The most outstanding features of the DIMENSION Q- Series DIN
rail power supplies are the extremely high efficiencies and the
small sizes, which are achieved by a synchronous rectification
and other technological designs.
The QS40.484 is a device for 200-240V mains voltages. Large
power reserves of 150% support the starting of heavy loads such
as DC-motors or capacitive loads. In many cases this allows the
use of a unit from a lower wattage class which saves space and
money.
High immunity to transients and power surges as well as low
electromagnetic emission makes usage in nearly every
environment possible.
The integrated output power manager and input fuses as well as
the near zero input inrush current make installation and usage
simple. Diagnostics are easy due to the DC-OK relay, a green DC-
OK LED and the red overload LED.
A large international approval package for a variety of
applications makes this unit suitable for nearly every
application.
O N
RDER UMBERS
Power Supply QS40.484
Accessory ZM2.WALL
UF20.481
YR40.482
Jul. 2023 / Rev. 3.4 DS-QS40.484-EN
All parameters are specified at 48V, 20A, 230Vac, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
48-54V Standard unit
Wall mount bracket
Buffer unit
Redundancy module
www.pulspower.com Phone +49 89 9278 0 Germany
48V, 20A, S
P S
OWER UPPLY
▪ AC 200-240V Input
▪ Width only 125mm, Weight only 1.8kg
▪ 95.0% Full Load and Excellent Partial Load Efficiencies
▪ 50% BonusPower, 1440W for up to 4s
▪ 55A High Peak Current for 25ms for Easy Fuse Tripping
▪ Safe Hiccup
PLUS Overload Mode
▪ Active PFC (Power Factor Correction)
▪ Negligible Low Input Inrush Current Surge
▪ Full Power Between -25°C and +60°C
▪ Current Sharing Feature for Parallel Use
▪ Internal Data Logging for Troubleshooting Included.
▪ DC-OK Relay Contact
▪ Shut-down Input
▪ 3 Year Warranty
S - D
HORT FORM ATA
Output voltage DC 48V
Adjustment range 48 - 54Vdc
Output current 20 – 17.8A
30 – 26.7A
Output power 960W
1440W
Output ripple < 150mVpp
Input voltage AC 200-240V
Mains frequency 50-60Hz
AC Input current 4.6A
Power factor 0.96
AC Inrush current 14A peak
Efficiency 95.0%
Losses 50.5W
Temperature range -25°C to +70°C
Derating 24W/°C
Hold-up time 30ms
Dimensions 125x124x127mm
Weight 1800g
M A
AIN PPROVALS
For details and the complete approval list, see chapter 22.
UL508
Marine
QS40.484
P I
INGLE HASE NPUT
nominal
continuous
short term (4s)
continuous
short term (4s)
20Hz to 20MHz
-15%/+10%
±6%
at 230Vac
at 230Vac
at 230Vac
at 230Vac
at 230Vac
operational
+60 to +70°C
at 230Vac
WxHxD
UL 60950-1 Marine
1/30
