Installation Instructions
Original Instructions
ArmorKinetix 2090 Cables and Connectors
Catalog Numbers 2090-CDHIFS-12AF, 2090-CDHP1S-12AF, 2090-CSBM1P7-14AF, 2090-CPWFLP7-14AF, 2090-CFBM7S7-CDAF, 2090-CFBFLS7-CDAF,
2090-CDET, 2090-CDHT, 2090-CDFT, 2090-CDPT
Topic
Cable Catalog Numbers
Before You Begin
ArmorKinetix Cable System Overview
Guidelines for Cable and Connector Installation
ArmorKinetix PIM to DSx Hybrid Cable Installation
ArmorKinetix DSx to DSx Hybrid Cable Installation
ArmorKinetix DSD to Kinetix VPL/MPL Motor Power/Feedback Cable Installation
ArmorKinetix DSD to Induction Motor Power Cable Installation
ArmorKinetix DSD to Kinetix Motor Feedback Cable Installation
ArmorKinetix DSD to Induction Motor and Auxiliary (stand-alone) Feedback Cable Installation
ArmorKinetix 2090 Hybrid Connector Communication Extension
Cable Bend Radius Specifications
ArmorKinetix Cables Environmental Specifications
Additional Resources
Cable Catalog Numbers
Catalog numbers consist of various characters, each of which identifies a specific option for that component. Use the catalog numbering charts below to understand the
configuration of your component. For the cable type: PUR = Polyurethane and TPE = Thermoplastic Elastomer.
ArmorKinetix PIM to ArmorKinetix DSx Hybrid Cables
This cable connects the ArmorKinetix® Power Interface Module (PIM) to either the ArmorKinetix Distributed Servo Motor (DSM) or the Distributed Servo Drive (DSD).
2090 - C DH IF S - 12 AF xx xx
Length Increments
P1 = 0.1 m, P2 = 0.2 m, P3 = 0.3 m, P4 = 0.4 m, P5 = 0.5 m,
P6 = 0.6 m, P7 = 0.7 m, P8 = 0.8 m, P9 = 0.9 m, Blank = 0
(a)
Length
xx = 3...50 m
Cable Type
AF = TPE, Continuous-flex
Wire Gauge
12 AWG
Downstream Connector
S = SpeedTec (socket)
Upstream Connector
IF = PIM end flying leads
Cable Type
DH = Hybrid
Accessory
C = Cable
Bulletin
(a)
For 3 m to 5 m cable lengths, cables are available in 0.1 m
increments. For cable lengths longer than 5 m, cables are
available in 0.5 m increments.
Page
1
3
4
5
5
6
7
7
8
8
9
9
10
10
Advertisement
Related Manuals for Rockwell Automation ArmorKinetix 2090
Summary of Contents for Rockwell Automation ArmorKinetix 2090
- Page 1 ArmorKinetix DSD to Induction Motor Power Cable Installation ArmorKinetix DSD to Kinetix Motor Feedback Cable Installation ArmorKinetix DSD to Induction Motor and Auxiliary (stand-alone) Feedback Cable Installation ArmorKinetix 2090 Hybrid Connector Communication Extension Cable Bend Radius Specifications ArmorKinetix Cables Environmental Specifications...
- Page 2 ArmorKinetix 2090 Cables and Connectors Installation Instructions ArmorKinetix DSx to DSx Hybrid Cables ArmorKinetix DSD to Induction Motor Power Cable This cable connects distributed servo drives and motors to each other. This cable connects the DSD to induction motors with open loop, Hiperface, incremental TTL, and generic SIN/COS encoders.
-
Page 3: Before You Begin
ArmorKinetix 2090 Cables and Connectors Installation Instructions ArmorKinetix DSD to Induction Motor Feedback or Auxiliary Feedback Cable This cable connects an induction motor feedback or auxiliary feedback device to the distributed servo drive. 2090 - C FB FL S7- CD AF xx... - Page 4 ArmorKinetix 2090 Cables and Connectors Installation Instructions ArmorKinetix Cable System Overview Each ArmorKinetix PIM module supports up to 24 ArmorKinetix DSD and/or DSM modules. Total cable length for the ArmorKinetix system (PIM, DSD including motor connections, and DSM modules) is 140 m (459 ft) maximum.
- Page 5 Route the cable to the module. Insert the connector plug into the module connector. IMPORTANT There is a maximum of two PIM modules per bus group, therefore, only two ArmorKinetix 2090-CDHIFS-12AFxxxx hybrid cables per bus group. Rockwell Automation Publication 2090-IN053A-EN-P - April 2023...
- Page 6 ArmorKinetix 2090 Cables and Connectors Installation Instructions ArmorKinetix DSx to DSx Hybrid Cable Installation ArmorKinetix DSx to DSx Hybrid Cable and ArmorKinetix DSx to DSx Zero Stack Jumper Cable Pinouts - 2090-CDHP1S-12AFxxxx and 2090-CDHP1S-12AFJ Cable Bend Radius Specifications on page...
- Page 7 ArmorKinetix 2090 Cables and Connectors Installation Instructions ArmorKinetix DSD to Kinetix VPL/MPL Motor Power/Feedback Cable Installation DSD to VPL/MPL Power Cable (2090-CSBM1P7-14AFxx) Cable Bend Radius Specifications on page Plug Connector Socket Connector Socket Plug Brown (U) Black (V) Blue (W)
- Page 8 ArmorKinetix 2090 Cables and Connectors Installation Instructions ArmorKinetix DSD to Kinetix Motor Feedback Cable Installation DSD to Kinetix Motor Feedback Cable (2090-CFBM7S7-CDAFxx) Cable Bend Radius Specifications on page M‘17 SIN + 26 AWG BLACK SIN + SIN - SIN -...
- Page 9 ArmorKinetix 2090 Cables and Connectors Installation Instructions ArmorKinetix 2090 Hybrid Connector Communication Extension The hybrid connector communication extension has only the communication/Ethernet pins populated on the M23 side, and passes through to an M12 X-coded Ethernet connection on the other side.
-
Page 10: Additional Resources
Water Absorption 168 hours (7 days). Additional Resources These documents contain additional information concerning related products from Rockwell Automation. You can view or download publications at rok.auto/literature. Resource Description Provides information on installing, configuring, startup, troubleshooting, and applications for your...
