Instructions - Parts List
Herbicide Pump
For pumping herbicides. Do not use to pump other fluids including water.
Model 260410, 10 gpm (38 lpm), 12 VDC (CSA C/US listed motor)
Model 260411, 10 gpm (38 lpm), 12 VDC (CSA C/US listed motor)
Includes 8 ft (2.44 m) hose, nozzle and inlet suction tube
Model 260408, 12 gpm (45 lpm), 115 VAC
Model 260409, 12 gpm (45 lpm), 115 VAC
Includes 8 ft (2.44 m) hose, nozzle and inlet suction tube
10 psi (0.07 MPa, 0.7 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mounting Pump . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mounting Hose and Nozzle . . . . . . . . . . . . . . . . . 4
Electrical Installation 12 VDC . . . . . . . . . . . . . . . 4
Electrical Installation 115 VAC . . . . . . . . . . . . . . . 5
Priming Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Flushing Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Parts Drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Parts List (continued) . . . . . . . . . . . . . . . . . . . . . . 12
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 14
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 14
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001
311628 rev.B
CSA mark applies only to 12 VDC motors
for Class I, Div I, Group D Hazardous
Locations.
Advertisement
Table of Contents
Related Manuals for Graco BLUE DEVIL 260410
Summary of Contents for Graco BLUE DEVIL 260410
-
Page 1: Table Of Contents
Graco Standard Warranty ....14 Graco Information ......14... -
Page 2: Warnings
Warnings Warnings The following general warnings are for the setup, use, grounding, maintenance, and repair of this equipment. Addi- tional, more specific warnings may be found throughout the body of this manual where applicable. Symbols appear- ing in the body of the manual refer to these general warnings. When these symbols appear throughout the manual, refer back to these pages for a description of the specific hazard. - Page 3 Read fluid and solvent manufacturer’s warnings. For complete information about your material, request MSDS forms from distributor or retailer. • Check equipment daily. Repair or replace worn or damaged parts immediately with genuine Graco replacement parts only. •...
-
Page 4: Installation
Suction tubes longer than 60 wires. in. (1.52 m) require a foot valve (Graco Part No. 260217) at the bottom of the tube to prevent loss of 5. Slide strain relief (6b) over end of power cable (6c) prime. -
Page 5: Electrical Installation 115 Vac
Connect black wire to negative bat- off. tery terminal. 3. To hold fluid in the suction tube, a check valve (Graco Part No. 260217) may be required on the Electrical Installation bottom of tanks with a suction height over 5 ft (1.52 115 VAC 4. -
Page 6: Operation
Operation Operation Maintenance 1. Clean inlet strainer (3b) after every 50 hours of operation. Before servicing, turn pump off and open the nozzle to relieve pressure. 2. To remove inlet strainer (3b), remove four screws (3c) and strainer cover (3a). Remove and clean strainer. - Page 7 Maintenance 311628B...
-
Page 8: Troubleshooting
Troubleshooting Troubleshooting Problem Cause Solution Motor runs but pump will not prime. Motor rotation wrong. (12 VDC units Check wiring instructions for possible only.) problems. Missing relief valve o-ring seal (4c). Remove gear cover (1b) inspect seal (4c), replace if missing or damaged. Sheared drive key (1g). - Page 9 Troubleshooting Problem Cause Solution Herbicide leaking in motor mount. Faulty or damaged motor shaft seal Replace shaft seal (1h). Operating pump extended time with Do not exceed 5 minutes of operation nozzle closed. with nozzle closed. Motor shaft worn. Replace motor if shaft has groove worn in seal area.
-
Page 10: Parts Drawing
Parts Drawing Parts Drawing Models 260410 and 260411, 12 VDC Models 260408 and 260409, 115 VAC 260456 260458 1f/10c 253723 1g/10b 1c/ 10a 260544 260300 260450 260452 253719 253721 260433 253718 260454 311628B... -
Page 11: Parts List
Parts List Parts List Models 260410 and 260411, 12 VDC Models 260408 and 260409, 115 VAC Ref. No. Description Qty. Ref. No. Description Qty. 260300 KIT, suction, pipe; includes items 260458 KIT, pump with swivel, blue 5a-5d (Models 260411, 260409 only) (includes items 1a-1k) PIPE, PVC 253723 KIT, pump with swivel, black... -
Page 12: Parts List (Continued)
Technical Data Technical Data Working pressure ....... 10 psi (0.07 MPa, 0.7 bar) Inlet size . -
Page 13: Technical Data
Technical Data 311628B... -
Page 14: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
