Instructions - Parts List
Oil Meter
For metering oils.
Model 260415
80 psi (0.55 MPa, 5.5 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Meter Calibration . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Meter Assembly and Disassembly . . . . . . . . . . . . 5
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . 8
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001
311310 rev.B
Advertisement
Table of Contents
Related Manuals for Graco 260415
Summary of Contents for Graco 260415
- Page 1 Graco Standard Warranty ....8 Graco Information ......8 Graco Inc.
- Page 2 Graco replacement parts only. • Do not alter or modify equipment. • Use equipment only for its intended purpose. Call your Graco distributor for informa- tion. • Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
- Page 3 Installation Installation Meter Meter Calibration See Parts, page 6. The meter is factory calibrated for use with 10 weight motor oil at 70°F (21°C). To recalibrate 1. When unpacking meter, check for shipping meter for different fluids, or to recalibrate meter damage.
- Page 4 Troubleshooting Troubleshooting Problem Cause Solution Meter runs in reverse. Meter installed backward. Install meter with port marked “inlet” to pump outlet. Fluid leakage in counter. Seal on counter input shaft Replace counter assembly. leaking. Dust and dirt in counter cover. Cover seal (8) or knob seal Install missing seal, or correct (10) missing or improperly installation.
- Page 5 Repair Repair Meter Assembly and 4. To remove disk assembly (3, 4, 5), remove two screws (7) and washers (6). Disk parts Disassembly must be replaced as an assembly; order kit number 260430. To replace any of the major assemblies, disas- semble meter as follows.
- Page 6 Parts Parts 260415 Ref. Ref. Description Qty. Description Qty. SEAL, grommet HOUSING, meter SCREW; 8-32 x 1/4 in. SEAL, o-ring HOUSING, counter, cover CHAMBER, lower HEX BOLT; 1/4-20 x 3/4 in. DISK COUNTER, assembly, quarts CHAMBER, upper SEAL, o-ring WASHER SCREW, adjustment SCREW;...
- Page 7 Technical Data Technical Data Maximum Working Pressure 80 psi (0.55 MPa, 5.5 bar) Inlet Size 3/4 in. npt Outlet Size 3/4 in. npt Weight 2.5 lb (1.1 kg) Wetted Parts diecast aluminum, carbon steel with zinc plat- ing, 12L14 steel with zinc plating, 416 stainless ®...
- Page 8 With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
