- Page 1 USER MANUAL COMPACTFLAT SN 2 Mounting Gauge VERSION: 01 LANGUAGE: ENGLISH | ORIGINAL LANGUAGE: GERMAN IMPORTANT! READ CAREFULLY BEFORE USE!
- Page 2 The user manual is protected by copyright. This manual may not be copied, reproduced, microfilmed, translated, or con- verted for storage and processing in computer systems, in whole or in part, without the written permission of AEROCOMPACT®. Copyright by © AEROCOMPACT® MANUFACTURER AEROCOMPACT® Holding Sonnenstraße 10...
- Page 3 Set up mounting gauge Use mounting gauge to align the feet Use mounting gauge to align base rails Apply mounting gauge Positioning the feet - SN 2 (5° or 10°) Positioning the feet - SN 2 Plus Positioning the base rail CompactFLAT SN 2 Mounting Gauge...
- Page 4 SET UP MOUNTING GAUGE The mounting gauge can be used to align the base rails as well as the feet. To insert the spacers, remove the end caps on one side. After inserting the spacers, reattach the end caps accordingly. Use mounting gauge to align the feet Insert the spacer (1) into the guide rail (2) and move it to the desired position.
- Page 5 Use mounting gauge to align base rails Insert the spacer (1) into the guide rail (2) and move it to the desired position. Then tighten with the locking screw (3). CompactFLAT SN 2 Mounting Gauge...
- Page 6 APPLY MOUNTING GAUGE Positioning the feet - SN 2 (5° or 10°) Mount the first three feet (1-3) according to the mounting instructions. The correct spacing dimensions of the feet must be taken from the planning documents. Place the mounting gauge according to the illustration and fix the spacer (distance A = 50 mm). The adjusted mounting gauge can now be repositioned, applying the spacer from foot (1) to foot (3).
- Page 7 Positioning the feet - SN 2 Plus Mount the first three feet (1-3) according to the mounting instructions. The correct spacing dimensions of the feet must be taken from the planning documents. Place the mounting gauge according to the illustration and fix the spacer (distance A = 50 mm). The adjusted mounting gauge can now be repositioned, turning the mounting gauge 180°...
- Page 8 Positioning the base rail Determine the distances between the base rails. The correct spacing dimensions of the base rails must be taken from the planning documents. Place the mounting gauge according to the illustration and fix the spacer. The adjusted mounting gauge can now be repositioned, with the spacer of base rail (1) being placed at base rail (3). Apply the mounting gauge along the base rails several times so that the base rails are aligned parallel.
