Rockwell Automation Allen-Bradley 800G-ACGK1 Installation Instructions

Bul. 800G
Publication 800G-IN006B-EN-P - May 2022
Installation instructions
en
de Montageanweisung
Notice de montage
fr
it Istruzioni di montaggio
zh
es Instrucciones de montaje
ru
pt Instruções de instalação
ko
설치 매뉴얼
ATTENTION: To help prevent electrical shock, disconnect from
power source before installing or servicing. Follow NFPA 70E
requirements or other applicable installation standards. Install in
suitable enclosure. Keep free from contaminants.
Only suitably trained personnel can install, adjust, commission,
use, assemble, disassemble, and maintain the product in
accordance with applicable codes of practice. If a malfunction or
damage occurs, do not attempt to repair the product.
IMPORTANT When working in hazardous areas, the safety of personnel
and equipment depends on compliance with the relevant
safety regulations. The people in charge of installation and
Maintenance bear a special responsibility. They must be
knowledgeable of the applicable rules and regulations.
These instructions provide a summary of the most important
installation measures. Everyone working with the product
must read these instructions so that they are familiar with the
correct handling of the product.
Keep these instructions for future reference as they must be
available throughout the expected life of the product.

Product Description

• Plastic Cable Gland Kits
These kits must be installed within Bulletin 800G"-EX"
assembled stations. They cannot be used in Bulletin 800G
c-UL-us stations for Class I Division 2 and Class I Zone 1
hazardous areas. They are not intended to be installed in
third-party explosion-proof or ame-proof enclosures. Cable
gland kit conects are as follows:
Cat. No. Description
800G-ACGK1 M20 plastic cable gland (1) with earth bracket (1)
800G-ACGK3 M25 plastic cable gland (1) with earth bracket (1)
• Metal Cable Gland Kits
These kits must be installed within Bulletin 800G "-EX"
assembled stations or Bulletin 800G c-UL-us assembled
stations for Class I Division 2 and Class I Zone 1 hazardous
areas. They are not intended to be installed in third-party
explosions-proof or ame-proof enclosures. Cable gland kit
conects are as follows:
Cat. No. Description
800G-ACGK5 M20 metal cable gland (1) with earth plate (1)
800G-ACGK6 M25 metal cable gland (1) with earth plate (1)
800G-ACGK7 M20S metal cable gland (2) with earth plate (1)
Latch Mount Back-of-Panel Modules

Specifications

Plastic Cable Glands

Certifications and Ratings (Bulletin 800G Assembled Stations)

c-UL-us Stations
ATEX (-EX Stations) CML 15 ATEX 3024
IECEx (-EX Stations) IECEx CML 15.0014
CML 21 UKEX 31392
UKEx(-EX Stations)
INMETRO (-EX Stations) UL-BR 17.0366
CCC (-EX Stations) 2020122304113731
• II 2 G Ex db eb IIC T6 Gb
Gas and Dust protection type
• II 2 D Ex tb IIIC T80C Db
-55...+60 °C
Ambient Temperature Range
(-67...+140 °F)
Degree of Protection IP64, IP66

Miscellaneous Cable Gland Kit Product Information

• Body/Cap: Polyamide
Cable Gland Material
• Seal: Silicone
Cable Gland Outer Thread
M20 x 1.5, M25 x 1.5
Size and Pitch
• M20: 7...13 mm
Cable Gland Clamping Range (9/32...33/64 in.)
(Inner Seal)
• M25: 12...17 mm
(15/32...43/64 in.)
Cable Gland Clamping Range
(Outer Seal)
Armor™ Wire Clamping
Range
PN-534159 DIR 10004603657 (Version 01)
At the end of its life, this
equipment should be
collected separately from
any unsorted municipal
waste.
Metal Cable Gland
—
E10314
CML 15 ATEX 3024
IECEx CML 15.0014
CML 21 UKEX 31392
UL-BR 17.0366
2020122304113731
• II 2 G Ex db eb IIC T6 Gb
• II 2 D Ex tb IIIC T80C Db
-55...+60 °C
(-67...+140 °F)
IP64, IP66
• Body/Cap: Nickel-plated
brass
• Seal/O-ring: Silicone
M20 x 1.5, M25 x 1.5
• M20S: 6...12 mm
(15/64...15/32 in.)
• M20: 8.5...14.5 mm
(21/64...37/64 in.)
• M25: 12...20 mm
(15/32...25/32 in.)
• M20S: 8.5...16 mm
(21/64...33/64 in.)
• M20: 12...20 mm
—
(15/32...43/64 in.)
• M25: 16...26 mm
(33/64...1-1/32 in.)
• M20S: 0.7...1.25 mm
(1/32...3/64 in.)
• M20: 0.9...1.3 mm
—
(1/32...3/64 in.)
• M25: 1.0...1.6 mm
(3/64...1/16 in.)
