B A R T O N
I I
D I G I T A L R A D I O & A L A R M C L O C K
BAR-DAB-2
Instructions Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BARTON II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MAJORITY BARTON II

  • Page 1 B A R T O N D I G I T A L R A D I O & A L A R M C L O C K BAR-DAB-2 Instructions Guide...
  • Page 2: Table Of Contents

    FM Radio Presets ����������������������������������������������������� Clock & Date Settings ����������������������������������������������� Dual Alarm Settings ������������������������������������������������� Alarm Functions ������������������������������������������������������� Other Functions ������������������������������������������������������� Troubleshooting ������������������������������������������������������ Spectifications ��������������������������������������������������������� Warranty ����������������������������������������������������������������� Safety Information��������������������������������������������������� YEAR Watch video tutorials and register your product for a FREE 3-year warranty WARRANTY at https://majority.co.uk...
  • Page 3 What’s In The Box? Box Contents Majority Barton II Radio UK Power Supply User Guide...
  • Page 4: Controls And Functions

    Controls And Functions Front View Power/Mode Display Screen Info/Menu Snooze/Sleep Scan 10. Previous Alarm 11. Preset Dimmer 12. Next Volume -/+ 13. Select Speaker...
  • Page 5 Controls And Functions Back View 14. O /On Switch 15. DC Power Input 16. Headphone Jack 17. Antenna...
  • Page 6 Support Support Thank you for your purchase of the Majority Barton II. Please follow the guidance of the manual to set up your radio and enjoy its fantastic variety of stations and features. If you require further assistance with your new radio, please contact our support team on the Majority website: https://majority.co.uk/...
  • Page 7: Instructions Guide

    Instructions Guide Basic Operation Please note all (Ref.) refer to Page 1 Controls and Functions mapping guide. Plug the connector into the back of the system labelled DC 5V (Ref.15) and the power supply into the mains. Ensure the antenna (Ref.17) is extended as far as possible so that you can rotate it which will enable you to get the best signal you can.
  • Page 8 Instructions Guide Standby To place the music system in standby, press and hold down the ‘Power/Mode’ button (Ref.1). To turn o the radio o fully, switch it o at the mains. The cord must be out of reach of children.
  • Page 9: Dab/Dab+ Radio

    Instructions Guide DAB/DAB+ Radio Press the ‘Power/Mode’ button (Ref.1) to switch to DAB/DAB+ Radio. On rst use it will automatically scan all stations and save them. Fully extend the antenna (Ref.17). If the unit hasn’t automatically scanned or you would like to rescan the available stations, press the ‘Scan’...
  • Page 10: Dab/Dab+ Presets

    Instructions Guide DAB/DAB+ Presets How to store a preset station To be able to quickly access your favourite DAB/DAB+ stations, you can preset them. Up to 10 di erent preset stations can be set for you to browse between. To store a station as a preset, it is best to be listening to the station at the time.
  • Page 11 Instructions Guide Station Information for DAB Radio DAB/DAB+ Radio When you are listening to a DAB/DAB+ radio station with good signal, you can press the ‘Info/Menu’ button (Ref.2) repeatedly to show the di erent programme information. Bit Rate: Shows the data rate at which the signal is being transmitted.
  • Page 12: Fm Radio

    Instructions Guide FM Radio Press the ‘Power/Mode’ button (Ref.1) multiple times to switch between DAB and FM. The rst time you switch to FM mode, the FM frequency “87.5 MHz” will be displayed on the screen. Fully extend the antenna (Ref.17). To scan for the available stations with good signal, press the ‘Scan’...
  • Page 13 Instructions Guide FM Scan Setting Choose between scanning strong and weak signals (All) or only the strong stations (Only). Press and hold the ‘Info/Menu’ button (Ref.2). To make your choice, use the ‘Prev’ or ‘Next’ buttons (Ref.10 ) to scroll to “FM Scan Setting”...
  • Page 14: Fm Radio Presets

    Instructions Guide FM Radio Presets How to store a preset station To be able to quickly access your favourite FM stations, you can preset them. Up to 10 di erent preset stations can be set for you to browse between. To store a station as a preset, it is best to be listening to the station at the time.
  • Page 15 Instructions Guide Station Information for FM Radio FM Radio When you are listening to an FM radio station with good signal, you can press the ‘Info/Menu’ button (Ref.2) repeatedly to show the di erent programme information. Signal Strength: Displays a signal bar with the strength of the current station.
  • Page 16: Clock & Date Settings

    Instructions Guide Clock & Date Settings Once the radio has been put into DAB/DAB+ mode, the time and date should automatically set. If this does not happen or you wish to alter the time and date, follow the below guidance: Manually Setting the Time Ensure the unit is turned on and o standby.
  • Page 17 Instructions Guide Manually Setting the Date The date can be changed after changing the time. The year will ash on the display screen. To change the date year, press the ‘Prev’ (Ref.10) or ‘Next’ (Ref.12) buttons until the required year is displayed. To con rm the year, press the ‘Select’...
  • Page 18: Dual Alarm Settings

    Instructions Guide Dual Alarm Settings 1. Press the ‘Alarm’ button (Ref.4) once for Alarm 1 or twice for Alarm 2. Press the ‘Select’ button (Ref.13) to con rm the alarm you wish to set. 2. Once alarm 1 or 2 is selected, “OFF” will display on the screen. To turn the alarm on, use the ‘Next’...
  • Page 19: Alarm Functions

    Instructions Guide Alarm Functions To Cancel Alarm 1 or Alarm 2 To cancel the alarm, press the ‘Alarm’ button (Ref.4) once for Alarm 1 or twice for Alarm 2. Press the ‘Select’ button (Ref.13) to con rm the alarm you wish to cancel. To turn the Alarm o , press the ‘Next’...
  • Page 20: Other Functions

    Instructions Guide Other Functions Sleep Setting This enables you to programme the radio to switch o at a speci c time, up to 120 minutes from activation. Press the ‘Snooze/Sleep’ button (Ref.9). Using the ‘Prev’ or ‘Next’ buttons (Ref.10 ), choose the sleep timer amount from activation: OFF/5 mins/15mins/30mins/45mi ns/60mins/90mins or 120mins.
  • Page 21 Instructions Guide To perform a factory reset, press and hold the ‘Info/Menu’ button (Ref.2). Use the ‘Prev’ or ‘Next’ buttons (Ref.10/ ) to browse to the “Factory reset” option and press the ‘Select’ button (Ref.13) to con rm. The display screen will then show “Factory reset?”. To con rm the factory reset, use the ‘Next’...
  • Page 22: Troubleshooting

    Troubleshooting Observation Potential Cause/Solution No sound The station is not tuned in properly. Please perform a rescan for available stations or manually scroll through available stations. Cannot preset Ensure that you are pressing and holding down the stations Preset button for 2-3 seconds to open Preset Store settings.
  • Page 23: Spectifications

    Warranty All products come with a standard 12 month warranty. All items must be registered on https://majority.co.uk/ for the warranty to be valid. Once on the web page, use the menu to nd “Register Your Product”. You will also be given the chance to extend your warranty for an additional 24 months, free of charge.
  • Page 24: Safety Information

    Safety Information 1. Read these instructions. ADDITIONAL WARNINGS 2. Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping or available for download at www.majorityradios.co.uk splashing and no objects lled with liquid, such as 3. Heed all Warnings vases, shall be places on the apparatus.
  • Page 26 www.majority.co.uk...
