- Page 1 HADOC 3012C v.1.0 HADOC 13,8V/3A/17Ah/OC Buffer, switch mode power supply unit with automatic operation control. Edition: 2 from 05.06.2014 Supercedes edition: 1 from 19.03.2014...
- Page 2 During normal operation, the total current drawn by the equipment may not exceed I = 3A. Maximum battery charge current: 0,23A. Total device current + battery: 3,23A max OPTIONAL POWER SUPPLY CONFIGURATIONS: (visualisation available at: www.pulsar.pl) BATTERY 17Ah: 1. Buffer power supply unit HADOC 13,8V/3x1A/17Ah. - HADOC3012C + LB4 3x1,0A (AWZ576 or AWZ575) + 17Ah 2.
- Page 3 GREEN POWER plus www.pulsar.pl HADOC3012C BATTERY 7Ah: 1. Buffer power supply unit HADOC 13,8V/12V/6x0,5A/7Ah. - HADOC3012C + RN500 (13,8V/12V) + LB8 6x0,5A (AWZ580 or AWZ578) + 7Ah 2. Buffer power supply unit HADOC 13,8V/2x5V÷7,4V/2x2A/7Ah. - HADOC3012C + 2xDCDC20 (2x5V÷7,4V/2x2A) + 7Ah 3.
- Page 4 GREEN POWER plus www.pulsar.pl HADOC3012C Description of PSU components and connectors (tab.2, fig.3). lement no. Description [Fig. 3] PSU module TAMPER, contact, sabotage protection (NC) Tab.2. Output terminals of the PSU. Fig.3. The view of the PSU. 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4)
- Page 5 GREEN POWER plus www.pulsar.pl HADOC3012C - AC diode indicating AC power status - red, normal status – on, failure: off - AUX diode indicating DC power status at - green, normal status – on, failure: off the PSU output - BAT diode indicating battery voltage level - green, normal status –...
- Page 6 GREEN POWER plus www.pulsar.pl HADOC3012C 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max.
- Page 7 GREEN POWER plus www.pulsar.pl HADOC3012C Moreover, the PSU is equipped with 3LEDs on the PCB board: - red LED (Fig.2, element 1) normal status (AC power): permanently illuminated. AC power absence is indicated by the AC diode going out. Caution! LED indicates power absence if the outage lasts >10s.
- Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a four-year warranty for the equipment, counted from the device’ production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects,...
