Installation Instructions
Original Instructions
2090-Series Kinetix TLP Power and Feedback Cables
Catalog Numbers 2090-CTPW-MEDF, 2090-CTPW-MDDF, 2090-CTPB-MDDF, 2090-CTPW-MCDF, 2090-CTPB-MCDF, 2090-CTPB-MADF, 2090-
CTPW-MADF, 2090-CTBK-MBDF, 2090-CTFB-MADD, 2090-CTFB-MFDD, 2090-CTPW-MEET, 2090-CTPW-MDET, 2090-CTPB-MDET, 2090-CTPW-
MCET, 2090-CTPB-MCET, 2090-CTPW-MAET, 2090-CTPB-MAET, 2090-CTBK-MBET, 2090-CTFB-MFET, 2090-CTFB-MAET
Topic
Summary of Changes
This publication contains the following new or updated information. This list includes substantive updates only and is not intended to reflect all changes.
Topic
Added catalog numbers for the Kinetix TLP 400V motors.
Page
1
2
3
3
5
7
9
12
Page
3...4
Advertisement
Related Manuals for Rockwell Automation Allen-Bradley Kinetix 2090 Series
Summary of Contents for Rockwell Automation Allen-Bradley Kinetix 2090 Series
-
Page 1: Table Of Contents
Installation Instructions Original Instructions 2090-Series Kinetix TLP Power and Feedback Cables Catalog Numbers 2090-CTPW-MEDF, 2090-CTPW-MDDF, 2090-CTPB-MDDF, 2090-CTPW-MCDF, 2090-CTPB-MCDF, 2090-CTPB-MADF, 2090- CTPW-MADF, 2090-CTBK-MBDF, 2090-CTFB-MADD, 2090-CTFB-MFDD, 2090-CTPW-MEET, 2090-CTPW-MDET, 2090-CTPB-MDET, 2090-CTPW- MCET, 2090-CTPB-MCET, 2090-CTPW-MAET, 2090-CTPB-MAET, 2090-CTBK-MBET, 2090-CTFB-MFET, 2090-CTFB-MAET Topic Page Summary of Changes Before You Begin Catalog Number Explanation Motor Connector/Cable Compatibility... -
Page 2: Before You Begin
Standard (non-flex) cables can be bent or reformed during installation and maintenance. Continuous-flex cables can be flexed repeatedly within a specified bend radius when properly installed. Do not use standard cables in a continuous-flex operation. Rockwell Automation Publication 2090-IN046B-EN-P - August 2020... -
Page 3: Catalog Number Explanation
• 2090-CTPW-MADF-xxAxx (standard, non-flex) power-only cables • 2090-CTPW-MADF-xxFxx (continuous-flex) power-only cables • TLP-A046-xxx…TLP-A100-xxx motors • Receives rectangular cable plugs • 2090-CTFB-MADD-CFAxx (standard, non-flex) drive-end connector feedback cables • 2090-CTFB-MADD-CFFxx (continuous-flex) drive-end connector feedback cables Rockwell Automation Publication 2090-IN046B-EN-P - August 2020... - Page 4 • 2090-CTPW-MEDF-xxFxx (continuous-flex) power-only cables • Receives military style cable plugs • 2090-CTBK-MBDF-xxAxx (standard, non-flex) flying-lead brake cables • 2090-CTFB-MBDF-xxFxx (continuous-flex) flying-lead brake cables For cable specifications, refer to Kinetix Motion Accessories Technical Data, publication KNX-TD004. Rockwell Automation Publication 2090-IN046B-EN-P - August 2020...
-
Page 5: Install Kinetix Tlp Motor Cables
The motor-end (rectangular) connector that is 19.0 mm (0.75 in.) square, requires a 26 mm (1.02 in.) hole to pass through. The motor-end (military-style) connector that is 37.2 mm (1.50 in.) diameter, requires a 48 mm (1.89 in.) hole to pass through. Rockwell Automation Publication 2090-IN046B-EN-P - August 2020... - Page 6 The motor-end (military-style) connector that is 43.0 (1.69) diameter, requires a 53 mm (2.09 in.) hole to pass through. The motor-end (military-style) connector that is 55.2 mm (2.17 in.) diameter, requires a 65 mm (2.56 in.) hole to pass through. Rockwell Automation Publication 2090-IN046B-EN-P - August 2020...
-
Page 7: Install Continuous-Flex Extension Cables
The motor-end (rectangular) connector that is 19.0 mm (0.75 in.) square, requires a 26 mm (1.02 in.) hole to pass through. The motor-end (military-style) connector that is 37.2 mm (1.50 in.) diameter, requires a 48 mm (1.89 in.) hole to pass through. Rockwell Automation Publication 2090-IN046B-EN-P - August 2020... - Page 8 The motor-end (military-style) connector that is 43.0 mm (1.69 in.) diameter, requires a 53 mm (2.09 in.) hole to pass through. The motor-end (military-style) connector that is 55.2 mm (2.17 in.) diameter, requires a 65 mm (2.56 in.) hole to pass through. Rockwell Automation Publication 2090-IN046B-EN-P - August 2020...
-
Page 9: Pinout Specifications
BAT+ 2090-CTFB-MADD- Feedback cables Brown CFAxx (standard, non- Blue 2090-CTFB-MFDD- flex) White/Red CFAxx White 2090-CTFB-MADD-CFxxx Shield/Drain 2090-CTFB-MADD- Feedback cables Connector to Motor 2090-CTFB-MFDD-CFxxx 2090-CTFB-MFDD-CFxxx CFFxx (continuous-flex) 2090-CTFB-MADD-CFxxx Connector to Motor Connector to Drive Rockwell Automation Publication 2090-IN046B-EN-P - August 2020... - Page 10 Do not coil a power cable except for temporary use when building or testing a machine. If you temporarily coil a power cable, you must also derate the cable to meet local code or follow an authoritative directive, such as Engineering Section 310.15(C) of the NEC Handbook. Rockwell Automation Publication 2090-IN046B-EN-P - August 2020...
- Page 11 2090-CTPW-MCET and 2090CTPW-MDET cables exclude the Red and Black twisted pair conductors. Brake Only Extension Cable Pinout Black 2090-CTBK-MBET-20Fxx Foil Feedback Extension Cable Pinouts Encoder Plug Extension Plug Black BAT- BAT+ 2090-CTFB-MFET-CFFxx Brown H G F Blue White/Red White Shield/Drain 2090-CTFB-MAET-CFFxx Rockwell Automation Publication 2090-IN046B-EN-P - August 2020...
-
Page 12: Additional Resources
2090-Series Kinetix TLP Power and Feedback Cables Installation Instructions Additional Resources These documents contain additional information concerning related products from Rockwell Automation. Resource Description Provides product specifications for Kinetix VPL, VPC, VPF, VPH, VPS, Kinetix Kinetix Rotary Motion Specifications Technical Data, publication... - Page 13 2090-Series Kinetix TLP Power and Feedback Cables Installation Instructions Notes: Rockwell Automation Publication 2090-IN046B-EN-P - August 2020...
- Page 14 Rockwell Otomasyon Ticaret A.Ş. Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400 EEE Yönetmeliğine Uygundur Allen-Bradley, expanding human possibility, Kinetix, LDC-Series, LDL-Series, and Rockwell Automation are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies.
