Q-Series
P
D
RODUCT
ESCRIPTION
The most outstanding features of this Dimension QS40.241 DIN
rail power supply are the extremely high efficiency and the small
size, which are achieved by a synchronous rectification, a
bridgeless PFC circuit and additional unique design details.
Large power reserves of 150% and built-in large sized output
capacitors support the starting of heavy loads such as DC motors
or capacitive loads. In many cases this allows the use of a unit
from a lower wattage class which saves space and money.
High immunity to transients and power surges as well as low
electromagnetic emissions makes usage in nearly every
environment possible.
The integrated input fuse as well as the near zero input inrush
current make installation and usage simple. Diagnostics are easy
due to the DC-OK relay, a green DC-OK LED and the red overload
LED.
A large international approval package for a variety of
applications makes this unit suitable for nearly every
application.
O
N
RDER
UMBERS
Power Supply
QS40.241
QS40.241-C2
Accessory
ZM2.WALL
UF20.241
YR80.242
YR40.245
Jul. 2023 / Rev. 1.4 DS-QS40.241-EN
All parameters are specified at 24V, 40A, 230Vac, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
24-28V Standard unit
Partially conformally
coated PCB
Wall mount bracket
Buffer unit
Redundancy module
Redundancy module
www.pulspower.com Phone +49 89 9278 0 Germany
QS40.241, QS40.241-C2
24V, 40A, S
P
S
OWER
UPPLY
▪ AC 100-240V Wide-range Input
▪ Width only 125mm, Weight only 1.9kg
▪ 94.6% Full Load and Excellent Partial Load Efficiencies
▪ Version-C2 with Partially Conformally Coated PCB
▪ 50% BonusPower, 1440W for up to 4s
▪ 110A High Peak Current for 10ms for Easy Fuse Tripping
▪ Safe Hiccup
PLUS
Overload Mode
▪ Active PFC (Power Factor Correction)
▪ Negligible Low Input Inrush Current Surge
▪ Full Power Between -25°C and +60°C
▪ Current Sharing Feature for Parallel Use
▪ Internal Data Logging for Troubleshooting Included.
▪ Remote Control of Output Voltage
▪ DC-OK Relay Contact
▪ Shut-down Input
▪ ATEX and IECEx Approved
▪ 3 Year Warranty
S
-
D
HORT
FORM
ATA
Output voltage
DC 24V
Adjustment range
24 - 28Vdc
Output current
40 – 34.3A
60 – 51.5A
Output power
960W
1440W
Output ripple
< 100mVpp
Input voltage
AC 100-240V
Mains frequency
50-60Hz
AC Input current
8.6 / 4.5A
Power factor
0.99 / 0.99
AC Inrush current
17 / 11A peak
Efficiency
93.6 / 94.6%
Losses
65.6 / 54.8W
Temperature range
-25°C to +70°C
Derating
24W/°C
between 85-90Vac see chapter 18
Hold-up time
27 / 27ms
Dimensions
125x124x127mm
Weight
1900g
M
A
AIN
PPROVALS
For details and the complete approval list, see chapter 22.
UL 508
ATEX
P
I
INGLE
HASE
NPUT
nominal
continuous
short term (4s)
continuous
short term (4s)
20Hz to 20MHz
-15%/+10%
±6%
at 120 / 230Vac
at 120 / 230Vac
at 120 / 230Vac
at 120 / 230Vac
at 120 / 230Vac
operational
+60 to +70°C
at 120 / 230Vac
WxHxD
UL 60950-1
Class I Div 2
IECEx
Marine
1/31
