bolt assemblies (#A) into each leg. Secure using the Allen wrench and a screwdriver. 1. Prepare 8 bolt assemblies by first inserting a lock washer (#B) onto the bolt (#A) then a flat washer (#C) onto that same bolt (#A).
- Page 11 1. Prepare 6 bolt assemblies by first inserting a lock washer (#B) onto the bolt (#A) then a flat washer (#C) onto that same bolt (#A). 2. Align the top of the support legs (#6) to the holes along the center support rail (#7). Insert a bolt assembly into each from above and secure using the Allen wrench (#F).
- Page 12 Assemble the slats by following the image below. Place the assembled slats onto the side rails.
- Page 16 1. Prepare 8 bolt assemblies by first inserting a lock washer (#B) onto the bolt (#A) then a flat washer (#C) onto that same bolt (#A). 2. Align the legs (#5) to the holes along the bottom of the headboard (#1) and footboard (#3).
- Page 17 Apply an end cap (#D) onto each end of the slats (#4). Place the slats onto the side rails.
