(the figure is for the unit with the new fan function)
Fig.10-9
the power of new fan motor is less than or equal to 200W
INDOOR UNIT
NEW FAN
220-240V~
(the figure is for the unit with the new fan function)
Fig.10-10
the power of new fan motor is more than 200W
INDOOR UNIT
NEW FAN
220-240V~
The wiring must be operated according to the wiring scheme,or it damages the unit.
Before obtaining access to terminals, all supply circuits must be disconnected.
NEW FAN
MOTOR
Fuse
DC RELAY/
AC CONTACTOR
CAUTION
L
NEW FAN
N
MOTOR
installation manual
23
