- Page 2 Light as soft as a cloud. As part of Luxli’s Softi series, the LED Ring Light with Camera Mount provides soft, flattering light without harsh shadows. Control the intensity when illuminating your subject with a variable dimmer and dial in the right amount of light for a proper exposure.
-
Page 3: Specifications
Specifications Light source 441 LEDs Color temperature 3200 K (with tungsten filter) or 5600 K Brightness 11,000 lx per 19.7" (50 cm) Power Source A C p o w e r ( w i t h i n c l u d e d a d a p t e r ) or two Sony L-Series batteries Continuous operating time Up to 150 min. - Page 4 Precautions • Do not attempt to disassemble, repair, or perform any unauthorized modifications on this device. • Do not handle with wet hands, immerse in liquids, or expose to water and rain. Electric shock or fire may result. • This device contains small parts which may pose a choking hazard. Keep out of reach of children.
- Page 5 • Batteries are prone to leakage when fully discharged. To avoid damaging this product, be sure to remove batteries when leaving the product unattended. • Do not cover the ventilation grille found at the rear of the device when in operation, and ensure the light is cool before storing. •...
- Page 6 Overview Front Back 1. Battery release button 2. Battery mounts 5. Power LED indicator 3. Magnetic posts 6. Power switch 4. Handle 7. Battery test button 8. Battery power indicator 9. Dimmer 10. Threaded sockets 11. Bracket locking knobs 12. DC power input 10 11...
- Page 7 • B a t te r y c h a rg e r p owe r • Tungsten filter adapter • Filter magnets • SFT-50R power adapter • 2 × NP-F750 rechargeable • Power cord batteries • Padded carrying case...
- Page 8 Powering the Ring Light Using the AC Power Adapter Mounting Batteries 1. Plug the 3-pronged end of 1. Place each battery in the the power cord into a power battery tray, aligning the source. conductor contacts of the battery with the metal prongs 2.
- Page 9 Checking the Battery Power While the device is powered on, hold the battery test button to see how much power is remaining. Charging the Batteries 1. Plug one end of the battery charger’s power adapter into a power source, and the other end into the dual battery charger.
- Page 10 Setting up the Ring Light Mounting the Macro Slider Mounting the Ring Light There are two 1/4"-20 threaded 1. Align the macro slider’s sockets to mount the macro slider mounting bracket with the to a tripod. One is for horizontal threaded sockets on the back orientation.
- Page 11 Attaching a Camera 1. Seat your camera’s threaded 2. Rotate the camera locking tripod socket onto the 1/4"-20 wheel until secure. camera mount.
- Page 12 Adjusting the Lens and Camera Vertical Alignment Macro Slider Control You can adjust the bracket R o ta te t h e m a c ro s l i d e r vertically to fit your camera and adjustment knob to fine-tune lens.
- Page 13 Adjusting the Light Dimming Attaching the Filters Rotate the dimming knob until To install the diffusion or tungsten the desired effect is achieved. You filters, align the filter’s magnets can adjust the desired brightness with the magnets on the ring light. level from 10%–100%.
-
Page 14: One-Year Limited Warranty
One-Year Limited Warranty This LUXLI product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall be... - Page 15 To obtain warranty coverage, contact the Luxli Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Luxli along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
- Page 16 www.luxlilight.com...
