3. ATTACHED FITTINGS

Please check whether the following fittings are of full scope. If there are some spare fittings , please restore them carefully .
Installation Fittings
Tubing & Fittings
Drainpipe Fittings
Remote controller & Its Frame
(The product you have might not be
provided the following accessory)
Installation accessory
(The product you have might not be
provided the following accessory)
EMC & Its Fitting
(on some models)
Cautions on remote controller installation:
Never throw or beat the controller.
Before installation, operate the remote controller to determine its location in a
reception range.
Keep the remote controller at least 1m apart from the nearest TV set or stereo
equipment. (it is necessary to prevent image disturbances or noise interferences.)
Do not install the remote controller in a place exposed to direct sunlight or close to a
heating source, such as a stove.
Note that the positive and negative poles are right positions when loading batteries.
This manual is subject to changes due to technological improvement without further
notices.
NAME
1. Installation paper board
(on some models)
2. Soundproof / insulation sheath
(on some models)
3. Out-let pipe sheath
(on some models)
4. Out-let pipe clasp
(on some models)
5. Drain joint(on some models)
6. Seal ring(on some models)
7. Remote controller
8. Remote controller holder
9. Mounting screw(ST2.9×10-C-H)
10. Alkaline dry batteries (AM4)
11. Owner's manual
12. Installation manual
13. Expansible hook
14. Installation hook
15 .Orifice
16. Magnetic ring
(twist the electirc wires P&Q&E around
the magnetic ring to two circles)
(depending on the models)
SHAPE
Mounting screw B
SET TEMPERATURE(°C)
ST2.9x10-C-H
AUTO FAN
COOL HIGH
DRY MED
HEAT LOW
TEMP
FAN
ON/OFF
MODE SPEED
ECONOMIC
SWING RUNNING TIMER
VENT CANCEL
LOCK
RESET
Remote
controller
QUANTITY
1
1
1
1
1
1
1
1
2
2
1
1
4
4
1
1
Remote controller
holder
Fig.3-1
installation manual
