- Page 1 Majority Chesterton DAB / DAB+ / FM Radio CB4-DAB-WHT/BLK User Guide...
-
Page 2: Table Of Contents
Contents Controls and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 What’s in the Box? . -
Page 3: Controls And Functions
Controls and Functions Instructions Guide 1 2 3 5 6 7 1 . Power/Source 4 . Volume 7 . Scan Up/Down 2 . Info/Menu 8 . Previous/Next 5 . Alarm/Sleep 3 . Preset 9 . Antenna 6 . Enter/Snooze 10 . Display screen... - Page 4 Instructions Guide Controls and Functions 5 6 7 11 . On/Off Switch 13 . Charging Light 14 . 3 .5mm Indicator Headphone 12 . DC 5V,1A Power Socket connector...
-
Page 5: What's In The Box
What’s in the Box? Instructions Guide Majority Chesterton DAB / DAB+ Radio Clock ● UK Standard Plug DC 5V,1A Power Supply ● User Guide ●... -
Page 6: Basic Operation
Instructions Guide Please note all (Ref.) refer to the Controls and Functions mapping guide on Pages 1-2 . Basic Operation Plug the connector into the back of the system labelled DC 5V (Ref .12) and the power supply into the mains . Power Supply ON/OFF at back of system (Ref .11) . -
Page 7: Dab Radio And Set Up Preset For Dab Radio
Instructions Guide Instructions Guide Standby To place the system in standby mode, press and hold the ‘Power/Source’ button (Ref .1) . To turn off fully, press the button on rear of the unit (Ref .11) and switch off at the mains . The cord must be out of reach of children . - Page 8 Instructions Guide To listen to all stations that have been stored use the ‘Next’ and ‘Prev’ (Ref .8) buttons to scroll through them . The radio will display station information when you press the ‘Info/Menu’ button (Ref .2) . Please see page 9 for further details . When you power up the radio again after switching off, it will automatically tune to the same station (DAB or FM) that was last selected .
-
Page 9: Fm Radio And Set Up Preset For Fm Radio
Instructions Guide FM Radio Press the ‘Power/Mode’ button (Ref .1) multiple times to switch to FM . The first time you do this, FM frequency “87 .5 MHz” will be displayed on the screen . Fully extend the antenna (Ref .9) . To auto-scan press and release the ‘Scan’... - Page 10 Instructions Guide How to store a preset radio station Up to 10 preset stations can be set . To store a station that you are currently playing: Press and hold the ‘Preset’ button (Ref .3) . “<1: (Empty)” will show on the display . Press ‘Prev’...
-
Page 11: Station Information For Dab And Fm Radio
Instructions Guide Station Information for DAB and FM Radio DAB / DAB+ Radio Press the ‘Info/Menu’ button (Ref .2) repeatedly to show the different programme information . Bit Rate: Shows the data rate at which the signal is being transmitted . Bit Error Rate (BER): Provides details of the signal error rate . - Page 12 Instructions Guide FM Radio Press the ‘Info/Menu’ button (Ref .2) repeatedly to show the different programme information . Signal Strength: Displays a signal bar with the strength of the current station . Time and Date: Displays the time and the date . Frequency: Displays the station’s transmission frequency .
-
Page 13: Clock And Date Setting
Instructions Guide Clock and Date Setting Manually Setting the Time The time will automatically update after the first time of using DAB Radio, but you can still set the time manually as follows: Ensure the unit is turned on . Press and hold the ‘Info/Menu’... - Page 14 Instructions Guide Manually Setting the Date The date can be changed straight after changing the time . The year will flash on the display screen . Press the ‘Prev’ or ‘Next’ (Ref .8) buttons until the required year is displayed . To confirm the year, press the ‘Enter/Snooze’...
-
Page 15: Dual Alarm Setting
Instructions Guide Dual Alarm Setting Alarm 1/Alarm 2 Setting Press (do not hold) the ‘Alarm/Sleep’ button (Ref .5) and “Alarm 1” will be displayed . Press the ‘Enter/Snooze’ button (Ref .6) to use Alarm 1, or press ‘Next’ button (Ref .8) to show Alarm 2 . To turn the Alarm on, press ‘Next’... -
Page 16: Alarm Sound And Snooze
Instructions Guide To Turn off Alarm 1 or Alarm 2 Press the ‘Alarm/Sleep’ button (Ref .5) and “Alarm 1” will be displayed . Choose which alarm you would like to turn off using the ‘Next’ button (Ref .8) . Press the ‘Enter/Snooze’ button (Ref .6) to confirm . -
Page 17: Other Functions
Instructions Guide Other Functions Sleep Setting This enables you to programme the radio to switch off at a selection of set times up to 120 minutes from activation . Press and hold the ‘Alarm/Sleep’ button (Ref .5) for 1 second and release . - Page 18 Instructions Guide System Reset Press and hold the ‘Info/Menu’ button (Ref .2) . Use the ‘Prev’ or ‘Next’ (Ref .8) buttons to make your selection . Choose “Factory Reset” and press the ‘Enter/Snooze’ button (Ref .6) . The display screen will show “Factory Reset?” Use the ‘Next’...
-
Page 19: Technical Specification
Technical Specifications and Warranty Technical Specifications Power Supply In-built Battery Mode FM (87 .5MHz – 108MHz) DAB/ DAB+ (174 – 240MHz) Output Connector 3 .5mm Earphone Socket Aerial Integral Telescopic Aerial Warranty All products come with a standard 12 month warranty . All items must be registered on www.majorityradios.co.uk for the warranty to be valid . -
Page 20: Troubleshooting Guide
Troubleshooting Guide Observation Potential cause/solution No sound The station is not tuned in . Fine tune the station . The volume is set to a low position . Increase the volume . Headphones may be connected . Disconnect the headphones . Buttons are not Turn off the unit and turn on after a few seconds . -
Page 21: Important Safety Information
IMPORTANT SAFETY INFORMATION ADDITIONAL WARNINGS 1 . Read these instructions . 2. Keep these instructions . Instructions are also The apparatus shall not be exposed to dripping or available for download at splashing and no objects filled with liquid, such as www.majorityradios.co.uk vases, shall be placed on apparatus . - Page 24 www.majorityradios.co.uk...
