QUICKSTART GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TIMPANI2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Luxli TIMPANI2

Summary of Contents for Luxli TIMPANI2

  • Page 1 QUICKSTART GUIDE...

  • Page 2: Firmware Upgrade

    • All images are for illustrative purposes only. Firmware Upgrade Firmware updates are available through the Composer app. Refer to the Timpani2’s full user manual available at www.luxlilight.com for information and instructions. Troubleshooting • If you encounter any problems, first try turning the device off and then on.
  • Page 3 Overview Front: 1. Diffuser 5. Center mounting screw 2. Diffuser thumbscrews 6. Outer mounting screw 3. Tilt lock handle 7. Locking handle 4. Tilt control screw 8. 5/8 in. receiver...
  • Page 4 TIMPANI MODE DC 12.5–30 V SERVICE DMX IN DMX OUT Back: 1. Removable handle 5. 5-pin DMX output 2. 4-pin power input 6. Bluetooth antenna 3. Manufacturer’s service port 7. User interface (see Interface Overview p. 8) 4. 5-pin DMX input...
  • Page 5 Power supply: 1. 4-pin power output 2. V-mount battery plate 3. Battery release button 4. AC power input Also included: • 4-pin XLR cable • AC cable (3-Prong US - C5 Connector) • Photometric calibration results data sheet...
  • Page 6 Setting Up the Timpani2 Attaching the Tilt Lock Handle The tilt lock handle can be attached to either side of the Timpani2. To attach the handle, follow these steps: 1. Place the Timpani2 and yoke facedown on a flat surface.
  • Page 7 Powering the Timpani2 Battery Power 1. Connect the 4-pin XLR cable to the power supply and the Timpani2. 2. Slide a V-mount battery into the power supply’s battery plate until it locks into place. To remove the battery, press the battery release, and slide it off the plate.

  • Page 8: Interface Overview

    Interface Overview MODE Intensity Dial In all operation modes, the Intensity dial adjusts to the intensity from 100% to 0% in 1% increments. In all operation modes, press the Intensity dial to toggle between the set intensity and 0%. 2. Power Button Press to power on or off.

  • Page 9: User Interface

    13). 5. Power Display • Batteries with SMBUS data 3h 31m communication: The Timpani2 displays an estimated time remaining at the top of the screen. • Batteries without SMBUS data 24.2V communication or AC power: The Timpani2 displays the actual voltage of the power source.
  • Page 10 CCT Mode 1. Intensity 24.2V 2. CCT • Select any color temperature from 2800 to +/- GREEN 10,000 K in 50 K increments. 3900K • Press the Adjustment dial to toggle between 3200 and 5600 K. 3. Tint (+/− Green) Screen •...

  • Page 11: Filter Mode

    Filter Mode 1. Filter Name, Number and Color Preview 3900K 24.2V 24.2V 24.2V Medium Purple Mauve 2. Base CCT Level Bright Pink • Adjust the base color temperature from Follies Pink Rose Pink 2800 to 10,000 K in 50 K increments. Smokey Pink Scarlet 3.

  • Page 12: Effects Mode

    • Opens the Edit menu (see below). BACK Edit Menu The Timpani2 displays the changes in real time as you modify them, so you can experiment with the settings while running the effect. 4. Scroll to the setting you want to edit, and press Select.

  • Page 13: Fcc Compliance Statement

    Main Menu Main menu Press the Menu button in all operating modes Presets to access the Main menu. Bluetooth Use the Adjustment dial to choose Presets, DMX, Display SELECT Bluetooth, Display, or About, and press Select to About access the menu. BACK FCC Compliance Statement This device complies with part 15 of the FCC rules.

  • Page 14: Specifications

    Specifications Light Fixture Beam Angle (with Diffuser) 78° Color Temperature 2800 to 10,000 K Color Accuracy Standard CRI: 3200 K: 97, 4300 K: 98, 5600 K: 97 TLCI: 3200 K: 96, 4300 K: 97, 5600 K: 98 Cooling System Passive Dimming Yes, 0% to 100% (continuous) Light Panel...

  • Page 15: One-Year Limited Warranty

    14.4 V and 26 V Max Power Consumption 120 W One-Year Limited Warranty For more information, visit www.luxlilight.com or call Customer Service at 212-594-2353. Luxli is a registered trademark of the Gradus Group. © 2021 Gradus Group LLC. All Rights Reserved.
  • Page 16 luxlilight.com...
