Rechargeable li-ion battery

Advertisement

Quick Links

Rechargeable Li-Ion Battery
产品型号 Product Model:
产品代码 Product Code
容量 Capacity.:
客户代码 Customer Code:
规格书编号 Specification No.:
文件版本 REV:
拟制
Prepared
陈晓东
2021-05-12
Customer
Approval
客户承认
厂址:深圳市宝安区松岗街道塘下涌第二工业区第十栋
Address: Bld.10,2rd Industrial Park TangXiaYong,SongGang,BaoAn,ShenZhen, China
电话(TEL) :+86-755-33893788
富基电子(深圳)有限公司
FUJI ELECTRONICS (SHENZHEN) CO., LTD.
Technical Data Sheet
FUJI ELECTRONICS (SHENZHEN) CO.,LTD.
Quality Checkout
2021-05-12
Company Name:
公司名称:
Customer Model :
客 户 型 号
Part No.:
部 件 编 号:
Signature
传真(FAX) :+86-755-33895166
18650(1INR19/66-4)
539043S
13000mAh
539
A2
品质检验
王虎
:
Date
日 期
核准
Approved
梁荣钦
2021-05-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 18650 and is the answer not in the manual?

Questions and answers

Summary of Contents for FujiFilm 18650

  • Page 1 富基电子(深圳)有限公司 FUJI ELECTRONICS (SHENZHEN) CO., LTD. Rechargeable Li-Ion Battery Technical Data Sheet 产品型号 Product Model: 18650(1INR19/66-4) 产品代码 Product Code 539043S 容量 Capacity.: 13000mAh 客户代码 Customer Code: 规格书编号 Specification No.: 文件版本 REV: FUJI ELECTRONICS (SHENZHEN) CO.,LTD. 拟制 品质检验 核准 Prepared Quality Checkout Approved 陈晓东...
  • Page 2 文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 1/ 18 Date Page 修订履历表 History of Change 序号 版本 修订内容 修订者 Date 日期 Rev. Content of Change Prepared Only for reference...
  • Page 3: Table Of Contents

    文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 2/ 18 Date Page 目录 Table of Content 1、目的 Scope..............................3 2、依据标准 Test reference standard......................3 3、基本参数 Key parameters..........................3 4、测试方法和定义 Test methods and definitions..................4 5、技术指标...
  • Page 4: 1、目的 Scope

    文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 3/ 18 Date Page 1、目的 Scope 本规格书适用于富基电子(深圳)有限公司生产的锂离子电池, 它是产品设计、生产和检验的依据,其作用是让顾客了解产 品的质量及正确使用方法. This specification shall be applied to Li-ion battery manufactured by FUJI ELECTRONICS (SHENZHEN) Co., LTD. It is the basis of the product design, production and testing;...
  • Page 5: 4、测试方法和定义 Test Methods And Definitions

    文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 4/ 18 Date Page 0℃~10℃: Charge current Max0.2C; Charge voltage 4.2V. 0℃~10℃: 最大充电电流 0.2C,充电电压 4.2V. Charging:0℃~45℃ 10℃~45℃: Charge current Max3A; Charge 充电:0℃~45℃...
  • Page 6: 5、技术指标 Technical Indicators

