- Page 1 Operations and Installation Manual Keysight 85132E/F 3.5 mm to 7 mm Test Port Return Cables...
-
Page 2: Safety Notices
PERFORMANCE OF THIS to the public to use, modify, DOCUMENT OR ANY INFORMATION reproduce, release, perform, CONTAINED HEREIN. SHOULD display, or disclose commercial KEYSIGHT AND THE USER HAVE A computer software or SEPARATE WRITTEN AGREEMENT commercial computer software WITH WARRANTY TERMS... -
Page 3: General Information
Both are test port return cables designed specifically for use with 7 mm calibration and verification kits and test sets with NMD-3.5 mm ports as part of a network analyzer system. the 85132E consists of a single, 97.2 cm (38.25 inches) long cable with a 7 mm connector on the DUT end and an NMD-3.5 mm (f) connector on the test set end. -
Page 4: Specifications
85132E/F Return Cables Specifications Keysight Technologies guarantees that the performance of your cables will equal or exceed the following specifications, at frequencies <18 GHz: ≤1.3 (17.7 dB return loss) Insertion Loss (in dB) Recession of center conductor shoulder behind outer conductor mating plane. -
Page 5: Performance Tests
≤0.13 (f) +0.5, 85132F a. (f) = frequency in GHz. Electrical length of the 85132E cable is approximately 1.150 m and it is approximately 0.74 m for the 85132F. Performance Tests Use a network analyzer to perform the following tests upon your cables as soon as you receive them. - Page 6 85132E/F Return Cables 9. Select the gating function and gate-out everything but the cable. See Figure 10.Select the analyzer’s frequency domain mode. 11.Use the markers to read the return loss value. Figure 2 Analyzer Trace Showing Location of Gates and Airline Insertion loss is measured by terminating the cable with a short and then measuring return loss.
-
Page 7: Replaceable Parts
85132E/F Return Cables Replaceable Parts The following items are replaceable on the 85132E/F cables:. Item Part Number Six slot collets 85050-20001 A single 85132E 3.5 mm to 7 mm cable 85132-60018 Was: 85132-60008 Two identical cables 85132F 3.5 mm (f) to 7... -
Page 8: Visual Inspection
85132E/F Return Cables Visual Inspection Visual inspection and, if necessary, cleaning should be done every time a connection is made. Metal particles from the connector threads may fall into the connector when it is disconnected. One connection made with a dirty or damaged connector can damage both connectors beyond repair. -
Page 9: Contacting Keysight
85132E/F Return Cables Contacting Keysight Assistance with test and measurement needs and information on finding a local Keysight office are available on the Web at: www.keysight.com/find/assist In any correspondence or telephone conversation, refer to the Keysight product by its model number and full serial number. With this information, the Keysight representative can determine whether your product is still within its warranty period. - Page 10 85132E/F Return Cables Operating and Service Manual 85132-90010...
- Page 11 85132E/F Return Cables Operating and Service Manual 85132-90010...
- Page 12 85132E/F Return Cables Operating and Service Manual 85132-90010...
- Page 13 85132E/F Return Cables Operating and Service Manual 85132-90010...
- Page 14 85132E/F Return Cables Operating and Service Manual 85132-90010...
- Page 15 85132E/F Return Cables Operating and Service Manual 85132-90010...
- Page 16 Installation Note Xxxxx-xxxxx...
- Page 17 This information is subject to change without notice. © Keysight Technologies 1987-2016 Edition 1, September 2016 www.keysight.com...
