- Page 1 Swing-gate gearmotor FA01561-EN ATS30DGS ATS50DGS ATS30DGR ATS30DGM ATS50DGM English INSTALLATION MANUAL...
- Page 3 Machinery Directive (2006/42/EC) and with the reference harmonised technical standards are specified in the general CAME product catalogue or on the website www.came.com. • Make sure the mains power supply is disconnected during all installation procedures. • Check that the temperature ranges given are suitable for the installation site.
-
Page 4: Dismantling And Disposal
DISMANTLING AND DISPOSAL CAME S.p.A. employs an Environmental Management System at its premises. This system is certified and compliant with the UNI EN ISO 14001 standard to ensure that the environment is respected and safeguarded. Please continue safeguarding the environment. At CAME we consider it one of the fundamentals of our operating and market strategies. -
Page 5: Intended Use
Grey RAL7024. 801MP-0140 ATS50DGM - Irreversible telescopic gearmotor 24 V with encoder for swing gates with C max. 200 mm with leaf up to 5 m and 400 kg, for applications also at low temperatures. Grey RAL7024. Intended use Solutions for applications in residential buildings and apartment blocks Any installation and/or use other than that specified in this manual is forbidden. -
Page 6: Description Of Parts
Door to access the end-of-travel adjustment screws Door to access the release mechanism M12,1 UNI6592 Sheath connector Pillar bracket Release key Release cord* M12 UNI7474 Cutting hazard labels * ATS30DGR M8x35 UNI5737 M8 UNI5588 Size 1320 ATS30DGS ATS30DGR ATS30DGM 1550 ATS50DGS 1050 ATS50DGM... - Page 7 (**) The average product life specified should be understood purely as an indicative estimate. It applies to normal usage conditions and where the product has been installed and maintained in compliance with the instructions provided in the CAME technical manual. The average product life is also affected, including significantly, by other variables such as, but not limited to, climatic and environmental conditions.
-
Page 8: Installation
INSTALLATION The following illustrations are examples only. The space available for fitting the operator and accessories varies depending on the area where it is installed. It is up to the installer to find the most suitable solution. The drawings refer to a gearmotor installed on the left-hand side. Preliminary operations Prepare the junction boxes and corrugated tubes you need for the connections from the junction pit. - Page 9 Respect the values indicated in the table. ≥60 ATS30DGS ATS30DGR ATS30DGM Gate-leaf opening (°) Max. C 90° 1220 90° 1290 90° 1300 120° 1300 ATS50DGS ATS50DGM Gate-leaf opening (°) Max. C 90° 1030 1430 90° 1030 1510 120° 1030 1460...
-
Page 10: Fastening The Brackets
Fastening the brackets Secure the post bracket with plugs and screws. The holes on the bracket fixing plate allow you to vary the opening angle of the gate leaf. Fasten in place with screws or weld the bracket to the gate. ø... - Page 11 Fastening the gearmotor Lubricate all moving parts on the operator. The self-locking nut must be loosely tightened so as not to affect the movement of the telescopic arm with the gate bracket. ATS30DGR...
-
Page 12: Electrical Connections
ELECTRICAL CONNECTIONS Before working on the control panel, disconnect the mains power supply and remove the batteries, if any. Remove the protective cover to access the terminal block. Control panel Gearmotor delayed while opening Gearmotor delayed while closing 230 V AC - 50-60 HZ power supply input Yellow/green cable M N ENC M N ENC... - Page 13 Determining the end-of-travel points with micro limit switches Rod for determining the opening end-of-travel point Rod for determining the closing end-of-travel point Micro limit switches The micro switches are positioned at the far ends of the travel range. To move the microswitch 10 mm in either direction, turn the rod 20 times. Determining the opening end-of-travel points Perform these operations on both gearmotors.
- Page 14 Determining the closing end-of-travel points Perform these operations on both gearmotors. Release the gearmotor. Manually close the leaf to the desired point. Disconnect the 9-pole terminal board. Connect the multimeter set to check continuity to the Rc-Rc terminals (NC contact); a buzzer will sound on the multimeter. Turn the shaft (C) ANTICLOCKWISE to determine the closing travel end point, until the Rc-Rc contact opens and the multimeter stops buzzing.
- Page 15 First determine where the gate bracket needs to be positioned, then where the post bracket needs to be positioned. Respect the values indicated in the table. Additional bracket (not included) ATS30DGS ATS30DGR ATS30DGM Gate-leaf opening (°) 90° ATS50DGS ATS50DGM Gate-leaf opening (°) 90° 1030...
- Page 16 Electrical connections Before working on the control panel, disconnect the mains power supply and remove the batteries, if any. Remove the protective cover to access the terminal block. Control panel Gearmotor delayed while opening Gearmotor delayed while closing 230 V AC - 50-60 HZ power supply input Yellow/green cable M1 N1 ENC1 M2 N2 ENC2...
- Page 17 Determining the end-of-travel points with micro limit switches Rod for determining the closing end-of-travel point Rod for determining the opening end-of-travel point Micro limit switches The micro switches are positioned at the far ends of the travel range. To move the microswitch 10 mm in either direction, turn the rod 20 times. Determining the opening end-of-travel points Perform these operations on both gearmotors.
-
Page 18: Final Operations
Determining the closing end-of-travel points Perform these operations on both gearmotors. Release the gearmotor. Manually close the leaf to the desired point. Disconnect the 9-pole terminal board. Connect the multimeter set to check continuity to the Ra-Ra terminals (NC contact); a buzzer will sound on the multimeter. Turn the shaft (A) CLOCKWISE to determine the closing travel end point, until the Ra-Ra contact opens and the multimeter stops buzzing. - Page 19 MCBF Models ATS30DGS-ATS30DGR-ATS30DGM ATS50DGS-ATS50DGM 2 m - 800 kg 120000 2.5 m - 600 kg 110000 3 m - 400 kg 100000 2 m - 1000 kg 120000 2.5 m - 800 kg 110000 3 m - 600 kg 100000...
- Page 20 CAME S.p.A. Via Martiri della Libertà, 15 31030 Dosson di Casier Treviso – Italy Tel. (+39) 0422 4940 Fax (+39) 0422 4941...