    文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 5/ 18 Date Page 4.3 标准充电 Standard charge 在环境温度为 25℃±2℃条件下,用 0.2C 电流对电池充电,当电压到 4.2V 时,改为 4.2V 恒压充电,直到电流小于或等于 0.02C,停止充电,充电时间不大于 8h。 Charge the battery at 0.2C to 4.2V at ambient temperature of 25℃±2℃, and then charge at constant voltage of 4.2V to current less than or equal to 0.02C.
  • Page 7 文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 6/ 18 Date Page 5.1.4 电池按 4.3 规定充电结束后, 放入 55℃±2℃的高温箱中恒温 容 量 ≥ 100% × 最 小 高温性能 High temperature 2h,然后以 0.2C A 电流放电至...
  • Page 8 文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 7/ 18 Date Page 5.2.2 电池按 4.3 规定充电结束后,将电池固定在振动台上,不可 振动测试 电池应不泄漏、不泄 Vibration test 使电池变形。 气、不破裂、不起火和 采用正弦波进行振动, 并以对数扫频方式在 15min 内从 7Hz 不 爆 炸 No leak, no 扫频到...
  • Page 9 文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 8/ 18 Date Page 图 1 温度循环流程示意图 Charge the battery per section 4.4 and place the battery at 25℃ ±2 ℃ temperature control chamber and go through the following steps (see figure 1):...
  • Page 10 文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 9/ 18 Date Page negative terminals with a resistor of 80±20mΩ. After the explosion. The battery test, the battery should meet the criteria. Disconnect the...
  • Page 11: 6、保护板规格与特性 Pcm Spec. And Characteristic

    文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 10/ 18 Date Page 6、保护板规格与特性 PCM Spec. and characteristic 6.1 PCM 规格(at 25℃)PCM specification(at 25℃) 序号 项目 最小值 典型值 最大值 备注 Item Min.
  • Page 12 文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 11/ 18 Date Page 6.2 电路原理图 Circuit Diagram B +1 P+ 1 IRQ 1 SC L1 A XP 2 6 0 1...
  • Page 13 文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 12/ 18 Date Page 6.4 保护板主要零件清单 PCM key component list 元件编 数 元件名称 元件规格 封装式 号 量 R5478N218CD 理光 ROHS 编带 SOT-23-6 Q1 Q2 8205A ROHS 编带...
  • Page 14: 7、装配结构 Assembly Configuration

    文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 13/ 18 Date Page 7、装配结构 Assembly configuration 7.1 电池尺寸结构 (单位 mm) Dimension (Unit :mm) 厚度37.8Max (检测区域) 青色纸 10(Ref) 12±2 25±2 5±2 12±3 *66.4±0.3...
  • Page 15 文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 14/ 18 Date Page 7.2 商标图 Label drawing --- FUJI Confidential ---...
  • Page 16: 9、环保要求 Environmental Requirements

    文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 15/ 18 Date Page 9、环保要求 Environmental requirements. 本电池产品符合 RoHS2.0 指令要求。 This product is RoHS2.0 compliant. 10、外观 Cosmetic requirements 10.1 用目测法检验被测电池外观,并检查电池与移动电话或模拟装置配合情况,应符合以下要求: Visually inspect the battery appearance and check the fit between the battery and the mobile phone or simulator device.
  • Page 17: 12、安全规程和使用说明 Safeguard And Instruction

    文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 16/ 18 Date Page 12、安全规程和使用说明 Safeguard and instruction 12.1 推荐使用事项 Recommendations 12.1.1 使用电池前,请仔细阅读使用说明书和电池表面标识。 Please read the instruction manual and the markings on the battery package carefully before using the battery.
  • Page 18 文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 17/ 18 Date Page 12.2.4 避免在热源附近使用电池 不要在火源,烤炉附近或超过 80℃的环境中使用电池 ,过热将会导致电池内部短路,使电池发热、冒烟、变形或燃烧。 Do not use the battery near a heat source,Do not use the battery near fire or an oven, or in an ambient temperature exceeding 80℃.
  • Page 19: 13、质量评定程序 Quality Assessment Procedures

    文件名称 电池规格书 产品型号 18650(1INR19/66-4) File Name Battery Spec. Product model 文件编号 文件版本 Document No. Version 日期 页码 2021-05-12 18/ 18 Date Page 12.2.11 不可将电池用于其它设备 不合适的使用条件会损坏电池的性能,降低寿命,甚至会使电池发热、冒烟、变形或燃烧。 Do not use batteries to power other devices Unusual operating conditions may damage the battery performance, reduce life cycle and even cause heat generation, smoking, deformation or burning.
