R
OPERATING INSTRUCTION
powerCON
CONNECTING
1.
A
Note:
When connecting, match the notch
on the cable connector to the
corresponding guide slot on the
chassis.
B
BDA 556
®
TRUE1 TOP
Note:
After inserting properly
A
as in illustration A ,
twist the cable
connector clockwise to
lock.
Cable Connector
SAFETY WARNING
incorrect insertion may cause electrical contact
misalignment resulting in equipment malfunction
and/or personal injur y.
C
click
Note:
The proper twist-lock
is achieved when the
silvery tab is in the
position shown in C
and an audibel «click»
is heard.
C
Page 1
